DODGE Grip Tight GT LF 3-Bolt Flange (17-35 mm, 1/2-1-7/16 in)

DODGE Grip Tight GT LF 3-Bolt Flange (17-35 mm, 1/2-1-7/16 in)

DODGE Grip Tight mounted ball bearings use a patented pull/push adapter for shaft-ready, damage-free mounting and dismounting.

Key features

  • Patented pull/push adapter with built-in bearing puller
  • Full 360° concentric shaft contact reduces vibration and fretting
  • Accommodates commercial grade and some undersize shafting
  • Case-carburized inner ring and grade 10 balls
  • Housing assembly and adapter can be purchased separately
  • Fits standard DODGE ball bearing housings

Specifications

Brand DODGE
Product line Grip Tight
Housing style 3-bolt flange
Housing material cast iron
Locking Grip Tight adapter mount
Shaft range 17-35 mm, 1/2-1-7/16 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 5-29
LF-GT-17M Series: 203 | Shaft: 17 mm | Variant: Complete unit | Part no.: Assembled to order
LF-GT-03 Series: 203 | Shaft: 17 mm, 1/2 in, 5/8 in | Variant: Unit without adapter & nut | Part no.: 136360
LF-GT-008 Series: 203 | Shaft: 1/2 in | Variant: Complete unit | Part no.: 136343
LF-GT-010 Series: 203 | Shaft: 5/8 in | Variant: Complete unit | Part no.: 136344
LF-GT-20M Series: 204 | Shaft: 20 mm | Variant: Complete unit | Part no.: 074017
LF-GT-04 Series: 204 | Shaft: 20 mm, 3/4 in | Variant: Unit without adapter & nut | Part no.: 136361
LF-GT-012 Series: 204 | Shaft: 3/4 in | Variant: Complete unit | Part no.: 136345
LF-GT-25M Series: 205 | Shaft: 25 mm | Variant: Complete unit | Part no.: Assembled to order
LF-GT-05 Series: 205 | Shaft: 25 mm, 7/8 in, 15/16 in, 1 in | Variant: Unit without adapter & nut | Part no.: 136362
LF-GT-014 Series: 205 | Shaft: 7/8 in | Variant: Complete unit | Part no.: 136346
LF-GT-015 Series: 205 | Shaft: 15/16 in | Variant: Complete unit | Part no.: 136347
LF-GT-100 Series: 205 | Shaft: 1 in | Variant: Complete unit | Part no.: 136348
LF-GT-30M Series: 206 | Shaft: 30 mm | Variant: Complete unit | Part no.: Assembled to order
LF-GT-06 Series: 206 | Shaft: 30 mm (multi) | Variant: Unit without adapter & nut | Part no.: 136363
LF-GT-102 Series: 206 | Shaft: 1-1/8 in | Variant: Complete unit | Part no.: 136349
LF-GT-103 Series: 206 | Shaft: 1-3/16 in | Variant: Complete unit | Part no.: 136350
LF-GT-104S Series: 206 | Shaft: 1-1/4 in | Variant: Complete unit | Part no.: 136351
LF-GT-35M Series: 207 | Shaft: 35 mm | Variant: Complete unit | Part no.: Assembled to order
LF-GT-07 Series: 207 | Shaft: 35 mm (multi) | Variant: Unit without adapter & nut | Part no.: 136364
LF-GT-104 Series: 207 | Shaft: 1-1/4 in | Variant: Complete unit | Part no.: 136352
LF-GT-106 Series: 207 | Shaft: 1-3/8 in | Variant: Complete unit | Part no.: 136353
LF-GT-107 Series: 207 | Shaft: 1-7/16 in | Variant: Complete unit | Part no.: 136354
