• DODGE Solidlube LT Sleeve Bearing Insert (20-75 mm, 3/4-3 in)
1 1

DODGE Solidlube LT Sleeve Bearing Insert (20-75 mm, 3/4-3 in)

DODGE Solidlube LT Sleeve Bearing Insert (20-75 mm, 3/4-3 in)

DODGE Solidlube sleeve bearings are self-lubricating, statically self-aligning bearings for extreme industrial applications.

Key features

  • Self-lubricating; no relubrication system required
  • Good in temperature extremes and inaccessible locations
  • Functions in vacuum and through dry cycles
  • Usable in many corrosive (chemical) media
  • Recommended for slow speeds and limited shaft movement

Specifications

Brand DODGE
Product line Solidlube
Housing style Bearing insert
Locking Set screw
Shaft range 20-75 mm, 3/4-3 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 7-26
INS-LT7-20M Series: 204 | Shaft: 20 mm | Variant: Solidlube 700 | Part no.: 034454
INS-LT10-20M Series: 204 | Shaft: 20 mm | Variant: Solidlube 1000 | Part no.: 034455
INS-LT7-012 Series: 204 | Shaft: 3/4 in | Variant: Solidlube 700 | Part no.: 033585
INS-LT10-012 Series: 204 | Shaft: 3/4 in | Variant: Solidlube 1000 | Part no.: 033610
INS-LT7-25M Series: 205 | Shaft: 25 mm | Variant: Solidlube 700 | Part no.: 034456
INS-LT10-25M Series: 205 | Shaft: 25 mm | Variant: Solidlube 1000 | Part no.: 034457
INS-LT7-014 Series: 205 | Shaft: 7/8 in | Variant: Solidlube 700 | Part no.: 033586
INS-LT10-014 Series: 205 | Shaft: 7/8 in | Variant: Solidlube 1000 | Part no.: 033611
INS-LT7-015 Series: 205 | Shaft: 15/16 in | Variant: Solidlube 700 | Part no.: 033587
INS-LT10-015 Series: 205 | Shaft: 15/16 in | Variant: Solidlube 1000 | Part no.: 033612
INS-LT7-100 Series: 205 | Shaft: 1 in | Variant: Solidlube 700 | Part no.: 033588
INS-LT10-100 Series: 205 | Shaft: 1 in | Variant: Solidlube 1000 | Part no.: 033613
INS-LT7-30M Series: 206 | Shaft: 30 mm | Variant: Solidlube 700 | Part no.: 034458
INS-LT10-30M Series: 206 | Shaft: 30 mm | Variant: Solidlube 1000 | Part no.: 034459
INS-LT7-102 Series: 206 | Shaft: 1-1/8 in | Variant: Solidlube 700 | Part no.: 033589
INS-LT10-102 Series: 206 | Shaft: 1-1/8 in | Variant: Solidlube 1000 | Part no.: 033614
INS-LT7-103 Series: 206 | Shaft: 1-3/16 in | Variant: Solidlube 700 | Part no.: 033590
INS-LT10-103 Series: 206 | Shaft: 1-3/16 in | Variant: Solidlube 1000 | Part no.: 033615
INS-LT7-35M Series: 207 | Shaft: 35 mm | Variant: Solidlube 700 | Part no.: 034460
INS-LT10-35M Series: 207 | Shaft: 35 mm | Variant: Solidlube 1000 | Part no.: 034461
INS-LT7-104 Series: 207 | Shaft: 1-1/4 in | Variant: Solidlube 700 | Part no.: 033591
INS-LT10-104 Series: 207 | Shaft: 1-1/4 in | Variant: Solidlube 1000 | Part no.: 033616
INS-LT7-106 Series: 207 | Shaft: 1-3/8 in | Variant: Solidlube 700 | Part no.: 033592
INS-LT10-106 Series: 207 | Shaft: 1-3/8 in | Variant: Solidlube 1000 | Part no.: 033617
INS-LT7-107 Series: 207 | Shaft: 1-7/16 in | Variant: Solidlube 700 | Part no.: 033593
INS-LT10-107 Series: 207 | Shaft: 1-7/16 in | Variant: Solidlube 1000 | Part no.: 033618
INS-LT7-108 Series: 207 | Shaft: 1-1/2 in | Variant: Solidlube 700 | Part no.: 033594
