DODGE Ultra Kleen SCEZ SHSS Stainless Flange Bracket

DODGE Ultra Kleen SCEZ SHSS Stainless Flange Bracket

DODGE Ultra Kleen mounted ball bearings combine stainless steel housings with 100% stainless steel set screw inserts for food and beverage washdown service.

Key features

  • 100% stainless steel insert with 65° set screws and stainless anti-rotation pin
  • QuadGuard sealing system: patented triple-lip seal with rubberized flinger
  • Maxlife cage creates grease compartments that resist washout
  • Factory filled 100% with H1 food-grade grease
  • 300 series stainless steel housing casting
  • Housing groove accepts snap-on polymer end covers

Specifications

Brand DODGE
Product line Ultra Kleen
Housing style Flange bracket
Housing material stainless steel
Locking Set screw (65°), stainless steel
Shaft range 20-50 mm, 3/4-2 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 1-24
FB-SCEZ-20M-SHSS Series: 204 | Shaft: 20 mm | Part no.: 136867
FB-SCEZ-012-SHSS Series: 204 | Shaft: 3/4 in | Part no.: 136801
FB-SCEZ-25M-SHSS Series: 205 | Shaft: 25 mm | Part no.: 136868
FB-SCEZ-100-SHSS Series: 205 | Shaft: 1 in | Part no.: 136802
FB-SCEZ-30M-SHSS Series: 206 | Shaft: 30 mm | Part no.: 136869
FB-SCEZ-103-SHSS Series: 206 | Shaft: 1-3/16 in | Part no.: 136803
FB-SCEZ-104S-SHSS Series: 206 | Shaft: 1-1/4 in | Part no.: 136804
FB-SCEZ-35M-SHSS Series: 207 | Shaft: 35 mm | Part no.: 136870
FB-SCEZ-104-SHSS Series: 207 | Shaft: 1-1/4 in | Part no.: 136805
FB-SCEZ-107-SHSS Series: 207 | Shaft: 1-7/16 in | Part no.: 136806
FB-SCEZ-50M-SHSS Series: 210 | Shaft: 50 mm | Part no.: 136872
FB-SCEZ-115-SHSS Series: 210 | Shaft: 1-15/16 in | Part no.: 136808
FB-SCEZ-200-SHSS Series: 210 | Shaft: 2 in | Part no.: 136992
Mounted Bearing UnitsDODGE
13 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE Ultra Kleen SCEZ SHSS Stainless Flange Bracket

Brand DODGE·Mounted Bearing Units

Available part numbers (13)

FB-SCEZ-20M-SHSS, FB-SCEZ-012-SHSS, FB-SCEZ-25M-SHSS, FB-SCEZ-100-SHSS, FB-SCEZ-30M-SHSS, FB-SCEZ-103-SHSS, FB-SCEZ-104S-SHSS, FB-SCEZ-35M-SHSS, FB-SCEZ-104-SHSS, FB-SCEZ-107-SHSS + 3 more — see full table ↓

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
FB-SCEZ-20M-SHSSSeries: 204 | Shaft: 20 mm | Part no.: 136867
FB-SCEZ-012-SHSSSeries: 204 | Shaft: 3/4 in | Part no.: 136801
FB-SCEZ-25M-SHSSSeries: 205 | Shaft: 25 mm | Part no.: 136868
FB-SCEZ-100-SHSSSeries: 205 | Shaft: 1 in | Part no.: 136802
FB-SCEZ-30M-SHSSSeries: 206 | Shaft: 30 mm | Part no.: 136869
FB-SCEZ-103-SHSSSeries: 206 | Shaft: 1-3/16 in | Part no.: 136803
FB-SCEZ-104S-SHSSSeries: 206 | Shaft: 1-1/4 in | Part no.: 136804
FB-SCEZ-35M-SHSSSeries: 207 | Shaft: 35 mm | Part no.: 136870
FB-SCEZ-104-SHSSSeries: 207 | Shaft: 1-1/4 in | Part no.: 136805
FB-SCEZ-107-SHSSSeries: 207 | Shaft: 1-7/16 in | Part no.: 136806
FB-SCEZ-50M-SHSSSeries: 210 | Shaft: 50 mm | Part no.: 136872
FB-SCEZ-115-SHSSSeries: 210 | Shaft: 1-15/16 in | Part no.: 136808
FB-SCEZ-200-SHSSSeries: 210 | Shaft: 2 in | Part no.: 136992
