DODGE Grip Tight GTM Medium Duty 2-Bolt Flange

DODGE Grip Tight GTM Medium Duty 2-Bolt Flange

DODGE Grip Tight mounted ball bearings use a patented pull/push adapter for shaft-ready, damage-free mounting and dismounting.

Key features

  • Patented pull/push adapter with built-in bearing puller
  • Full 360° concentric shaft contact reduces vibration and fretting
  • Accommodates commercial grade and some undersize shafting
  • Case-carburized inner ring and grade 10 balls
  • Housing assembly and adapter can be purchased separately
  • Fits standard DODGE ball bearing housings

Specifications

Brand DODGE
Product line Grip Tight
Housing style 2-bolt flange
Housing material cast iron
Locking Grip Tight adapter mount
Shaft range 25-55 mm, 3/4-2-1/4 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 5-25
F2B-GTM-012 Series: 205 | Shaft: 3/4 in | Variant: Complete unit | Part no.: 129369
F2B-GTM-25M Series: 206 | Shaft: 25 mm | Variant: Complete unit | Part no.: 136268
F2B-GTM-100 Series: 206 | Shaft: 1 in | Variant: Complete unit | Part no.: 129330
F2B-GTM-30M Series: 207 | Shaft: 30 mm | Variant: Complete unit | Part no.: 136269
F2B-GTM-103 Series: 207 | Shaft: 1-3/16 in | Variant: Complete unit | Part no.: 129331
F2B-GTM-35M Series: 208 | Shaft: 35 mm | Variant: Complete unit | Part no.: 136270
F2B-GTM-107 Series: 208 | Shaft: 1-7/16 in | Variant: Complete unit | Part no.: 129332
F2B-GTM-40M Series: 209 | Shaft: 40 mm | Variant: Complete unit | Part no.: 136271
F2B-GTM-108 Series: 209 | Shaft: 1-1/2 in | Variant: Complete unit | Part no.: 129333
F2B-GTM-405M Series: 210 | Shaft: 45 mm | Variant: Complete unit | Part no.: 136272
F2B-GTM-111 Series: 210 | Shaft: 1-11/16 in | Variant: Complete unit | Part no.: 129334
F2B-GTM-112 Series: 210 | Shaft: 1-3/4 in | Variant: Complete unit | Part no.: 129335
F2B-GTM-50M Series: 211 | Shaft: 50 mm | Variant: Complete unit | Part no.: 136273
F2B-GTM-115 Series: 211 | Shaft: 1-15/16 in | Variant: Complete unit | Part no.: 129336
F2B-GTM-55M Series: 212 | Shaft: 55 mm | Variant: Complete unit | Part no.: 136274
F2B-GTM-203 Series: 212 | Shaft: 2-3/16 in | Variant: Complete unit | Part no.: Assembled to order
Mounted Bearing UnitsDODGE
16 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE Grip Tight GTM Medium Duty 2-Bolt Flange

Brand DODGE·Mounted Bearing Units

Available part numbers (16)

F2B-GTM-012, F2B-GTM-25M, F2B-GTM-100, F2B-GTM-30M, F2B-GTM-103, F2B-GTM-35M, F2B-GTM-107, F2B-GTM-40M, F2B-GTM-108, F2B-GTM-405M + 6 more — see full table ↓

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
F2B-GTM-012Series: 205 | Shaft: 3/4 in | Variant: Complete unit | Part no.: 129369
F2B-GTM-25MSeries: 206 | Shaft: 25 mm | Variant: Complete unit | Part no.: 136268
F2B-GTM-100Series: 206 | Shaft: 1 in | Variant: Complete unit | Part no.: 129330
F2B-GTM-30MSeries: 207 | Shaft: 30 mm | Variant: Complete unit | Part no.: 136269
F2B-GTM-103Series: 207 | Shaft: 1-3/16 in | Variant: Complete unit | Part no.: 129331
F2B-GTM-35MSeries: 208 | Shaft: 35 mm | Variant: Complete unit | Part no.: 136270
F2B-GTM-107Series: 208 | Shaft: 1-7/16 in | Variant: Complete unit | Part no.: 129332
F2B-GTM-40MSeries: 209 | Shaft: 40 mm | Variant: Complete unit | Part no.: 136271
F2B-GTM-108Series: 209 | Shaft: 1-1/2 in | Variant: Complete unit | Part no.: 129333
F2B-GTM-405MSeries: 210 | Shaft: 45 mm | Variant: Complete unit | Part no.: 136272
F2B-GTM-111Series: 210 | Shaft: 1-11/16 in | Variant: Complete unit | Part no.: 129334
F2B-GTM-112Series: 210 | Shaft: 1-3/4 in | Variant: Complete unit | Part no.: 129335
F2B-GTM-50MSeries: 211 | Shaft: 50 mm | Variant: Complete unit | Part no.: 136273
F2B-GTM-115Series: 211 | Shaft: 1-15/16 in | Variant: Complete unit | Part no.: 129336
F2B-GTM-55MSeries: 212 | Shaft: 55 mm | Variant: Complete unit | Part no.: 136274
F2B-GTM-203Series: 212 | Shaft: 2-3/16 in | Variant: Complete unit | Part no.: Assembled to order
