• DODGE Grip Tight GTM Medium Duty 4-Bolt Flange
1 1

DODGE Grip Tight GTM Medium Duty 4-Bolt Flange

DODGE Grip Tight GTM Medium Duty 4-Bolt Flange

DODGE Grip Tight mounted ball bearings use a patented pull/push adapter for shaft-ready, damage-free mounting and dismounting.

Key features

  • Patented pull/push adapter with built-in bearing puller
  • Full 360° concentric shaft contact reduces vibration and fretting
  • Accommodates commercial grade and some undersize shafting
  • Case-carburized inner ring and grade 10 balls
  • Housing assembly and adapter can be purchased separately
  • Fits standard DODGE ball bearing housings

Specifications

Brand DODGE
Product line Grip Tight
Housing style 4-bolt flange
Housing material cast iron
Locking Grip Tight adapter mount
Shaft range 25-85 mm, 3/4-3-1/2 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 5-33
F4B-GTM-012 Series: 205 | Shaft: 3/4 in | Variant: Complete unit | Part no.: 129679
F4B-GTM-25M Series: 206 | Shaft: 25 mm | Variant: Complete unit | Part no.: 136275
F4B-GTM-100 Series: 206 | Shaft: 1 in | Variant: Complete unit | Part no.: 129680
F4B-GTM-30M Series: 207 | Shaft: 30 mm | Variant: Complete unit | Part no.: 136276
F4B-GTM-103 Series: 207 | Shaft: 1-3/16 in | Variant: Complete unit | Part no.: 129681
F4B-GTM-35M Series: 208 | Shaft: 35 mm | Variant: Complete unit | Part no.: 136277
F4B-GTM-107 Series: 208 | Shaft: 1-7/16 in | Variant: Complete unit | Part no.: 129682
F4B-GTM-40M Series: 209 | Shaft: 40 mm | Variant: Complete unit | Part no.: 136278
F4B-GTM-108 Series: 209 | Shaft: 1-1/2 in | Variant: Complete unit | Part no.: 129683
F4B-GTM-45M Series: 210 | Shaft: 45 mm | Variant: Complete unit | Part no.: 136279
F4B-GTM-111 Series: 210 | Shaft: 1-11/16 in | Variant: Complete unit | Part no.: 129684
F4B-GTM-112 Series: 210 | Shaft: 1-3/4 in | Variant: Complete unit | Part no.: 129685
F4B-GTM-50M Series: 211 | Shaft: 50 mm | Variant: Complete unit | Part no.: 136280
F4B-GTM-115 Series: 211 | Shaft: 1-15/16 in | Variant: Complete unit | Part no.: 129686
F4B-GTM-55M Series: 212 | Shaft: 55 mm | Variant: Complete unit | Part no.: 136281
F4B-GTM-203 Series: 212 | Shaft: 2-3/16 in | Variant: Complete unit | Part no.: 129688
F4B-GTM-65M Series: 214 | Shaft: 65 mm | Variant: Complete unit | Part no.: 136282
F4B-GTM-207 Series: 214 | Shaft: 2-7/16 in | Variant: Complete unit | Part no.: 129690
F4B-GTM-70M Series: 215 | Shaft: 70 mm | Variant: Complete unit | Part no.: 136283
F4B-GTM-211 Series: 215 | Shaft: 2-11/16 in | Variant: Complete unit | Part no.: 129692
F4B-GTM-75M Series: 216 | Shaft: 75 mm | Variant: Complete unit | Part no.: 136284
F4B-GT-16 Series: 216 | Shaft: 75 mm, 2-15/16 in, 3 in | Variant: Unit without adapter & nut | Part no.: 129486
F4B-GTM-215 Series: 216 | Shaft: 2-15/16 in | Variant: Complete unit | Part no.: 129693
F4B-GTM-300 Series: 216 | Shaft: 3 in | Variant: Complete unit | Part no.: 129694
F4B-GTM-85M Series: 218 | Shaft: 85 mm | Variant: Complete unit | Part no.: 136285
F4B-GT-18 Series: 218 | Shaft: 85 mm, 3-7/16 in, 3-1/2 in | Variant: Unit without adapter & nut | Part no.: 129487
F4B-GTM-307 Series: 218 | Shaft: 3-7/16 in | Variant: Complete unit | Part no.: 129695
F4B-GTM-308 Series: 218 | Shaft: 3-1/2 in | Variant: Complete unit | Part no.: 129696
Mounted Bearing UnitsDODGE
28 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE Grip Tight GTM Medium Duty 4-Bolt Flange

