DODGE SC Set Screw 3-Bolt Flanged Bracket (1/2-2 in)

DODGE SC Set Screw 3-Bolt Flanged Bracket (1/2-2 in)

DODGE SC/SCM/SL set screw mounted ball bearings cover light, normal and medium duty applications in a wide range of housing styles.

Key features

  • 65° set screw design balances locking force and inner ring stress
  • Light duty (SL), normal duty (SC) and medium duty (SCM) inner rings
  • DualGuard seal with rubberized flinger standard on SC/SCM
  • Fiberglass-reinforced nylon ball cage
  • Anti-rotation pin (SC, SCM) simplifies insert replacement
  • Options: no-lube sealed for life (NL), high temperature (HT)

Specifications

Brand DODGE
Product line SC/SCM/SL set screw
Housing style 3-bolt flange
Housing material cast iron
Locking Set screw (65°)
Shaft range 1/2-2 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 4-42
FB-SC-008 Series: 204 | Shaft: 1/2 in | Variant: Standard | Part no.: 124435
FB-SC-008-NL Series: 204 | Shaft: 1/2 in | Variant: Sealed for life (NL) | Part no.: 068720
FB-SC-010 Series: 204 | Shaft: 5/8 in | Variant: Standard | Part no.: 124436
FB-SC-010-NL Series: 204 | Shaft: 5/8 in | Variant: Sealed for life (NL) | Part no.: 059816
FB-SC-012 Series: 204 | Shaft: 3/4 in | Variant: Standard | Part no.: 124437
FB-SC-012-NL Series: 204 | Shaft: 3/4 in | Variant: Sealed for life (NL) | Part no.: 058544
FB-SC-014 Series: 205 | Shaft: 7/8 in | Variant: Standard | Part no.: 124438
FB-SC-014-NL Series: 205 | Shaft: 7/8 in | Variant: Sealed for life (NL) | Part no.: 056765
FB-SC-015 Series: 205 | Shaft: 15/16 in | Variant: Standard | Part no.: 124439
FB-SC-015-NL Series: 205 | Shaft: 15/16 in | Variant: Sealed for life (NL) | Part no.: Assembled to order
FB-SC-100 Series: 205 | Shaft: 1 in | Variant: Standard | Part no.: 124440
FB-SC-100-NL Series: 205 | Shaft: 1 in | Variant: Sealed for life (NL) | Part no.: 051774
FB-SC-101 Series: 206 | Shaft: 1-1/16 in | Variant: Standard | Part no.: 124441
FB-SC-101-NL Series: 206 | Shaft: 1-1/16 in | Variant: Sealed for life (NL) | Part no.: Assembled to order
FB-SC-102 Series: 206 | Shaft: 1-1/8 in | Variant: Standard | Part no.: 124442
FB-SC-102-NL Series: 206 | Shaft: 1-1/8 in | Variant: Sealed for life (NL) | Part no.: Assembled to order
FB-SC-103 Series: 206 | Shaft: 1-3/16 in | Variant: Standard | Part no.: 124443
FB-SC-103-NL Series: 206 | Shaft: 1-3/16 in | Variant: Sealed for life (NL) | Part no.: 049615
FB-SC-104S Series: 206 | Shaft: 1-1/4 in | Variant: Standard | Part no.: 124444
FB-SC-104S-NL Series: 206 | Shaft: 1-1/4 in | Variant: Sealed for life (NL) | Part no.: 124450
FB-SC-104 Series: 207 | Shaft: 1-1/4 in | Variant: Standard | Part no.: 124445
FB-SC-104-NL Series: 207 | Shaft: 1-1/4 in | Variant: Sealed for life (NL) | Part no.: 058545
FB-SC-105 Series: 207 | Shaft: 1-5/16 in | Variant: Standard | Part no.: 124446
FB-SC-105-NL Series: 207 | Shaft: 1-5/16 in | Variant: Sealed for life (NL) | Part no.: Assembled to order
FB-SC-106 Series: 207 | Shaft: 1-3/8 in | Variant: Standard | Part no.: 124447
FB-SC-106-NL Series: 207 | Shaft: 1-3/8 in | Variant: Sealed for life (NL) | Part no.: Assembled to order
FB-SC-107 Series: 207 | Shaft: 1-7/16 in | Variant: Standard | Part no.: 124448
FB-SC-107-NL Series: 207 | Shaft: 1-7/16 in | Variant: Sealed for life (NL) | Part no.: 052016
FB-SCM-111 Series: 210 | Shaft: 1-11/16 in | Variant: Standard | Part no.: 052906
FB-SCM-111-NL Series: 210 | Shaft: 1-11/16 in | Variant: Sealed for life (NL) | Part no.: 068840
FB-SC-115 Series: 210 | Shaft: 1-15/16 in | Variant: Standard | Part no.: 052094
FB-SC-115-NL Series: 210 | Shaft: 1-15/16 in | Variant: Sealed for life (NL) | Part no.: 073669
FB-SC-200 Series: 210 | Shaft: 2 in | Variant: Standard | Part no.: 058529
FB-SC-200-NL Series: 210 | Shaft: 2 in | Variant: Sealed for life (NL) | Part no.: 073139
Mounted Bearing UnitsDODGE
34 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE SC Set Screw 3-Bolt Flanged Bracket (1/2-2 in)

