DODGE ISN Plummer Block with Trident Seals

DODGE ISN Plummer Block with Trident Seals

DODGE ISN shaft-ready plummer blocks with Trident triple-lip rubbing seals, supplied as fixed (FR) or expansion (LR) units with adapter-mounted spherical roller bearings.

Key features

  • Patented adapter mounting system for quick installation and removal
  • Clearance setting without feeler gauges
  • Full shaft contact reduces or eliminates fretting corrosion
  • 22200 series spherical roller bearing with steel cage and guide ring
  • Dimensionally interchangeable with SN family housings
  • 2-bolt housings cast iron; 4-bolt housings ductile iron

Specifications

Brand DODGE
Product line ISN plummer blocks
Bearing type Spherical roller, adapter mounted
Housing 2-bolt cast iron / 4-bolt ductile iron
Units Shaft in mm or inch as listed
Seal Trident triple-lip rubbing seal (R)
Max. temperature 107 °C
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 6-10
P2B507-ISN-030MFR Series: 507 | Shaft: 30 mm | Type: Fixed (non-expansion) | Part no.: 071000
P2B507-ISN-030MLR Series: 507 | Shaft: 30 mm | Type: Expansion | Part no.: 071017
P2B507-ISN-102 FR Series: 507 | Shaft: 1-1/8 in | Type: Fixed (non-expansion) | Part no.: 747900
P2B507-ISN-102 LR Series: 507 | Shaft: 1-1/8 in | Type: Expansion | Part no.: 747904
P2B507-ISN-103FR Series: 507 | Shaft: 1-3/16 in | Type: Fixed (non-expansion) | Part no.: 747901
P2B507-ISN-103 LR Series: 507 | Shaft: 1-3/16 in | Type: Expansion | Part no.: 747905
P2B508-ISN-035MFR Series: 508 | Shaft: 35 mm | Type: Fixed (non-expansion) | Part no.: 071001
P2B508-ISN-035MLR Series: 508 | Shaft: 35 mm | Type: Expansion | Part no.: 071018
P2B508-ISN-104 FR Series: 508 | Shaft: 1-1/4 in | Type: Fixed (non-expansion) | Part no.: 747908
P2B508-ISN-104 LR Series: 508 | Shaft: 1-1/4 in | Type: Expansion | Part no.: 747912
P2B508-ISN-106 FR Series: 508 | Shaft: 1-3/8 in | Type: Fixed (non-expansion) | Part no.: 747909
P2B508-ISN-106 LR Series: 508 | Shaft: 1-3/8 in | Type: Expansion | Part no.: 747913
P2B509-ISN-040MFR Series: 509 | Shaft: 40 mm | Type: Fixed (non-expansion) | Part no.: 071002
P2B509-ISN-040MLR Series: 509 | Shaft: 40 mm | Type: Expansion | Part no.: 071019
P2B509-ISN-107 FR Series: 509 | Shaft: 1-7/16 in | Type: Fixed (non-expansion) | Part no.: 747916
P2B509-ISN-107 LR Series: 509 | Shaft: 1-7/16 in | Type: Expansion | Part no.: 747920
P2B509-ISN-108 FR Series: 509 | Shaft: 1-1/2 in | Type: Fixed (non-expansion) | Part no.: 747917
P2B509-ISN-108 LR Series: 509 | Shaft: 1-1/2 in | Type: Expansion | Part no.: 747921
P2B510-ISN-045MFR Series: 510 | Shaft: 45 mm | Type: Fixed (non-expansion) | Part no.: 071003
P2B510-ISN-045MLR Series: 510 | Shaft: 45 mm | Type: Expansion | Part no.: 71020
P2B510-ISN-111 FR Series: 510 | Shaft: 1-11/16 in | Type: Fixed (non-expansion) | Part no.: 747924
P2B510-ISN-111 LR Series: 510 | Shaft: 1-11/16 in | Type: Expansion | Part no.: 747928
P2B510-ISN-112 FR Series: 510 | Shaft: 1-3/4 in | Type: Fixed (non-expansion) | Part no.: 747925
P2B510-ISN-112 LR Series: 510 | Shaft: 1-3/4 in | Type: Expansion | Part no.: 747929
P2B511-ISN-050MFR Series: 511 | Shaft: 50 mm | Type: Fixed (non-expansion) | Part no.: 071004
P2B511-ISN-050MLR Series: 511 | Shaft: 50 mm | Type: Expansion | Part no.: 071021
P2B511-ISN-115 FR Series: 511 | Shaft: 1-15/16 in | Type: Fixed (non-expansion) | Part no.: 747932
P2B511-ISN-115 LR Series: 511 | Shaft: 1-15/16 in | Type: Expansion | Part no.: 747936
