• DODGE Ultra Kleen SCEZ PSS Polymer 4-Bolt Flange (20-50 mm, 3/4-2 in)
1 1

DODGE Ultra Kleen SCEZ PSS Polymer 4-Bolt Flange (20-50 mm, 3/4-2 in)

DODGE Ultra Kleen SCEZ PSS Polymer 4-Bolt Flange (20-50 mm, 3/4-2 in)

DODGE Ultra Kleen mounted ball bearings combine polymer housings with 100% stainless steel set screw inserts for food and beverage washdown service.

Key features

  • 100% stainless steel insert with 65° set screws and stainless anti-rotation pin
  • QuadGuard sealing system: patented triple-lip seal with rubberized flinger
  • Maxlife cage creates grease compartments that resist washout
  • Factory filled 100% with H1 food-grade grease
  • Solid cross-section polymer housing with anti-microbial agent
  • Housing groove accepts snap-on polymer end covers

Specifications

Brand DODGE
Product line Ultra Kleen
Housing style 4-bolt flange
Housing material polymer
Locking Set screw (65°), stainless steel
Shaft range 20-50 mm, 3/4-2 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 1-26
F4B-SCEZ-20M-PSS Series: 204 | Shaft: 20 mm | Part no.: 136762
F4B-SCEZ-012-PSS Series: 204 | Shaft: 3/4 in | Part no.: 136725
F4B-SCEZ-25M-PSS Series: 205 | Shaft: 25 mm | Part no.: 136763
F4B-SCEZ-100-PSS Series: 205 | Shaft: 1 in | Part no.: 136726
F4B-SCEZ-30M-PSS Series: 206 | Shaft: 30 mm | Part no.: 136764
F4B-SCEZ-103-PSS Series: 206 | Shaft: 1-3/16 in | Part no.: 136727
F4B-SCEZ-104S-PSS Series: 206 | Shaft: 1-1/4 in | Part no.: 136728
F4B-SCEZ-35M-PSS Series: 207 | Shaft: 35 mm | Part no.: 136765
F4B-SCEZ-104-PSS Series: 207 | Shaft: 1-1/4 in | Part no.: 136729
F4B-SCEZ-107-PSS Series: 207 | Shaft: 1-7/16 in | Part no.: 136730
F4B-SCEZ-40M-PSS Series: 208 | Shaft: 40 mm | Part no.: 136766
F4B-SCEZ-108-PSS Series: 208 | Shaft: 1-1/2 in | Part no.: 136731
F4B-SCEZ-45M-PSS Series: 209 | Shaft: 45 mm | Part no.: 136767
F4B-SCEZ-111-PSS Series: 209 | Shaft: 1-11/16 in | Part no.: 136732
F4B-SCEZ-50M-PSS Series: 210 | Shaft: 50 mm | Part no.: 136768
F4B-SCEZ-115-PSS Series: 210 | Shaft: 1-15/16 in | Part no.: 136733
F4B-SCEZ-200-PSS Series: 210 | Shaft: 2 in | Part no.: 136988
Mounted Bearing UnitsDODGE
17 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE Ultra Kleen SCEZ PSS Polymer 4-Bolt Flange (20-50 mm, 3/4-2 in)

Brand DODGE·Mounted Bearing Units

Available part numbers (17)

F4B-SCEZ-20M-PSS, F4B-SCEZ-012-PSS, F4B-SCEZ-25M-PSS, F4B-SCEZ-100-PSS, F4B-SCEZ-30M-PSS, F4B-SCEZ-103-PSS, F4B-SCEZ-104S-PSS, F4B-SCEZ-35M-PSS, F4B-SCEZ-104-PSS, F4B-SCEZ-107-PSS + 7 more — see full table ↓

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
F4B-SCEZ-20M-PSSSeries: 204 | Shaft: 20 mm | Part no.: 136762
F4B-SCEZ-012-PSSSeries: 204 | Shaft: 3/4 in | Part no.: 136725
F4B-SCEZ-25M-PSSSeries: 205 | Shaft: 25 mm | Part no.: 136763
F4B-SCEZ-100-PSSSeries: 205 | Shaft: 1 in | Part no.: 136726
F4B-SCEZ-30M-PSSSeries: 206 | Shaft: 30 mm | Part no.: 136764
F4B-SCEZ-103-PSSSeries: 206 | Shaft: 1-3/16 in | Part no.: 136727
F4B-SCEZ-104S-PSSSeries: 206 | Shaft: 1-1/4 in | Part no.: 136728
F4B-SCEZ-35M-PSSSeries: 207 | Shaft: 35 mm | Part no.: 136765
F4B-SCEZ-104-PSSSeries: 207 | Shaft: 1-1/4 in | Part no.: 136729
F4B-SCEZ-107-PSSSeries: 207 | Shaft: 1-7/16 in | Part no.: 136730
F4B-SCEZ-40M-PSSSeries: 208 | Shaft: 40 mm | Part no.: 136766
F4B-SCEZ-108-PSSSeries: 208 | Shaft: 1-1/2 in | Part no.: 136731
F4B-SCEZ-45M-PSSSeries: 209 | Shaft: 45 mm | Part no.: 136767
F4B-SCEZ-111-PSSSeries: 209 | Shaft: 1-11/16 in | Part no.: 136732
F4B-SCEZ-50M-PSSSeries: 210 | Shaft: 50 mm | Part no.: 136768
F4B-SCEZ-115-PSSSeries: 210 | Shaft: 1-15/16 in | Part no.: 136733
F4B-SCEZ-200-PSSSeries: 210 | Shaft: 2 in | Part no.: 136988

Need a different model, or a part not listed here? Send us your parts list →
