DODGE Extreme Duty SCMED Medium Duty Piloted Flange

DODGE Extreme Duty SCMED Medium Duty Piloted Flange

DODGE Extreme Duty SCED/SCMED set screw mounted ball bearings are built for demanding industrial service where equipment uptime is critical.

Key features

  • 65° set screws give maximum locking force without weakening the inner ring
  • Anti-rotation pin prevents insert rotation in the housing
  • QuadGuard sealing system: triple-lip seal with rubberized flinger
  • Maxlife ball cage for extended grease life
  • Suited to agriculture, aggregate, cement, paper, wood products and metals

Specifications

Brand DODGE
Product line Extreme Duty
Housing style Piloted flange
Housing material cast iron
Locking Set screw (65°)
Shaft range 25-85 mm, 1-3-1/2 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 3-27
FC-SCMED-25M Series: 206 | Shaft: 25 mm | Part no.: 076324
FC-SCMED-100 Series: 206 | Shaft: 1 in | Part no.: 076166
FC-SCMED-30M Series: 207 | Shaft: 30 mm | Part no.: 076325
FC-SCMED-103 Series: 207 | Shaft: 1-3/16 in | Part no.: 076167
FC-SCMED-35M Series: 208 | Shaft: 35 mm | Part no.: 076326
FC-SCMED-107 Series: 208 | Shaft: 1-7/16 in | Part no.: 076168
FC-SCMED-40M Series: 209 | Shaft: 40 mm | Part no.: 076327
FC-SCMED-108 Series: 209 | Shaft: 1-1/2 in | Part no.: 076169
FC-SCMED-45M Series: 210 | Shaft: 45 mm | Part no.: 076328
FC-SCMED-111 Series: 210 | Shaft: 1-11/16 in | Part no.: 076170
FC-SCMED-112 Series: 210 | Shaft: 1-3/4 in | Part no.: 076171
FC-SCMED-50M Series: 211 | Shaft: 50 mm | Part no.: 076329
FC-SCMED-115 Series: 211 | Shaft: 1-15/16 in | Part no.: 076172
FC-SCMED-55M Series: 212 | Shaft: 55 mm | Part no.: 076330
FC-SCMED-203 Series: 212 | Shaft: 2-3/16 in | Part no.: 076174
FC-SCMED-65M Series: 214 | Shaft: 65 mm | Part no.: 076331
FC-SCMED-207 Series: 214 | Shaft: 2-7/16 in | Part no.: 076175
FC-SCMED-75M Series: 216 | Shaft: 75 mm | Part no.: 076332
FC-SCMED-215 Series: 216 | Shaft: 2-15/16 in | Part no.: 076177
FC-SCMED-300 Series: 216 | Shaft: 3 in | Part no.: 076178
FC-SCMED-85M Series: 218 | Shaft: 85 mm | Part no.: 076333
FC-SCMED-307 Series: 218 | Shaft: 3-7/16 in | Part no.: 076179
FC-SCMED-308 Series: 218 | Shaft: 3-1/2 in | Part no.: 076180
Mounted Bearing UnitsDODGE
23 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE Extreme Duty SCMED Medium Duty Piloted Flange

Brand DODGE·Mounted Bearing Units

Available part numbers (23)

FC-SCMED-25M, FC-SCMED-100, FC-SCMED-30M, FC-SCMED-103, FC-SCMED-35M, FC-SCMED-107, FC-SCMED-40M, FC-SCMED-108, FC-SCMED-45M, FC-SCMED-111 + 13 more — see full table ↓

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
FC-SCMED-25MSeries: 206 | Shaft: 25 mm | Part no.: 076324
FC-SCMED-100Series: 206 | Shaft: 1 in | Part no.: 076166
FC-SCMED-30MSeries: 207 | Shaft: 30 mm | Part no.: 076325
FC-SCMED-103Series: 207 | Shaft: 1-3/16 in | Part no.: 076167
FC-SCMED-35MSeries: 208 | Shaft: 35 mm | Part no.: 076326
FC-SCMED-107Series: 208 | Shaft: 1-7/16 in | Part no.: 076168
FC-SCMED-40MSeries: 209 | Shaft: 40 mm | Part no.: 076327
FC-SCMED-108Series: 209 | Shaft: 1-1/2 in | Part no.: 076169
FC-SCMED-45MSeries: 210 | Shaft: 45 mm | Part no.: 076328
FC-SCMED-111Series: 210 | Shaft: 1-11/16 in | Part no.: 076170
FC-SCMED-112Series: 210 | Shaft: 1-3/4 in | Part no.: 076171
FC-SCMED-50MSeries: 211 | Shaft: 50 mm | Part no.: 076329
FC-SCMED-115Series: 211 | Shaft: 1-15/16 in | Part no.: 076172
FC-SCMED-55MSeries: 212 | Shaft: 55 mm | Part no.: 076330
FC-SCMED-203Series: 212 | Shaft: 2-3/16 in | Part no.: 076174
FC-SCMED-65MSeries: 214 | Shaft: 65 mm | Part no.: 076331
FC-SCMED-207Series: 214 | Shaft: 2-7/16 in | Part no.: 076175
FC-SCMED-75MSeries: 216 | Shaft: 75 mm | Part no.: 076332
FC-SCMED-215Series: 216 | Shaft: 2-15/16 in | Part no.: 076177
FC-SCMED-300Series: 216 | Shaft: 3 in | Part no.: 076178
FC-SCMED-85MSeries: 218 | Shaft: 85 mm | Part no.: 076333
FC-SCMED-307Series: 218 | Shaft: 3-7/16 in | Part no.: 076179
FC-SCMED-308Series: 218 | Shaft: 3-1/2 in | Part no.: 076180