Brand DODGE·Mounted Bearing Units

Available part numbers (34)

FB-SC-008, FB-SC-008-NL, FB-SC-010, FB-SC-010-NL, FB-SC-012, FB-SC-012-NL, FB-SC-014, FB-SC-014-NL, FB-SC-015, FB-SC-015-NL + 24 more — see full table ↓

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
FB-SC-008Series: 204 | Shaft: 1/2 in | Variant: Standard | Part no.: 124435
FB-SC-008-NLSeries: 204 | Shaft: 1/2 in | Variant: Sealed for life (NL) | Part no.: 068720
FB-SC-010Series: 204 | Shaft: 5/8 in | Variant: Standard | Part no.: 124436
FB-SC-010-NLSeries: 204 | Shaft: 5/8 in | Variant: Sealed for life (NL) | Part no.: 059816
FB-SC-012Series: 204 | Shaft: 3/4 in | Variant: Standard | Part no.: 124437
FB-SC-012-NLSeries: 204 | Shaft: 3/4 in | Variant: Sealed for life (NL) | Part no.: 058544
FB-SC-014Series: 205 | Shaft: 7/8 in | Variant: Standard | Part no.: 124438
FB-SC-014-NLSeries: 205 | Shaft: 7/8 in | Variant: Sealed for life (NL) | Part no.: 056765
FB-SC-015Series: 205 | Shaft: 15/16 in | Variant: Standard | Part no.: 124439
FB-SC-015-NLSeries: 205 | Shaft: 15/16 in | Variant: Sealed for life (NL) | Part no.: Assembled to order
FB-SC-100Series: 205 | Shaft: 1 in | Variant: Standard | Part no.: 124440
FB-SC-100-NLSeries: 205 | Shaft: 1 in | Variant: Sealed for life (NL) | Part no.: 051774
FB-SC-101Series: 206 | Shaft: 1-1/16 in | Variant: Standard | Part no.: 124441
FB-SC-101-NLSeries: 206 | Shaft: 1-1/16 in | Variant: Sealed for life (NL) | Part no.: Assembled to order
FB-SC-102Series: 206 | Shaft: 1-1/8 in | Variant: Standard | Part no.: 124442
FB-SC-102-NLSeries: 206 | Shaft: 1-1/8 in | Variant: Sealed for life (NL) | Part no.: Assembled to order
FB-SC-103Series: 206 | Shaft: 1-3/16 in | Variant: Standard | Part no.: 124443
FB-SC-103-NLSeries: 206 | Shaft: 1-3/16 in | Variant: Sealed for life (NL) | Part no.: 049615
FB-SC-104SSeries: 206 | Shaft: 1-1/4 in | Variant: Standard | Part no.: 124444
FB-SC-104S-NLSeries: 206 | Shaft: 1-1/4 in | Variant: Sealed for life (NL) | Part no.: 124450
FB-SC-104Series: 207 | Shaft: 1-1/4 in | Variant: Standard | Part no.: 124445
FB-SC-104-NLSeries: 207 | Shaft: 1-1/4 in | Variant: Sealed for life (NL) | Part no.: 058545
FB-SC-105Series: 207 | Shaft: 1-5/16 in | Variant: Standard | Part no.: 124446
FB-SC-105-NLSeries: 207 | Shaft: 1-5/16 in | Variant: Sealed for life (NL) | Part no.: Assembled to order
FB-SC-106Series: 207 | Shaft: 1-3/8 in | Variant: Standard | Part no.: 124447
FB-SC-106-NLSeries: 207 | Shaft: 1-3/8 in | Variant: Sealed for life (NL) | Part no.: Assembled to order
FB-SC-107Series: 207 | Shaft: 1-7/16 in | Variant: Standard | Part no.: 124448
FB-SC-107-NLSeries: 207 | Shaft: 1-7/16 in | Variant: Sealed for life (NL) | Part no.: 052016
FB-SCM-111Series: 210 | Shaft: 1-11/16 in | Variant: Standard | Part no.: 052906
FB-SCM-111-NLSeries: 210 | Shaft: 1-11/16 in | Variant: Sealed for life (NL) | Part no.: 068840
FB-SC-115Series: 210 | Shaft: 1-15/16 in | Variant: Standard | Part no.: 052094
FB-SC-115-NLSeries: 210 | Shaft: 1-15/16 in | Variant: Sealed for life (NL) | Part no.: 073669
FB-SC-200Series: 210 | Shaft: 2 in | Variant: Standard | Part no.: 058529
FB-SC-200-NLSeries: 210 | Shaft: 2 in | Variant: Sealed for life (NL) | Part no.: 073139
