DODGE SC Set Screw 2-Bolt Piloted Flange (20-50 mm, 1/2-2 in)

DODGE SC Set Screw 2-Bolt Piloted Flange (20-50 mm, 1/2-2 in)

DODGE SC/SCM/SL set screw mounted ball bearings cover light, normal and medium duty applications in a wide range of housing styles.

Key features

  • 65° set screw design balances locking force and inner ring stress
  • Light duty (SL), normal duty (SC) and medium duty (SCM) inner rings
  • DualGuard seal with rubberized flinger standard on SC/SCM
  • Fiberglass-reinforced nylon ball cage
  • Anti-rotation pin (SC, SCM) simplifies insert replacement
  • Options: no-lube sealed for life (NL), high temperature (HT)

Specifications

Brand DODGE
Product line SC/SCM/SL set screw
Housing style Piloted flange
Housing material cast iron
Locking Set screw (65°)
Shaft range 20-50 mm, 1/2-2 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 4-34
F2BZ-SC-20M Series: 204 | Shaft: 20 mm | Part no.: 130367
F2BZ-SC-008L Series: 204 | Shaft: 1/2 in | Part no.: Assembled to order
F2BZ-SC-010L Series: 204 | Shaft: 5/8 in | Part no.: 064775
F2BZ-SC-012 Series: 204 | Shaft: 3/4 in | Part no.: 062648
F2BZ-SC-25M Series: 205 | Shaft: 25 mm | Part no.: 130368
F2BZ-SC-014 Series: 205 | Shaft: 7/8 in | Part no.: 068915
F2BZ-SC-015 Series: 205 | Shaft: 15/16 in | Part no.: Assembled to order
F2BZ-SC-100 Series: 205 | Shaft: 1 in | Part no.: 056929
F2BZ-SC-30M Series: 206 | Shaft: 30 mm | Part no.: 130369
F2BZ-SC-102 Series: 206 | Shaft: 1-1/8 in | Part no.: 049926
F2BZ-SC-103 Series: 206 | Shaft: 1-3/16 in | Part no.: 064480
F2BZ-SC-104S Series: 206 | Shaft: 1-1/4 in | Part no.: 064361
F2BZ-SC-35M Series: 207 | Shaft: 35 mm | Part no.: 130370
F2BZ-SC-104 Series: 207 | Shaft: 1-1/4 in | Part no.: 064089
F2BZ-SC-106 Series: 207 | Shaft: 1-3/8 in | Part no.: 068937
F2BZ-SC-107 Series: 207 | Shaft: 1-7/16 in | Part no.: 065565
F2BZ-SC-40M Series: 208 | Shaft: 40 mm | Part no.: 130371
F2BZ-SC-108 Series: 208 | Shaft: 1-1/2 in | Part no.: 062686
F2BZ-SC-110 Series: 208 | Shaft: 1-5/8 in | Part no.: Assembled to order
F2BZ-SC-45M Series: 209 | Shaft: 45 mm | Part no.: 130372
F2BZ-SC-110L Series: 209 | Shaft: 1-5/8 in | Part no.: Assembled to order
F2BZ-SC-111 Series: 209 | Shaft: 1-11/16 in | Part no.: 068839
F2BZ-SC-112 Series: 209 | Shaft: 1-3/4 in | Part no.: Assembled to order
F2BZ-SC-50M Series: 210 | Shaft: 50 mm | Part no.: 130373
F2BZ-SC-115 Series: 210 | Shaft: 1-15/16 in | Part no.: 056845
F2BZ-SC-200 Series: 210 | Shaft: 2 in | Part no.: 074396
