DODGE Type G Medium Duty Top Angle Take-Up (1-11/16-3-1/2 in)

DODGE Type G Medium Duty Top Angle Take-Up (1-11/16-3-1/2 in)

DODGE SC/SCM/SL set screw mounted ball bearings cover light, normal and medium duty applications in a wide range of housing styles.

Key features

  • 65° set screw design balances locking force and inner ring stress
  • Light duty (SL), normal duty (SC) and medium duty (SCM) inner rings
  • DualGuard seal with rubberized flinger standard on SC/SCM
  • Fiberglass-reinforced nylon ball cage
  • Anti-rotation pin (SC, SCM) simplifies insert replacement
  • Options: no-lube sealed for life (NL), high temperature (HT)

Specifications

Brand DODGE
Product line SC/SCM/SL set screw
Housing style Top angle take-up
Housing material cast iron
Locking Set screw (65°)
Shaft range 1-11/16-3-1/2 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 4-71
TP-GM-111 Series: 210 | Shaft: 1-11/16 in | Part no.: 136070
TP-GM-112 Series: 210 | Shaft: 1-3/4 in | Part no.: 136080
TP-GM-115 Series: 211 | Shaft: 1-15/16 in | Part no.: 136071
TP-GM-203 Series: 212 | Shaft: 2-3/16 in | Part no.: 136072
TP-GM-207 Series: 214 | Shaft: 2-7/16 in | Part no.: 136073
TP-GM-211 Series: 215 | Shaft: 2-11/16 in | Part no.: 136076
TP-GM-215 Series: 216 | Shaft: 2-15/16 in | Part no.: 136074
TP-GM-300 Series: 216 | Shaft: 3 in | Part no.: 136084
TP-GM-307 Series: 218 | Shaft: 3-7/16 in | Part no.: 136075
TP-GM-308 Series: 218 | Shaft: 3-1/2 in | Part no.: 136085
Mounted Bearing UnitsDODGE
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE Type G Medium Duty Top Angle Take-Up (1-11/16-3-1/2 in)

Brand DODGE·Mounted Bearing Units

Available part numbers (10)

TP-GM-111, TP-GM-112, TP-GM-115, TP-GM-203, TP-GM-207, TP-GM-211, TP-GM-215, TP-GM-300, TP-GM-307, TP-GM-308

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
TP-GM-111Series: 210 | Shaft: 1-11/16 in | Part no.: 136070
TP-GM-112Series: 210 | Shaft: 1-3/4 in | Part no.: 136080
TP-GM-115Series: 211 | Shaft: 1-15/16 in | Part no.: 136071
TP-GM-203Series: 212 | Shaft: 2-3/16 in | Part no.: 136072
TP-GM-207Series: 214 | Shaft: 2-7/16 in | Part no.: 136073
TP-GM-211Series: 215 | Shaft: 2-11/16 in | Part no.: 136076
TP-GM-215Series: 216 | Shaft: 2-15/16 in | Part no.: 136074
TP-GM-300Series: 216 | Shaft: 3 in | Part no.: 136084
TP-GM-307Series: 218 | Shaft: 3-7/16 in | Part no.: 136075
TP-GM-308Series: 218 | Shaft: 3-1/2 in | Part no.: 136085