Brand DODGE·Mounted Bearing Units

Available part numbers (28)

F4B-GTM-012, F4B-GTM-25M, F4B-GTM-100, F4B-GTM-30M, F4B-GTM-103, F4B-GTM-35M, F4B-GTM-107, F4B-GTM-40M, F4B-GTM-108, F4B-GTM-45M + 18 more — see full table ↓

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
F4B-GTM-012Series: 205 | Shaft: 3/4 in | Variant: Complete unit | Part no.: 129679
F4B-GTM-25MSeries: 206 | Shaft: 25 mm | Variant: Complete unit | Part no.: 136275
F4B-GTM-100Series: 206 | Shaft: 1 in | Variant: Complete unit | Part no.: 129680
F4B-GTM-30MSeries: 207 | Shaft: 30 mm | Variant: Complete unit | Part no.: 136276
F4B-GTM-103Series: 207 | Shaft: 1-3/16 in | Variant: Complete unit | Part no.: 129681
F4B-GTM-35MSeries: 208 | Shaft: 35 mm | Variant: Complete unit | Part no.: 136277
F4B-GTM-107Series: 208 | Shaft: 1-7/16 in | Variant: Complete unit | Part no.: 129682
F4B-GTM-40MSeries: 209 | Shaft: 40 mm | Variant: Complete unit | Part no.: 136278
F4B-GTM-108Series: 209 | Shaft: 1-1/2 in | Variant: Complete unit | Part no.: 129683
F4B-GTM-45MSeries: 210 | Shaft: 45 mm | Variant: Complete unit | Part no.: 136279
F4B-GTM-111Series: 210 | Shaft: 1-11/16 in | Variant: Complete unit | Part no.: 129684
F4B-GTM-112Series: 210 | Shaft: 1-3/4 in | Variant: Complete unit | Part no.: 129685
F4B-GTM-50MSeries: 211 | Shaft: 50 mm | Variant: Complete unit | Part no.: 136280
F4B-GTM-115Series: 211 | Shaft: 1-15/16 in | Variant: Complete unit | Part no.: 129686
F4B-GTM-55MSeries: 212 | Shaft: 55 mm | Variant: Complete unit | Part no.: 136281
F4B-GTM-203Series: 212 | Shaft: 2-3/16 in | Variant: Complete unit | Part no.: 129688
F4B-GTM-65MSeries: 214 | Shaft: 65 mm | Variant: Complete unit | Part no.: 136282
F4B-GTM-207Series: 214 | Shaft: 2-7/16 in | Variant: Complete unit | Part no.: 129690
F4B-GTM-70MSeries: 215 | Shaft: 70 mm | Variant: Complete unit | Part no.: 136283
F4B-GTM-211Series: 215 | Shaft: 2-11/16 in | Variant: Complete unit | Part no.: 129692
F4B-GTM-75MSeries: 216 | Shaft: 75 mm | Variant: Complete unit | Part no.: 136284
F4B-GT-16Series: 216 | Shaft: 75 mm, 2-15/16 in, 3 in | Variant: Unit without adapter & nut | Part no.: 129486
F4B-GTM-215Series: 216 | Shaft: 2-15/16 in | Variant: Complete unit | Part no.: 129693
F4B-GTM-300Series: 216 | Shaft: 3 in | Variant: Complete unit | Part no.: 129694
F4B-GTM-85MSeries: 218 | Shaft: 85 mm | Variant: Complete unit | Part no.: 136285
F4B-GT-18Series: 218 | Shaft: 85 mm, 3-7/16 in, 3-1/2 in | Variant: Unit without adapter & nut | Part no.: 129487
F4B-GTM-307Series: 218 | Shaft: 3-7/16 in | Variant: Complete unit | Part no.: 129695
F4B-GTM-308Series: 218 | Shaft: 3-1/2 in | Variant: Complete unit | Part no.: 129696