INS-LT10-108 Series: 207 | Shaft: 1-1/2 in | Variant: Solidlube 1000 | Part no.: 033619
INS-LT7-40M Series: 209 | Shaft: 40 mm | Variant: Solidlube 700 | Part no.: 034462
INS-LT10-40M Series: 209 | Shaft: 40 mm | Variant: Solidlube 1000 | Part no.: 034463
INS-LT7-45M Series: 209 | Shaft: 45 mm | Variant: Solidlube 700 | Part no.: 034464
INS-LT10-45M Series: 209 | Shaft: 45 mm | Variant: Solidlube 1000 | Part no.: 034465
INS-LT7-111 Series: 209 | Shaft: 1-11/16 in | Variant: Solidlube 700 | Part no.: 033595
INS-LT10-111 Series: 209 | Shaft: 1-11/16 in | Variant: Solidlube 1000 | Part no.: 033620
INS-LT7-112 Series: 209 | Shaft: 1-3/4 in | Variant: Solidlube 700 | Part no.: 033596
INS-LT10-112 Series: 209 | Shaft: 1-3/4 in | Variant: Solidlube 1000 | Part no.: 033621
INS-LT7-50M Series: 210 | Shaft: 50 mm | Variant: Solidlube 700 | Part no.: 034466
INS-LT10-50M Series: 210 | Shaft: 50 mm | Variant: Solidlube 1000 | Part no.: 034467
INS-LT7-115 Series: 210 | Shaft: 1-15/16 in | Variant: Solidlube 700 | Part no.: 033597
INS-LT10-115 Series: 210 | Shaft: 1-15/16 in | Variant: Solidlube 1000 | Part no.: 033622
INS-LT7-200 Series: 210 | Shaft: 2 in | Variant: Solidlube 700 | Part no.: 033598
INS-LT10-200 Series: 210 | Shaft: 2 in | Variant: Solidlube 1000 | Part no.: 033623
INS-LT7-203 Series: 211 | Shaft: 2-3/16 in | Variant: Solidlube 700 | Part no.: 033599
INS-LT10-203 Series: 211 | Shaft: 2-3/16 in | Variant: Solidlube 1000 | Part no.: 033624
INS-LT7-60M Series: 212 | Shaft: 60 mm | Variant: Solidlube 700 | Part no.: 034468
INS-LT10-60M Series: 212 | Shaft: 60 mm | Variant: Solidlube 1000 | Part no.: 034469
INS-LT7-207 Series: 212 | Shaft: 2-7/16 in | Variant: Solidlube 700 | Part no.: 033600
INS-LT10-207 Series: 212 | Shaft: 2-7/16 in | Variant: Solidlube 1000 | Part no.: 033625
INS-LT7-208 Series: 212 | Shaft: 2-1/2 in | Variant: Solidlube 700 | Part no.: 033601
INS-LT10-208 Series: 212 | Shaft: 2-1/2 in | Variant: Solidlube 1000 | Part no.: 033626
INS-LT7-70M Series: 215 | Shaft: 70 mm | Variant: Solidlube 700 | Part no.: 034470
INS-LT10-70M Series: 215 | Shaft: 70 mm | Variant: Solidlube 1000 | Part no.: 034471
INS-LT7-75M Series: 215 | Shaft: 75 mm | Variant: Solidlube 700 | Part no.: 034472
INS-LT10-75M Series: 215 | Shaft: 75 mm | Variant: Solidlube 1000 | Part no.: 034473
INS-LT7-215 Series: 215 | Shaft: 2-15/16 in | Variant: Solidlube 700 | Part no.: 033602
INS-LT10-215 Series: 215 | Shaft: 2-15/16 in | Variant: Solidlube 1000 | Part no.: 033627
INS-LT7-300 Series: 215 | Shaft: 3 in | Variant: Solidlube 700 | Part no.: 034117
INS-LT10-300 Series: 215 | Shaft: 3 in | Variant: Solidlube 1000 | Part no.: 034525
Insert BearingsDODGE
58 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE Solidlube LT Sleeve Bearing Insert (20-75 mm, 3/4-3 in)

Brand DODGE·Insert Bearings

Available part numbers (58)

INS-LT7-20M, INS-LT10-20M, INS-LT7-012, INS-LT10-012, INS-LT7-25M, INS-LT10-25M, INS-LT7-014, INS-LT10-014, INS-LT7-015, INS-LT10-015 + 48 more — see full table ↓

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
