DODGE Extreme Duty SCMED Medium Duty 4-Bolt Flange

DODGE Extreme Duty SCMED Medium Duty 4-Bolt Flange

DODGE Extreme Duty SCED/SCMED set screw mounted ball bearings are built for demanding industrial service where equipment uptime is critical.

Key features

  • 65° set screws give maximum locking force without weakening the inner ring
  • Anti-rotation pin prevents insert rotation in the housing
  • QuadGuard sealing system: triple-lip seal with rubberized flinger
  • Maxlife ball cage for extended grease life
  • Suited to agriculture, aggregate, cement, paper, wood products and metals

Specifications

Brand DODGE
Product line Extreme Duty
Housing style 4-bolt flange
Housing material cast iron
Locking Set screw (65°)
Shaft range 25-85 mm, 1-3-1/2 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 3-25
F4B-SCMED-25M Series: 206 | Shaft: 25 mm | Part no.: 076313
F4B-SCMED-100 Series: 206 | Shaft: 1 in | Part no.: 076150
F4B-SCMED-30M Series: 207 | Shaft: 30 mm | Part no.: 076314
F4B-SCMED-103 Series: 207 | Shaft: 1-3/16 in | Part no.: 076151
F4B-SCMED104 Series: 207 | Shaft: 1-1/4 in | Part no.: Assembled to order
F4B-SCMED-35M Series: 208 | Shaft: 35 mm | Part no.: 076315
F4B-SCMED-107 Series: 208 | Shaft: 1-7/16 in | Part no.: 076152
F4B-SCMED-40M Series: 209 | Shaft: 40 mm | Part no.: 076316
F4B-SCMED-108 Series: 209 | Shaft: 1-1/2 in | Part no.: 076153
F4B-SCMED110L Series: 209 | Shaft: 1-5/8 in | Part no.: Assembled to order
F4B-SCMED-45M Series: 210 | Shaft: 45 mm | Part no.: 076317
F4B-SCMED-111 Series: 210 | Shaft: 1-11/16 in | Part no.: 076154
F4B-SCMED-112 Series: 210 | Shaft: 1-3/4 in | Part no.: 076155
F4B-SCMED-50M Series: 211 | Shaft: 50 mm | Part no.: 076318
F4B-SCMED-115 Series: 211 | Shaft: 1-15/16 in | Part no.: 076156
F4B-SCMED-55M Series: 212 | Shaft: 55 mm | Part no.: 076319
F4B-SCMED-203 Series: 212 | Shaft: 2-3/16 in | Part no.: 076158
F4B-SCMED-65M Series: 214 | Shaft: 65 mm | Part no.: 076320
F4B-SCMED-207 Series: 214 | Shaft: 2-7/16 in | Part no.: 076159
F4B-SCMED-70M Series: 215 | Shaft: 70 mm | Part no.: 076321
F4B-SCMED-211 Series: 215 | Shaft: 2-11/16 in | Part no.: 076161
F4B-SCMED-75M Series: 216 | Shaft: 75 mm | Part no.: 076322
F4B-SCMED-215 Series: 216 | Shaft: 2-15/16 in | Part no.: 076162
F4B-SCMED-300 Series: 216 | Shaft: 3 in | Part no.: 076163
F4B-SCMED-85M Series: 218 | Shaft: 85 mm | Part no.: 076323
F4B-SCMED-307 Series: 218 | Shaft: 3-7/16 in | Part no.: 076164
F4B-SCMED-308 Series: 218 | Shaft: 3-1/2 in | Part no.: 076165
Mounted Bearing UnitsDODGE
27 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE Extreme Duty SCMED Medium Duty 4-Bolt Flange

Brand DODGE·Mounted Bearing Units

Available part numbers (27)

F4B-SCMED-25M, F4B-SCMED-100, F4B-SCMED-30M, F4B-SCMED-103, F4B-SCMED104, F4B-SCMED-35M, F4B-SCMED-107, F4B-SCMED-40M, F4B-SCMED-108, F4B-SCMED110L + 17 more — see full table ↓

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
