• DODGE Ultra Kleen SCEZ SHSS Stainless Wide Slot Take-Up
1 1

DODGE Ultra Kleen SCEZ SHSS Stainless Wide Slot Take-Up

DODGE Ultra Kleen SCEZ SHSS Stainless Wide Slot Take-Up

DODGE Ultra Kleen mounted ball bearings combine stainless steel housings with 100% stainless steel set screw inserts for food and beverage washdown service.

Key features

  • 100% stainless steel insert with 65° set screws and stainless anti-rotation pin
  • QuadGuard sealing system: patented triple-lip seal with rubberized flinger
  • Maxlife cage creates grease compartments that resist washout
  • Factory filled 100% with H1 food-grade grease
  • 300 series stainless steel housing casting
  • Housing groove accepts snap-on polymer end covers

Specifications

Brand DODGE
Product line Ultra Kleen
Housing style Wide slot take-up
Housing material stainless steel
Locking Set screw (65°), stainless steel
Shaft range 20-50 mm, 3/4-2 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 1-30
WSTU-SCEZ-20M-SHSS Series: 204 | Shaft: 20 mm | Part no.: 136897
WSTU-SCEZ-012-SHSS Series: 204 | Shaft: 3/4 in | Part no.: 136841
WSTU-SCEZ-25M-SHSS Series: 205 | Shaft: 25 mm | Part no.: 136898
WSTU-SCEZ-100-SHSS Series: 205 | Shaft: 1 in | Part no.: 136842
WSTU-SCEZ-30M-SHSS Series: 206 | Shaft: 30 mm | Part no.: 136899
WSTU-SCEZ-103-SHSS Series: 206 | Shaft: 1-3/16 in | Part no.: 136843
WSTU-SCEZ-104S-SHSS Series: 206 | Shaft: 1-1/4 in | Part no.: 136844
WSTU-SCEZ-35M-SHSS Series: 207 | Shaft: 35 mm | Part no.: 136900
WSTU-SCEZ-104-SHSS Series: 207 | Shaft: 1-1/4 in | Part no.: 136845
WSTU-SCEZ-107-SHSS Series: 207 | Shaft: 1-7/16 in | Part no.: 136846
WSTU-SCEZ-40M-SHSS Series: 208 | Shaft: 40 mm | Part no.: 136901
WSTU-SCEZ-108-SHSS Series: 208 | Shaft: 1-1/2 in | Part no.: 136847
WSTU-SCEZ-50M-SHSS Series: 210 | Shaft: 50 mm | Part no.: 136902
WSTU-SCEZ-115-SHSS Series: 210 | Shaft: 1-15/16 in | Part no.: 136848
WSTU-SCEZ-200-SHSS Series: 210 | Shaft: 2 in | Part no.: 136995
Mounted Bearing UnitsDODGE
15 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE Ultra Kleen SCEZ SHSS Stainless Wide Slot Take-Up

Brand DODGE·Mounted Bearing Units

Available part numbers (15)

WSTU-SCEZ-20M-SHSS, WSTU-SCEZ-012-SHSS, WSTU-SCEZ-25M-SHSS, WSTU-SCEZ-100-SHSS, WSTU-SCEZ-30M-SHSS, WSTU-SCEZ-103-SHSS, WSTU-SCEZ-104S-SHSS, WSTU-SCEZ-35M-SHSS, WSTU-SCEZ-104-SHSS, WSTU-SCEZ-107-SHSS + 5 more — see full table ↓

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
WSTU-SCEZ-20M-SHSSSeries: 204 | Shaft: 20 mm | Part no.: 136897
WSTU-SCEZ-012-SHSSSeries: 204 | Shaft: 3/4 in | Part no.: 136841
WSTU-SCEZ-25M-SHSSSeries: 205 | Shaft: 25 mm | Part no.: 136898
WSTU-SCEZ-100-SHSSSeries: 205 | Shaft: 1 in | Part no.: 136842
WSTU-SCEZ-30M-SHSSSeries: 206 | Shaft: 30 mm | Part no.: 136899
WSTU-SCEZ-103-SHSSSeries: 206 | Shaft: 1-3/16 in | Part no.: 136843
WSTU-SCEZ-104S-SHSSSeries: 206 | Shaft: 1-1/4 in | Part no.: 136844
WSTU-SCEZ-35M-SHSSSeries: 207 | Shaft: 35 mm | Part no.: 136900
WSTU-SCEZ-104-SHSSSeries: 207 | Shaft: 1-1/4 in | Part no.: 136845
WSTU-SCEZ-107-SHSSSeries: 207 | Shaft: 1-7/16 in | Part no.: 136846
WSTU-SCEZ-40M-SHSSSeries: 208 | Shaft: 40 mm | Part no.: 136901
WSTU-SCEZ-108-SHSSSeries: 208 | Shaft: 1-1/2 in | Part no.: 136847
WSTU-SCEZ-50M-SHSSSeries: 210 | Shaft: 50 mm | Part no.: 136902
WSTU-SCEZ-115-SHSSSeries: 210 | Shaft: 1-15/16 in | Part no.: 136848
WSTU-SCEZ-200-SHSSSeries: 210 | Shaft: 2 in | Part no.: 136995
