• DODGE Solidlube LT Sleeve Bearing 2-Bolt Flange (20-50 mm, 3/4-2 in)
1 1

DODGE Solidlube LT Sleeve Bearing 2-Bolt Flange (20-50 mm, 3/4-2 in)

DODGE Solidlube LT Sleeve Bearing 2-Bolt Flange (20-50 mm, 3/4-2 in)

DODGE Solidlube sleeve bearings are self-lubricating, statically self-aligning bearings for extreme industrial applications.

Key features

  • Self-lubricating; no relubrication system required
  • Good in temperature extremes and inaccessible locations
  • Functions in vacuum and through dry cycles
  • Usable in many corrosive (chemical) media
  • Recommended for slow speeds and limited shaft movement

Specifications

Brand DODGE
Product line Solidlube
Housing style 2-bolt flange
Housing material cast iron
Locking Set screw
Shaft range 20-50 mm, 3/4-2 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 7-16
F2B-LT7-20M Series: 204 | Shaft: 20 mm | Variant: Solidlube 700 | Part no.: 034260
F2B-LT10-20M Series: 204 | Shaft: 20 mm | Variant: Solidlube 1000 | Part no.: 034266
F2B-LT7-012 Series: 204 | Shaft: 3/4 in | Variant: Solidlube 700 | Part no.: 033085
F2B-LT10-012 Series: 204 | Shaft: 3/4 in | Variant: Solidlube 1000 | Part no.: 033185
F2B-LT7-25M Series: 205 | Shaft: 25 mm | Variant: Solidlube 700 | Part no.: 034261
F2B-LT10-25M Series: 205 | Shaft: 25 mm | Variant: Solidlube 1000 | Part no.: 034267
F2B-LT7-014 Series: 205 | Shaft: 7/8 in | Variant: Solidlube 700 | Part no.: 033086
F2B-LT10-014 Series: 205 | Shaft: 7/8 in | Variant: Solidlube 1000 | Part no.: 033186
F2B-LT7-015 Series: 205 | Shaft: 15/16 in | Variant: Solidlube 700 | Part no.: 033087
F2B-LT10-015 Series: 205 | Shaft: 15/16 in | Variant: Solidlube 1000 | Part no.: 033187
F2B-LT7-100 Series: 205 | Shaft: 1 in | Variant: Solidlube 700 | Part no.: 033088
F2B-LT10-100 Series: 205 | Shaft: 1 in | Variant: Solidlube 1000 | Part no.: 033188
F2B-LT7-30M Series: 206 | Shaft: 30 mm | Variant: Solidlube 700 | Part no.: 034262
F2B-LT10-30M Series: 206 | Shaft: 30 mm | Variant: Solidlube 1000 | Part no.: 034268
F2B-LT7-102 Series: 206 | Shaft: 1-1/8 in | Variant: Solidlube 700 | Part no.: 033089
F2B-LT10-102 Series: 206 | Shaft: 1-1/8 in | Variant: Solidlube 1000 | Part no.: 033189
F2B-LT7-103 Series: 206 | Shaft: 1-3/16 in | Variant: Solidlube 700 | Part no.: 033090