P2B511-ISN-200 FR Series: 511 | Shaft: 2 in | Type: Fixed (non-expansion) | Part no.: 747933
P2B511-ISN-200 LR Series: 511 | Shaft: 2 in | Type: Expansion | Part no.: 747937
P2B512-ISN-055MFR Series: 512 | Shaft: 55 mm | Type: Fixed (non-expansion) | Part no.: 071005
P2B512-ISN-055MLR Series: 512 | Shaft: 55 mm | Type: Expansion | Part no.: 071022
P2B512-ISN-202 FR Series: 512 | Shaft: 2-1/8 in | Type: Fixed (non-expansion) | Part no.: 748012
P2B512-ISN-202 LR Series: 512 | Shaft: 2-1/8 in | Type: Expansion | Part no.: 748013
P2B513-ISN-060MFR Series: 513 | Shaft: 60 mm | Type: Fixed (non-expansion) | Part no.: 071006
P2B513-ISN-060MLR Series: 513 | Shaft: 60 mm | Type: Expansion | Part no.: 071023
P2B513-ISN-203 FR Series: 513 | Shaft: 2-3/16 in | Type: Fixed (non-expansion) | Part no.: 747940
P2B513-ISN-203 LR Series: 513 | Shaft: 2-3/16 in | Type: Expansion | Part no.: 747944
P2B513-ISN-204 FR Series: 513 | Shaft: 2-1/4 in | Type: Fixed (non-expansion) | Part no.: 747941
P2B513-ISN-204 LR Series: 513 | Shaft: 2-1/4 in | Type: Expansion | Part no.: 747945
P2B515-ISN-065MFR Series: 515 | Shaft: 65 mm | Type: Fixed (non-expansion) | Part no.: 071007
P2B515-ISN-065MLR Series: 515 | Shaft: 65 mm | Type: Expansion | Part no.: 71024
P2B515-ISN-207 FR Series: 515 | Shaft: 2-7/16 in | Type: Fixed (non-expansion) | Part no.: 747948
P2B515-ISN-207 LR Series: 515 | Shaft: 2-7/16 in | Type: Expansion | Part no.: 747952
P2B515-ISN-208 FR Series: 515 | Shaft: 2-1/2 in | Type: Fixed (non-expansion) | Part no.: 747949
P2B515-ISN-208 LR Series: 515 | Shaft: 2-1/2 in | Type: Expansion | Part no.: 747953
P2B516-ISN-070MFR Series: 516 | Shaft: 70 mm | Type: Fixed (non-expansion) | Part no.: 071008
P2B516-ISN-070MLR Series: 516 | Shaft: 70 mm | Type: Expansion | Part no.: 071025
P2B516-ISN-211 FR Series: 516 | Shaft: 2-11/16 in | Type: Fixed (non-expansion) | Part no.: 747956
P2B516-ISN-211 LR Series: 516 | Shaft: 2-11/16 in | Type: Expansion | Part no.: 747960
P2B516-ISN-212 FR Series: 516 | Shaft: 2-3/4 in | Type: Fixed (non-expansion) | Part no.: 747957
P2B516-ISN-212 LR Series: 516 | Shaft: 2-3/4 in | Type: Expansion | Part no.: 747961
P2B517-ISN-075MFR Series: 517 | Shaft: 75 mm | Type: Fixed (non-expansion) | Part no.: 071009
P2B517-ISN-075MLR Series: 517 | Shaft: 75 mm | Type: Expansion | Part no.: 71026
P2B517-ISN-215 FR Series: 517 | Shaft: 2-15/16 in | Type: Fixed (non-expansion) | Part no.: 747964
P2B517-ISN-215 LR Series: 517 | Shaft: 2-15/16 in | Type: Expansion | Part no.: 747968
P2B517-ISN-300 FR Series: 517 | Shaft: 3 in | Type: Fixed (non-expansion) | Part no.: 747965
P2B517-ISN-300 LR Series: 517 | Shaft: 3 in | Type: Expansion | Part no.: 747969
P2B518-ISN-080MFR Series: 518 | Shaft: 80 mm | Type: Fixed (non-expansion) | Part no.: 071010
P2B518-ISN-080MLR Series: 518 | Shaft: 80 mm | Type: Expansion | Part no.: 071027
P2B518-ISN-303 FR Series: 518 | Shaft: 3-3/16 in | Type: Fixed (non-expansion) | Part no.: 747972
P2B518-ISN-303 LR Series: 518 | Shaft: 3-3/16 in | Type: Expansion | Part no.: 747976
P2B518-ISN-304 FR Series: 518 | Shaft: 3-1/4 in | Type: Fixed (non-expansion) | Part no.: 747973
P2B518-ISN-304 LR Series: 518 | Shaft: 3-1/4 in | Type: Expansion | Part no.: 747977
P2B519-ISN-085MFR Series: 519 | Shaft: 85 mm | Type: Fixed (non-expansion) | Part no.: 071011
P2B519-ISN-085MLR Series: 519 | Shaft: 85 mm | Type: Expansion | Part no.: 071028
P2B520-ISN-090MFR Series: 520 | Shaft: 90 mm | Type: Fixed (non-expansion) | Part no.: 071012
P2B520-ISN-090MLR Series: 520 | Shaft: 90 mm | Type: Expansion | Part no.: 071029
