DODGE Extreme Duty SCMED Wide Slot Take-Up (25-75 mm, 1-3 in)

DODGE Extreme Duty SCMED Wide Slot Take-Up (25-75 mm, 1-3 in)

DODGE Extreme Duty SCED/SCMED set screw mounted ball bearings are built for demanding industrial service where equipment uptime is critical.

Key features

  • 65° set screws give maximum locking force without weakening the inner ring
  • Anti-rotation pin prevents insert rotation in the housing
  • QuadGuard sealing system: triple-lip seal with rubberized flinger
  • Maxlife ball cage for extended grease life
  • Suited to agriculture, aggregate, cement, paper, wood products and metals

Specifications

Brand DODGE
Product line Extreme Duty
Housing style Wide slot take-up
Housing material cast iron
Locking Set screw (65°)
Shaft range 25-75 mm, 1-3 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 3-37 to 3-39
WSTU-SCMED-25M Series: 206 | Shaft: 25 mm | Part no.: 076334
WSTU-SCMED-100 Series: 206 | Shaft: 1 in | Part no.: 076190
WSTU-SCMED-30M Series: 207 | Shaft: 30 mm | Part no.: 076335
WSTU-SCMED-103 Series: 207 | Shaft: 1-3/16 in | Part no.: 076191
WSTU-SCMED-35M Series: 208 | Shaft: 35 mm | Part no.: 076336
WSTU-SCMED-107 Series: 208 | Shaft: 1-7/16 in | Part no.: 076192
WSTU-SCMED-40M Series: 209 | Shaft: 40 mm | Part no.: 076337
WSTU-SCMED-108 Series: 209 | Shaft: 1-1/2 in | Part no.: 076193
WSTU-SCMED-45M Series: 210 | Shaft: 45 mm | Part no.: 076338
WSTU-SCMED-111 Series: 210 | Shaft: 1-11/16 in | Part no.: 076194
WSTU-SCMED-112 Series: 210 | Shaft: 1-3/4 in | Part no.: 076195
WSTU-SCMED-50M Series: 211 | Shaft: 50 mm | Part no.: 076339
WSTU-SCMED-115 Series: 211 | Shaft: 1-15/16 in | Part no.: 076196
WSTU-SCMED-55M Series: 212 | Shaft: 55 mm | Part no.: 076340
WSTU-SCMED-203 Series: 212 | Shaft: 2-3/16 in | Part no.: 076198
WSTU-SCMED-65M Series: 214 | Shaft: 65 mm | Part no.: 076341
WSTU-SCMED-207 Series: 214 | Shaft: 2-7/16 in | Part no.: 076199
WSTU-SCMED-70M Series: 215 | Shaft: 70 mm | Part no.: 076342
WSTU-SCMED-211 Series: 215 | Shaft: 2-11/16 in | Part no.: 076201
WSTU-SCMED-75M Series: 216 | Shaft: 75 mm | Part no.: 076343
WSTU-SCMED-215 Series: 216 | Shaft: 2-15/16 in | Part no.: 076202
WSTU-SCMED-300 Series: 216 | Shaft: 3 in | Part no.: 076203
Mounted Bearing UnitsDODGE
22 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE Extreme Duty SCMED Wide Slot Take-Up (25-75 mm, 1-3 in)

Brand DODGE·Mounted Bearing Units

Available part numbers (22)

WSTU-SCMED-25M, WSTU-SCMED-100, WSTU-SCMED-30M, WSTU-SCMED-103, WSTU-SCMED-35M, WSTU-SCMED-107, WSTU-SCMED-40M, WSTU-SCMED-108, WSTU-SCMED-45M, WSTU-SCMED-111 + 12 more — see full table ↓

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
WSTU-SCMED-25MSeries: 206 | Shaft: 25 mm | Part no.: 076334
WSTU-SCMED-100Series: 206 | Shaft: 1 in | Part no.: 076190
WSTU-SCMED-30MSeries: 207 | Shaft: 30 mm | Part no.: 076335
WSTU-SCMED-103Series: 207 | Shaft: 1-3/16 in | Part no.: 076191
WSTU-SCMED-35MSeries: 208 | Shaft: 35 mm | Part no.: 076336
WSTU-SCMED-107Series: 208 | Shaft: 1-7/16 in | Part no.: 076192
WSTU-SCMED-40MSeries: 209 | Shaft: 40 mm | Part no.: 076337
WSTU-SCMED-108Series: 209 | Shaft: 1-1/2 in | Part no.: 076193
WSTU-SCMED-45MSeries: 210 | Shaft: 45 mm | Part no.: 076338
WSTU-SCMED-111Series: 210 | Shaft: 1-11/16 in | Part no.: 076194
WSTU-SCMED-112Series: 210 | Shaft: 1-3/4 in | Part no.: 076195
WSTU-SCMED-50MSeries: 211 | Shaft: 50 mm | Part no.: 076339
WSTU-SCMED-115Series: 211 | Shaft: 1-15/16 in | Part no.: 076196
WSTU-SCMED-55MSeries: 212 | Shaft: 55 mm | Part no.: 076340
WSTU-SCMED-203Series: 212 | Shaft: 2-3/16 in | Part no.: 076198
WSTU-SCMED-65MSeries: 214 | Shaft: 65 mm | Part no.: 076341
WSTU-SCMED-207Series: 214 | Shaft: 2-7/16 in | Part no.: 076199
WSTU-SCMED-70MSeries: 215 | Shaft: 70 mm | Part no.: 076342
WSTU-SCMED-211Series: 215 | Shaft: 2-11/16 in | Part no.: 076201
WSTU-SCMED-75MSeries: 216 | Shaft: 75 mm | Part no.: 076343
WSTU-SCMED-215Series: 216 | Shaft: 2-15/16 in | Part no.: 076202
WSTU-SCMED-300Series: 216 | Shaft: 3 in | Part no.: 076203