F2B-LT10-103 Series: 206 | Shaft: 1-3/16 in | Variant: Solidlube 1000 | Part no.: 033190
F2B-LT7-35M Series: 207 | Shaft: 35 mm | Variant: Solidlube 700 | Part no.: 034263
F2B-LT10-35M Series: 207 | Shaft: 35 mm | Variant: Solidlube 1000 | Part no.: 034269
F2B-LT7-104 Series: 207 | Shaft: 1-1/4 in | Variant: Solidlube 700 | Part no.: 033091
F2B-LT10-104 Series: 207 | Shaft: 1-1/4 in | Variant: Solidlube 1000 | Part no.: 033191
F2B-LT7-106 Series: 207 | Shaft: 1-3/8 in | Variant: Solidlube 700 | Part no.: 033092
F2B-LT10-106 Series: 207 | Shaft: 1-3/8 in | Variant: Solidlube 1000 | Part no.: 033192
F2B-LT7-107 Series: 207 | Shaft: 1-7/16 in | Variant: Solidlube 700 | Part no.: 033093
F2B-LT10-107 Series: 207 | Shaft: 1-7/16 in | Variant: Solidlube 1000 | Part no.: 033193
F2B-LT7-108 Series: 207 | Shaft: 1-1/2 in | Variant: Solidlube 700 | Part no.: 033094
F2B-LT7-40M Series: 209 | Shaft: 40 mm | Variant: Solidlube 700 | Part no.: 034218
F2B-LT10-40M Series: 209 | Shaft: 40 mm | Variant: Solidlube 1000 | Part no.: 034270
F2B-LT7-45M Series: 209 | Shaft: 45 mm | Variant: Solidlube 700 | Part no.: 034264
F2B-LT10-45M Series: 209 | Shaft: 45 mm | Variant: Solidlube 1000 | Part no.: 034271
F2B-LT7-111 Series: 209 | Shaft: 1-11/16 in | Variant: Solidlube 700 | Part no.: 033095
F2B-LT10-111 Series: 209 | Shaft: 1-11/16 in | Variant: Solidlube 1000 | Part no.: 033195
F2B-LT7-112 Series: 209 | Shaft: 1-3/4 in | Variant: Solidlube 700 | Part no.: 033096
F2B-LT10-112 Series: 209 | Shaft: 1-3/4 in | Variant: Solidlube 1000 | Part no.: 033196
F2B-LT7-50M Series: 210 | Shaft: 50 mm | Variant: Solidlube 700 | Part no.: 034265
F2B-LT10-50M Series: 210 | Shaft: 50 mm | Variant: Solidlube 1000 | Part no.: 034272
F2B-LT7-115 Series: 210 | Shaft: 1-15/16 in | Variant: Solidlube 700 | Part no.: 033097
F2B-LT10-115 Series: 210 | Shaft: 1-15/16 in | Variant: Solidlube 1000 | Part no.: 033197
F2B-LT7-200 Series: 210 | Shaft: 2 in | Variant: Solidlube 700 | Part no.: 033098
F2B-LT10-200 Series: 210 | Shaft: 2 in | Variant: Solidlube 1000 | Part no.: 033198
Mounted Bearing UnitsDODGE
41 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE Solidlube LT Sleeve Bearing 2-Bolt Flange (20-50 mm, 3/4-2 in)

