• DODGE Grip Tight GT Top Angle Take-Up (1-15/16-2-15/16 in)
1 1

DODGE Grip Tight GT Top Angle Take-Up (1-15/16-2-15/16 in)

DODGE Grip Tight GT Top Angle Take-Up (1-15/16-2-15/16 in)

DODGE Grip Tight mounted ball bearings use a patented pull/push adapter for shaft-ready, damage-free mounting and dismounting.

Key features

  • Patented pull/push adapter with built-in bearing puller
  • Full 360° concentric shaft contact reduces vibration and fretting
  • Accommodates commercial grade and some undersize shafting
  • Case-carburized inner ring and grade 10 balls
  • Housing assembly and adapter can be purchased separately
  • Fits standard DODGE ball bearing housings

Specifications

Brand DODGE
Product line Grip Tight
Housing style Top angle take-up
Housing material cast iron
Locking Grip Tight adapter mount
Shaft range 1-15/16-2-15/16 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 5-49
TP-GT-115 Series: 210 | Shaft: 1-15/16 in | Variant: Complete unit | Part no.: 136152
TP-GT-10 Series: 210 | Shaft: 1-15/16 in, 2 in | Variant: Unit without adapter & nut | Part no.: 136231
TP-GT-200 Series: 210 | Shaft: 2 in | Variant: Complete unit | Part no.: 136153
TP-GTM-200 Series: 211 | Shaft: 2 in | Variant: Complete unit | Part no.: 136189
TP-GT-11 Series: 211 | Shaft: 2 in, 2-3/16 in, 2-1/4 in | Variant: Unit without adapter & nut | Part no.: 136232
TP-GT-203 Series: 211 | Shaft: 2-3/16 in | Variant: Complete unit | Part no.: 136154
TP-GT-204 Series: 211 | Shaft: 2-1/4 in | Variant: Complete unit | Part no.: 136155
TP-GTM-204 Series: 212 | Shaft: 2-1/4 in | Variant: Complete unit | Part no.: 136191
TP-GT-12 Series: 212 | Shaft: 2-1/4 in, 2-7/16 in | Variant: Unit without adapter & nut | Part no.: 136233
TP-GT-207 Series: 212 | Shaft: 2-7/16 in | Variant: Complete unit | Part no.: 136156
TP-GTM-208 Series: 214 | Shaft: 2-1/2 in | Variant: Complete unit | Part no.: 136193
TP-GT-14 Series: 214 | Shaft: 2-1/2 in, 2-11/16 in | Variant: Unit without adapter & nut | Part no.: 136234
TP-GT-211 Series: 214 | Shaft: 2-11/16 in | Variant: Complete unit | Part no.: 136157
TP-GT-215 Series: 215 | Shaft: 2-15/16 in | Variant: Complete unit | Part no.: 136158
TP-GT-15 Series: 215 | Shaft: 2-15/16 in | Variant: Unit without adapter & nut | Part no.: 136235
Mounted Bearing UnitsDODGE
15 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE Grip Tight GT Top Angle Take-Up (1-15/16-2-15/16 in)

Brand DODGE·Mounted Bearing Units

Available part numbers (15)

TP-GT-115, TP-GT-10, TP-GT-200, TP-GTM-200, TP-GT-11, TP-GT-203, TP-GT-204, TP-GTM-204, TP-GT-12, TP-GT-207 + 5 more — see full table ↓

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
TP-GT-115Series: 210 | Shaft: 1-15/16 in | Variant: Complete unit | Part no.: 136152
TP-GT-10Series: 210 | Shaft: 1-15/16 in, 2 in | Variant: Unit without adapter & nut | Part no.: 136231
TP-GT-200Series: 210 | Shaft: 2 in | Variant: Complete unit | Part no.: 136153
TP-GTM-200Series: 211 | Shaft: 2 in | Variant: Complete unit | Part no.: 136189
TP-GT-11Series: 211 | Shaft: 2 in, 2-3/16 in, 2-1/4 in | Variant: Unit without adapter & nut | Part no.: 136232
TP-GT-203Series: 211 | Shaft: 2-3/16 in | Variant: Complete unit | Part no.: 136154
TP-GT-204Series: 211 | Shaft: 2-1/4 in | Variant: Complete unit | Part no.: 136155
TP-GTM-204Series: 212 | Shaft: 2-1/4 in | Variant: Complete unit | Part no.: 136191
TP-GT-12Series: 212 | Shaft: 2-1/4 in, 2-7/16 in | Variant: Unit without adapter & nut | Part no.: 136233
TP-GT-207Series: 212 | Shaft: 2-7/16 in | Variant: Complete unit | Part no.: 136156
TP-GTM-208Series: 214 | Shaft: 2-1/2 in | Variant: Complete unit | Part no.: 136193
TP-GT-14Series: 214 | Shaft: 2-1/2 in, 2-11/16 in | Variant: Unit without adapter & nut | Part no.: 136234
TP-GT-211Series: 214 | Shaft: 2-11/16 in | Variant: Complete unit | Part no.: 136157
TP-GT-215Series: 215 | Shaft: 2-15/16 in | Variant: Complete unit | Part no.: 136158
TP-GT-15Series: 215 | Shaft: 2-15/16 in | Variant: Unit without adapter & nut | Part no.: 136235
