DODGE Ultra Kleen SCEZ PSS Polymer Flange Bracket

DODGE Ultra Kleen SCEZ PSS Polymer Flange Bracket

DODGE Ultra Kleen mounted ball bearings combine polymer housings with 100% stainless steel set screw inserts for food and beverage washdown service.

Key features

  • 100% stainless steel insert with 65° set screws and stainless anti-rotation pin
  • QuadGuard sealing system: patented triple-lip seal with rubberized flinger
  • Maxlife cage creates grease compartments that resist washout
  • Factory filled 100% with H1 food-grade grease
  • Solid cross-section polymer housing with anti-microbial agent
  • Housing groove accepts snap-on polymer end covers

Specifications

Brand DODGE
Product line Ultra Kleen
Housing style Flange bracket
Housing material polymer
Locking Set screw (65°), stainless steel
Shaft range 20-35 mm, 3/4-1-7/16 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 1-23
FB-SCEZ-20M-PSS Series: 204 | Shaft: 20 mm | Part no.: 136758
FB-SCEZ-012-PSS Series: 204 | Shaft: 3/4 in | Part no.: 136719
FB-SCEZ-25M-PSS Series: 205 | Shaft: 25 mm | Part no.: 136759
FB-SCEZ-100-PSS Series: 205 | Shaft: 1 in | Part no.: 136720
FB-SCEZ-30M-PSS Series: 206 | Shaft: 30 mm | Part no.: 136760
FB-SCEZ-103-PSS Series: 206 | Shaft: 1-3/16 in | Part no.: 136721
FB-SCEZ-104S-PSS Series: 206 | Shaft: 1-1/4 in | Part no.: 136722
FB-SCEZ-35M-PSS Series: 207 | Shaft: 35 mm | Part no.: 136761
FB-SCEZ-104-PSS Series: 207 | Shaft: 1-1/4 in | Part no.: 136723
FB-SCEZ-107-PSS Series: 207 | Shaft: 1-7/16 in | Part no.: 136724
Mounted Bearing UnitsDODGE
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE Ultra Kleen SCEZ PSS Polymer Flange Bracket

Brand DODGE·Mounted Bearing Units

Available part numbers (10)

FB-SCEZ-20M-PSS, FB-SCEZ-012-PSS, FB-SCEZ-25M-PSS, FB-SCEZ-100-PSS, FB-SCEZ-30M-PSS, FB-SCEZ-103-PSS, FB-SCEZ-104S-PSS, FB-SCEZ-35M-PSS, FB-SCEZ-104-PSS, FB-SCEZ-107-PSS