Brand DODGE·Mounted Bearing Units

Available part numbers (41)

F2B-LT7-20M, F2B-LT10-20M, F2B-LT7-012, F2B-LT10-012, F2B-LT7-25M, F2B-LT10-25M, F2B-LT7-014, F2B-LT10-014, F2B-LT7-015, F2B-LT10-015 + 31 more — see full table ↓

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
F2B-LT7-20MSeries: 204 | Shaft: 20 mm | Variant: Solidlube 700 | Part no.: 034260
F2B-LT10-20MSeries: 204 | Shaft: 20 mm | Variant: Solidlube 1000 | Part no.: 034266
F2B-LT7-012Series: 204 | Shaft: 3/4 in | Variant: Solidlube 700 | Part no.: 033085
F2B-LT10-012Series: 204 | Shaft: 3/4 in | Variant: Solidlube 1000 | Part no.: 033185
F2B-LT7-25MSeries: 205 | Shaft: 25 mm | Variant: Solidlube 700 | Part no.: 034261
F2B-LT10-25MSeries: 205 | Shaft: 25 mm | Variant: Solidlube 1000 | Part no.: 034267
F2B-LT7-014Series: 205 | Shaft: 7/8 in | Variant: Solidlube 700 | Part no.: 033086
F2B-LT10-014Series: 205 | Shaft: 7/8 in | Variant: Solidlube 1000 | Part no.: 033186
F2B-LT7-015Series: 205 | Shaft: 15/16 in | Variant: Solidlube 700 | Part no.: 033087
F2B-LT10-015Series: 205 | Shaft: 15/16 in | Variant: Solidlube 1000 | Part no.: 033187
F2B-LT7-100Series: 205 | Shaft: 1 in | Variant: Solidlube 700 | Part no.: 033088
F2B-LT10-100Series: 205 | Shaft: 1 in | Variant: Solidlube 1000 | Part no.: 033188
F2B-LT7-30MSeries: 206 | Shaft: 30 mm | Variant: Solidlube 700 | Part no.: 034262
F2B-LT10-30MSeries: 206 | Shaft: 30 mm | Variant: Solidlube 1000 | Part no.: 034268
F2B-LT7-102Series: 206 | Shaft: 1-1/8 in | Variant: Solidlube 700 | Part no.: 033089
F2B-LT10-102Series: 206 | Shaft: 1-1/8 in | Variant: Solidlube 1000 | Part no.: 033189
F2B-LT7-103Series: 206 | Shaft: 1-3/16 in | Variant: Solidlube 700 | Part no.: 033090
F2B-LT10-103Series: 206 | Shaft: 1-3/16 in | Variant: Solidlube 1000 | Part no.: 033190
F2B-LT7-35MSeries: 207 | Shaft: 35 mm | Variant: Solidlube 700 | Part no.: 034263
F2B-LT10-35MSeries: 207 | Shaft: 35 mm | Variant: Solidlube 1000 | Part no.: 034269
F2B-LT7-104Series: 207 | Shaft: 1-1/4 in | Variant: Solidlube 700 | Part no.: 033091
F2B-LT10-104Series: 207 | Shaft: 1-1/4 in | Variant: Solidlube 1000 | Part no.: 033191
F2B-LT7-106Series: 207 | Shaft: 1-3/8 in | Variant: Solidlube 700 | Part no.: 033092
F2B-LT10-106Series: 207 | Shaft: 1-3/8 in | Variant: Solidlube 1000 | Part no.: 033192
F2B-LT7-107Series: 207 | Shaft: 1-7/16 in | Variant: Solidlube 700 | Part no.: 033093
F2B-LT10-107Series: 207 | Shaft: 1-7/16 in | Variant: Solidlube 1000 | Part no.: 033193
F2B-LT7-108Series: 207 | Shaft: 1-1/2 in | Variant: Solidlube 700 | Part no.: 033094
F2B-LT7-40MSeries: 209 | Shaft: 40 mm | Variant: Solidlube 700 | Part no.: 034218
F2B-LT10-40MSeries: 209 | Shaft: 40 mm | Variant: Solidlube 1000 | Part no.: 034270
F2B-LT7-45MSeries: 209 | Shaft: 45 mm | Variant: Solidlube 700 | Part no.: 034264
F2B-LT10-45MSeries: 209 | Shaft: 45 mm | Variant: Solidlube 1000 | Part no.: 034271
F2B-LT7-111Series: 209 | Shaft: 1-11/16 in | Variant: Solidlube 700 | Part no.: 033095
F2B-LT10-111Series: 209 | Shaft: 1-11/16 in | Variant: Solidlube 1000 | Part no.: 033195
F2B-LT7-112Series: 209 | Shaft: 1-3/4 in | Variant: Solidlube 700 | Part no.: 033096
F2B-LT10-112Series: 209 | Shaft: 1-3/4 in | Variant: Solidlube 1000 | Part no.: 033196
F2B-LT7-50MSeries: 210 | Shaft: 50 mm | Variant: Solidlube 700 | Part no.: 034265
F2B-LT10-50MSeries: 210 | Shaft: 50 mm | Variant: Solidlube 1000 | Part no.: 034272
F2B-LT7-115Series: 210 | Shaft: 1-15/16 in | Variant: Solidlube 700 | Part no.: 033097
F2B-LT10-115Series: 210 | Shaft: 1-15/16 in | Variant: Solidlube 1000 | Part no.: 033197
F2B-LT7-200Series: 210 | Shaft: 2 in | Variant: Solidlube 700 | Part no.: 033098
F2B-LT10-200Series: 210 | Shaft: 2 in | Variant: Solidlube 1000 | Part no.: 033198
