DODGE ISN Plummer Block with Labyrinth Seals

DODGE ISN Plummer Block with Labyrinth Seals

DODGE ISN plummer blocks with labyrinth clearance seals for high speed or high temperature duty, 30 to 140 mm, fixed (FS) or expansion (LS).

Key features

  • Patented adapter mounting system for quick installation and removal
  • Clearance setting without feeler gauges
  • Full shaft contact reduces or eliminates fretting corrosion
  • 22200 series spherical roller bearing with steel cage and guide ring
  • Dimensionally interchangeable with SN family housings
  • 2-bolt housings cast iron; 4-bolt housings ductile iron

Specifications

Brand DODGE
Product line ISN plummer blocks
Bearing type Spherical roller, adapter mounted
Housing 2-bolt cast iron / 4-bolt ductile iron
Units Shaft in mm or inch as listed
Seal Labyrinth clearance seal (S)
Max. temperature 204 °C
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 6-11
P2B507-ISN-030MFS Series: 507 | Shaft: 30 mm | Type: Fixed (non-expansion) | Part no.: 071034
P2B507-ISN-030MLS Series: 507 | Shaft: 30 mm | Type: Expansion | Part no.: 071051
P2B508-ISN-035MFS Series: 508 | Shaft: 35 mm | Type: Fixed (non-expansion) | Part no.: 071035
P2B508-ISN-035MLS Series: 508 | Shaft: 35 mm | Type: Expansion | Part no.: 071052
P2B509-ISN-040MFS Series: 509 | Shaft: 40 mm | Type: Fixed (non-expansion) | Part no.: 071036
P2B509-ISN-040MLS Series: 509 | Shaft: 40 mm | Type: Expansion | Part no.: 070053
P2B509-ISN-108 FS Series: 509 | Shaft: 1-1/2 in | Type: Fixed (non-expansion) | Part no.: 075154
P2B510-ISN-045MFS Series: 510 | Shaft: 45 mm | Type: Fixed (non-expansion) | Part no.: 071037
P2B510-ISN-045MLS Series: 510 | Shaft: 45 mm | Type: Expansion | Part no.: 071054
P2B511-ISN-050MFS Series: 511 | Shaft: 50 mm | Type: Fixed (non-expansion) | Part no.: 071038
P2B511-ISN-050MLS Series: 511 | Shaft: 50 mm | Type: Expansion | Part no.: 071055
P2B512-ISN-055MFS Series: 512 | Shaft: 55 mm | Type: Fixed (non-expansion) | Part no.: 071039
P2B512-ISN-055MLS Series: 512 | Shaft: 55 mm | Type: Expansion | Part no.: 071056
P2B513-ISN-060MFS Series: 513 | Shaft: 60 mm | Type: Fixed (non-expansion) | Part no.: 071040
P2B513-ISN-060MLS Series: 513 | Shaft: 60 mm | Type: Expansion | Part no.: 071057
P2B513-ISN-203 FS Series: 513 | Shaft: 2-3/16 in | Type: Fixed (non-expansion) | Part no.: 077481
P2B513-ISN-208-LS Series: 513 | Shaft: 2-1/2 in | Type: Expansion | Part no.: 076670
P2B515-ISN-065MFS Series: 515 | Shaft: 65 mm | Type: Fixed (non-expansion) | Part no.: 071041
P2B515-ISN-065MLS Series: 515 | Shaft: 65 mm | Type: Expansion | Part no.: 071058
P2B515-ISN-208 FS Series: 515 | Shaft: 2-1/2 in | Type: Fixed (non-expansion) | Part no.: 074989
P2B516-ISN-070MFS Series: 516 | Shaft: 70 mm | Type: Fixed (non-expansion) | Part no.: 071042
P2B516-ISN-070MLS Series: 516 | Shaft: 70 mm | Type: Expansion | Part no.: 071059
P2B517-ISN-075MFS Series: 517 | Shaft: 75 mm | Type: Fixed (non-expansion) | Part no.: 071043
P2B517-ISN-075MLS Series: 517 | Shaft: 75 mm | Type: Expansion | Part no.: 071060
P2B518-ISN-080MFS Series: 518 | Shaft: 80 mm | Type: Fixed (non-expansion) | Part no.: 071044
P2B518-ISN-080MLS Series: 518 | Shaft: 80 mm | Type: Expansion | Part no.: 071061
P2B519-ISN-085MFS Series: 519 | Shaft: 85 mm | Type: Fixed (non-expansion) | Part no.: 071045
P2B519-ISN-085MLS Series: 519 | Shaft: 85 mm | Type: Expansion | Part no.: 071062
P2B520-ISN-090MFS Series: 520 | Shaft: 90 mm | Type: Fixed (non-expansion) | Part no.: 071046
P2B520-ISN-090MLS Series: 520 | Shaft: 90 mm | Type: Expansion | Part no.: 071063
P2B522-ISN-100MFS Series: 522 | Shaft: 100 mm | Type: Fixed (non-expansion) | Part no.: 071047
P2B522-ISN-100MLS Series: 522 | Shaft: 100 mm | Type: Expansion | Part no.: 071064
P2B524-ISN-110MFS Series: 524 | Shaft: 110 mm | Type: Fixed (non-expansion) | Part no.: 071048
P2B524-ISN-110MLS Series: 524 | Shaft: 110 mm | Type: Expansion | Part no.: 071065
P2B526-ISN-115MFS Series: 526 | Shaft: 115 mm | Type: Fixed (non-expansion) | Part no.: 071049
P2B526-ISN-115MLS Series: 526 | Shaft: 115 mm | Type: Expansion | Part no.: 071066
P2B528-ISN-125MFS Series: 528 | Shaft: 125 mm | Type: Fixed (non-expansion) | Part no.: 071050
P2B528-ISN-125MLS Series: 528 | Shaft: 125 mm | Type: Expansion | Part no.: 071067
P2B530-ISN-135MFS Series: 530 | Shaft: 135 mm | Type: Fixed (non-expansion) | Part no.: 071104
P2B530-ISN-135MLS Series: 530 | Shaft: 135 mm | Type: Expansion | Part no.: 071105
P2B532-ISN-140MFS Series: 532 | Shaft: 140 mm | Type: Fixed (non-expansion) | Part no.: 071108
P2B532-ISN-140MLS Series: 532 | Shaft: 140 mm | Type: Expansion | Part no.: 071109
