DODGE SR Fixing Rings for SNX/SDX Plummer Blocks

DODGE SR Fixing Rings for SNX/SDX Plummer Blocks

SR fixing (stabilizing) rings that locate the bearing in DODGE SNX and SDX plummer blocks for non-expansion arrangements.

Key features

  • Locate the bearing outer ring axially in the housing
  • Size designation = housing bore diameter x ring width
  • Quantity per housing listed in the tables
  • Used for fixed (non-expansion) bearing positions

Specifications

Brand DODGE
Product line SNX / SDX plummer blocks
Units mm
Housing material Cast iron (GG)
Selection By housing size per catalogue table
Ordering DODGE part number per code
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 6-29 to 6-43
SR 85x3.5 For housing: SNX 209 | Qty per housing: 2 | Part no.: 747105
SR 90x9 For housing: SNX 210 | Qty per housing: 2 | Part no.: 747108
SR 100x9.5 For housing: SNX 211 | Qty per housing: 2 | Part no.: 747111
SR 110x10 For housing: SNX 212 | Qty per housing: 2 | Part no.: 747115
SR 120x10 For housing: SNX 213 | Qty per housing: 2 | Part no.: 747118
SR 130x12.5 For housing: SNX 215 | Qty per housing: 2 | Part no.: 747121
SR 140x12.5 For housing: SNX 216 | Qty per housing: 2 | Part no.: 747123
SR 150x12.5 For housing: SNX 217 | Qty per housing: 2 | Part no.: 747125
SR 160x12.5 For housing: SNX 218 | Qty per housing: 2 | Part no.: 747128
SR 170x12.5 For housing: SNX 219 | Qty per housing: 2 | Part no.: 747130
SR 180x12 For housing: SNX 220 | Qty per housing: 2 | Part no.: 747132
SR 200x13.5 For housing: SNX 222 | Qty per housing: 2 | Part no.: 747137
SR 215x14 For housing: SNX 224 | Qty per housing: 2 | Part no.: 747141
SR 230x13 For housing: SNX 226 | Qty per housing: 2 | Part no.: 747143
SR 250x15 For housing: SNX 228 | Qty per housing: 2 | Part no.: 747146
SR 270x16.5 For housing: SNX 230 | Qty per housing: 2 | Part no.: 747149
SR 290x17 For housing: SNX 232 | Qty per housing: 2 | Part no.: 747152
SR 160x6.25 For housing: SNX 218 | Qty per housing: 2 | Part no.: 747189
SR 180x4.85 For housing: SNX 220 | Qty per housing: 2 | Part no.: 747190
SR 200x5.1 For housing: SNX 222 | Qty per housing: 2 | Part no.: 747191
SR 215x5 For housing: SNX 224 | Qty per housing: 2 | Part no.: 712225
SR 230x5 For housing: SNX 226 | Qty per housing: 2 | Part no.: 747192
SR 250x5 For housing: SNX 228 | Qty per housing: 2 | Part no.: 747193
SR 270x5 For housing: SNX 230 | Qty per housing: 2 | Part no.: 747194
SR 290x5 For housing: SNX 232 | Qty per housing: 2 | Part no.: 747195
SR 85x5.5 For housing: SNX 509 | Qty per housing: 2 | Part no.: 747177
SR 90x10.5 For housing: SNX 510 | Qty per housing: 2 | Part no.: 747178
SR 100x12 For housing: SNX 511 | Qty per housing: 2 | Part no.: 747179
SR 110x13 For housing: SNX 512 | Qty per housing: 2 | Part no.: 747180
SR 120x14 For housing: SNX 513 | Qty per housing: 2 | Part no.: 747181
SR 130x15.5 For housing: SNX 515 | Qty per housing: 2 | Part no.: 747182
SR 140x16 For housing: SNX 516 | Qty per housing: 2 | Part no.: 747183
