DODGE Type G Set Screw Top Angle Take-Up (1-15/16-2-15/16 in)

DODGE Type G Set Screw Top Angle Take-Up (1-15/16-2-15/16 in)

DODGE SC/SCM/SL set screw mounted ball bearings cover light, normal and medium duty applications in a wide range of housing styles.

Key features

  • 65° set screw design balances locking force and inner ring stress
  • Light duty (SL), normal duty (SC) and medium duty (SCM) inner rings
  • DualGuard seal with rubberized flinger standard on SC/SCM
  • Fiberglass-reinforced nylon ball cage
  • Anti-rotation pin (SC, SCM) simplifies insert replacement
  • Options: no-lube sealed for life (NL), high temperature (HT)

Specifications

Brand DODGE
Product line SC/SCM/SL set screw
Housing style Top angle take-up
Housing material cast iron
Locking Set screw (65°)
Shaft range 1-15/16-2-15/16 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 4-70
TP-G-115 Series: 210 | Shaft: 1-15/16 in | Part no.: 012340
TP-G-200 Series: 210 | Shaft: 2 in | Part no.: 012302
TP-GM-200 Series: 211 | Shaft: 2 in | Part no.: 136081
TP-G-203 Series: 211 | Shaft: 2-3/16 in | Part no.: 012341
TP-G-204 Series: 211 | Shaft: 2-1/4 in | Part no.: 012303
TP-GM-204 Series: 212 | Shaft: 2-1/4 in | Part no.: 136082
TP-G-207 Series: 212 | Shaft: 2-7/16 in | Part no.: 012342
TP-GM-208 Series: 214 | Shaft: 2-1/2 in | Part no.: 136083
TP-G-211 Series: 214 | Shaft: 2-11/15 in | Part no.: Assembled to order
TP-G-215 Series: 215 | Shaft: 2-15/16 in | Part no.: 012343
Mounted Bearing UnitsDODGE
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE Type G Set Screw Top Angle Take-Up (1-15/16-2-15/16 in)

Brand DODGE·Mounted Bearing Units

Available part numbers (10)

TP-G-115, TP-G-200, TP-GM-200, TP-G-203, TP-G-204, TP-GM-204, TP-G-207, TP-GM-208, TP-G-211, TP-G-215

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
TP-G-115Series: 210 | Shaft: 1-15/16 in | Part no.: 012340
TP-G-200Series: 210 | Shaft: 2 in | Part no.: 012302
TP-GM-200Series: 211 | Shaft: 2 in | Part no.: 136081
TP-G-203Series: 211 | Shaft: 2-3/16 in | Part no.: 012341
TP-G-204Series: 211 | Shaft: 2-1/4 in | Part no.: 012303
TP-GM-204Series: 212 | Shaft: 2-1/4 in | Part no.: 136082
TP-G-207Series: 212 | Shaft: 2-7/16 in | Part no.: 012342
TP-GM-208Series: 214 | Shaft: 2-1/2 in | Part no.: 136083
TP-G-211Series: 214 | Shaft: 2-11/15 in | Part no.: Assembled to order
TP-G-215Series: 215 | Shaft: 2-15/16 in | Part no.: 012343