P2B520-ISN-307 FR Series: 520 | Shaft: 3-7/16 in | Type: Fixed (non-expansion) | Part no.: 747980
P2B520-ISN-307 LR Series: 520 | Shaft: 3-7/16 in | Type: Expansion | Part no.: 747984
P2B520-ISN-308 FR Series: 520 | Shaft: 3-1/2 in | Type: Fixed (non-expansion) | Part no.: 747981
P2B520-ISN-308 LR Series: 520 | Shaft: 3-1/2 in | Type: Expansion | Part no.: 747985
P2B522-ISN-100MFR Series: 522 | Shaft: 100 mm | Type: Fixed (non-expansion) | Part no.: 071013
P2B522-ISN-100MLR Series: 522 | Shaft: 100 mm | Type: Expansion | Part no.: 071030
P2B522-ISN-315 FR Series: 522 | Shaft: 3-15/16 in | Type: Fixed (non-expansion) | Part no.: 747988
P2B522-ISN-315 LR Series: 522 | Shaft: 3-15/16 in | Type: Expansion | Part no.: 747992
P2B522-ISN-400 FR Series: 522 | Shaft: 4 in | Type: Fixed (non-expansion) | Part no.: 747989
P2B522-ISN-400 LR Series: 522 | Shaft: 4 in | Type: Expansion | Part no.: 747993
P2B524-ISN-110MFR Series: 524 | Shaft: 110 mm | Type: Fixed (non-expansion) | Part no.: 071014
P2B524-ISN-110MLR Series: 524 | Shaft: 110 mm | Type: Expansion | Part no.: 071031
P2B526-ISN-115MFR Series: 526 | Shaft: 115 mm | Type: Fixed (non-expansion) | Part no.: 071015
P2B526-ISN-115MLR Series: 526 | Shaft: 115 mm | Type: Expansion | Part no.: 071032
P2B526-ISN-407 FR Series: 526 | Shaft: 4-7/16 in | Type: Fixed (non-expansion) | Part no.: 747996
P2B526-ISN-407 LR Series: 526 | Shaft: 4-7/16 in | Type: Expansion | Part no.: 748000
P2B526-ISN-408 FR Series: 526 | Shaft: 4-1/2 in | Type: Fixed (non-expansion) | Part no.: 747997
P2B526-ISN-408 LR Series: 526 | Shaft: 4-1/2 in | Type: Expansion | Part no.: 748001
P2B528-ISN-125MFR Series: 528 | Shaft: 125 mm | Type: Fixed (non-expansion) | Part no.: 071016
P2B528-ISN-125MLR Series: 528 | Shaft: 125 mm | Type: Expansion | Part no.: 071033
P2B528-ISN-415 FR Series: 528 | Shaft: 4-15/16 in | Type: Fixed (non-expansion) | Part no.: 748004
P2B528-ISN-415 LR Series: 528 | Shaft: 4-15/16 in | Type: Expansion | Part no.: 748008
P2B528-ISN-500 FR Series: 528 | Shaft: 5 in | Type: Fixed (non-expansion) | Part no.: 748005
P2B528-ISN-500 LR Series: 528 | Shaft: 5 in | Type: Expansion | Part no.: 748009
P2B530-ISN-135MFR Series: 530 | Shaft: 135 mm | Type: Fixed (non-expansion) | Part no.: 071102
P2B530-ISN-135MLR Series: 530 | Shaft: 135 mm | Type: Expansion | Part no.: 071103
P2B532-ISN-140MFR Series: 532 | Shaft: 140 mm | Type: Fixed (non-expansion) | Part no.: 071106
P2B532-ISN-140MLR Series: 532 | Shaft: 140 mm | Type: Expansion | Part no.: 071107
P4B534-ISN-150MFR Series: 534 | Shaft: 150 mm | Type: Fixed (non-expansion) | Part no.: 078822
P4B534-ISN-150MLR Series: 534 | Shaft: 150 mm | Type: Expansion | Part no.: 078823
P4B536-ISN-160MFR Series: 536 | Shaft: 160 mm | Type: Fixed (non-expansion) | Part no.: 078824
P4B536-ISN-160MLR Series: 536 | Shaft: 160 mm | Type: Expansion | Part no.: 078825
P4B538-ISN-170MFR Series: 538 | Shaft: 170 mm | Type: Fixed (non-expansion) | Part no.: 078826
P4B538-ISN-170MLR Series: 538 | Shaft: 170 mm | Type: Expansion | Part no.: 078827
Mounted Bearing UnitsDODGE
102 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE ISN Plummer Block with Trident Seals

Brand DODGE·Mounted Bearing Units

Available part numbers (102)

P2B507-ISN-030MFR, P2B507-ISN-030MLR, P2B507-ISN-102 FR, P2B507-ISN-102 LR, P2B507-ISN-103FR, P2B507-ISN-103 LR, P2B508-ISN-035MFR, P2B508-ISN-035MLR, P2B508-ISN-104 FR, P2B508-ISN-104 LR + 92 more — see full table ↓

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