SR 150x16.5 For housing: SNX 517 | Qty per housing: 2 | Part no.: 747184
SR 160x17.5 For housing: SNX 518 | Qty per housing: 2 | Part no.: 747185
SR 170x18 For housing: SNX 519 | Qty per housing: 2 | Part no.: 747186
SR 180x18 For housing: SNX 520 | Qty per housing: 2 | Part no.: 747187
SR 200x21 For housing: SNX 522 | Qty per housing: 2 | Part no.: 747188
SR 90X4 For housing: SNX 308 | Qty per housing: 2 | Part no.: 747107
SR 100X4 For housing: SNX 309 | Qty per housing: 2 | Part no.: 747110
SR 110X4 For housing: SNX 310 | Qty per housing: 2 | Part no.: 747114
SR 120X4 For housing: SNX 311 | Qty per housing: 2 | Part no.: 747117
SR 130X4 For housing: SNX 312 | Qty per housing: 2 | Part no.: 747120
SR 140X5 For housing: SNX 313 | Qty per housing: 2 | Part no.: 747122
SR 150X5 For housing: SNX 314 | Qty per housing: 2 | Part no.: 747124
SR 160X5 For housing: SNX 315 | Qty per housing: 2 | Part no.: 747126
SR 170X5 For housing: SNX 316 | Qty per housing: 2 | Part no.: 747129
SR 180X5 For housing: SNX 317 | Qty per housing: 2 | Part no.: 747131
SR 200X6.5 For housing: SNX 319 | Qty per housing: 2 | Part no.: 747135
SR 215X6.5 For housing: SNX 320 | Qty per housing: 2 | Part no.: 747139
SR 130X5 For housing: SNX 612 | Qty per housing: 2 | Part no.: 747120
SR 200X10 For housing: SNX 3026 | Qty per housing: 1 | Part no.: 747136
SR 210X10 For housing: SNX 3028 | Qty per housing: 1 | Part no.: 747138
SR 225X10 For housing: SNX 3030 | Qty per housing: 1 | Part no.: 747142
SR 240X10 For housing: SNX 3032 | Qty per housing: 1 | Part no.: 747145
SR 260X10 For housing: SNX 3034 | Qty per housing: 1 | Part no.: 747148
SR 280X10 For housing: SNX 3036 | Qty per housing: 1 | Part no.: 747150
SR 290X10 For housing: SNX 3038 | Qty per housing: 1 | Part no.: 747151
SR 310x20 For housing: SDX 3040 | Qty per housing: 2 | Part no.: 747155
SR 340x21 For housing: SDX 3044 | Qty per housing: 2 | Part no.: 747159
SR 360x24 For housing: SDX 3048 | Qty per housing: 2 | Part no.: 747161
SR 400x22 For housing: SDX 3052 | Qty per housing: 2 | Part no.: 747166
SR 420x30 For housing: SDX 3056 | Qty per housing: 2 | Part no.: 747167
SR 460x24 For housing: SDX 3060 | Qty per housing: 2 | Part no.: 747171
SR 480x30 For housing: SDX 3064 | Qty per housing: 2 | Part no.: 747172
SR 520x32 For housing: SDX 3068 | Qty per housing: 2 | Part no.: 747174
SR 300x10 For housing: SDX 3136 | Qty per housing: 2 | Part no.: 747154
SR 320x10 For housing: SDX 3138 | Qty per housing: 2 | Part no.: 747156
SR 340x10 For housing: SDX 3140 | Qty per housing: 2 | Part no.: 747157
SR 370x10 For housing: SDX 3144 | Qty per housing: 2 | Part no.: 747162
SR 400x10 For housing: SDX 3148 | Qty per housing: 2 | Part no.: 747164
SR 440x10 For housing: SDX 3152 | Qty per housing: 2 | Part no.: 747168
SR 460x10 For housing: SDX 3156 | Qty per housing: 2 | Part no.: 747170
SR 500x10 For housing: SDX 3160 | Qty per housing: 2 | Part no.: 747173
SR 540x10 For housing: SDX 3164 | Qty per housing: 2 | Part no.: 747175
