DODGE Solidlube GLT Sleeve Bearing Top Angle Take-Up (1-15/16-3 in)

DODGE Solidlube GLT Sleeve Bearing Top Angle Take-Up (1-15/16-3 in)

DODGE Solidlube sleeve bearings are self-lubricating, statically self-aligning bearings for extreme industrial applications.

Key features

  • Self-lubricating; no relubrication system required
  • Good in temperature extremes and inaccessible locations
  • Functions in vacuum and through dry cycles
  • Usable in many corrosive (chemical) media
  • Recommended for slow speeds and limited shaft movement

Specifications

Brand DODGE
Product line Solidlube
Housing style Top angle take-up
Housing material cast iron
Locking Set screw
Shaft range 1-15/16-3 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 7-24
TP-GLT7-115 Shaft: 1-15/16 in | Variant: Solidlube 700 | Part no.: 033739
TP-GLT10-115 Shaft: 1-15/16 in | Variant: Solidlube 1000 | Part no.: 033750
TP-GLT7-200 Shaft: 2 in | Variant: Solidlube 700 | Part no.: 033740
TP-GLT10-200 Shaft: 2 in | Variant: Solidlube 1000 | Part no.: 033751
TP-GLT7-203 Shaft: 2-3/16 in | Variant: Solidlube 700 | Part no.: 033741
TP-GLT10-203 Shaft: 2-3/16 in | Variant: Solidlube 1000 | Part no.: 033752
TP-GLT7-207 Shaft: 2-7/16 in | Variant: Solidlube 700 | Part no.: 033742
TP-GLT10-207 Shaft: 2-7/16 in | Variant: Solidlube 1000 | Part no.: 033753
TP-GLT7-208 Shaft: 2-1/2 in | Variant: Solidlube 700 | Part no.: 033743
TP-GLT10-208 Shaft: 2-1/2 in | Variant: Solidlube 1000 | Part no.: 033754
TP-GLT7-215 Shaft: 2-15/16 in | Variant: Solidlube 700 | Part no.: 033744
TP-GLT10-215 Shaft: 2-15/16 in | Variant: Solidlube 1000 | Part no.: 033755
TP-GLT7-300 Shaft: 3 in | Variant: Solidlube 700 | Part no.: 033745
TP-GLT10-300 Shaft: 3 in | Variant: Solidlube 1000 | Part no.: 033756
Mounted Bearing UnitsDODGE
14 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE Solidlube GLT Sleeve Bearing Top Angle Take-Up (1-15/16-3 in)

Brand DODGE·Mounted Bearing Units

Available part numbers (14)

TP-GLT7-115, TP-GLT10-115, TP-GLT7-200, TP-GLT10-200, TP-GLT7-203, TP-GLT10-203, TP-GLT7-207, TP-GLT10-207, TP-GLT7-208, TP-GLT10-208 + 4 more — see full table ↓

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
TP-GLT7-115Shaft: 1-15/16 in | Variant: Solidlube 700 | Part no.: 033739
TP-GLT10-115Shaft: 1-15/16 in | Variant: Solidlube 1000 | Part no.: 033750
TP-GLT7-200Shaft: 2 in | Variant: Solidlube 700 | Part no.: 033740
TP-GLT10-200Shaft: 2 in | Variant: Solidlube 1000 | Part no.: 033751
TP-GLT7-203Shaft: 2-3/16 in | Variant: Solidlube 700 | Part no.: 033741
TP-GLT10-203Shaft: 2-3/16 in | Variant: Solidlube 1000 | Part no.: 033752
TP-GLT7-207Shaft: 2-7/16 in | Variant: Solidlube 700 | Part no.: 033742
TP-GLT10-207Shaft: 2-7/16 in | Variant: Solidlube 1000 | Part no.: 033753
TP-GLT7-208Shaft: 2-1/2 in | Variant: Solidlube 700 | Part no.: 033743
TP-GLT10-208Shaft: 2-1/2 in | Variant: Solidlube 1000 | Part no.: 033754
TP-GLT7-215Shaft: 2-15/16 in | Variant: Solidlube 700 | Part no.: 033744
TP-GLT10-215Shaft: 2-15/16 in | Variant: Solidlube 1000 | Part no.: 033755
TP-GLT7-300Shaft: 3 in | Variant: Solidlube 700 | Part no.: 033745
TP-GLT10-300Shaft: 3 in | Variant: Solidlube 1000 | Part no.: 033756
