Dongyang Chain DYBS Bushed Elevator Chain

Dongyang Chain DYBS Bushed Elevator Chain

The DYBS bush-type chain is a heavy-duty chain for applications that need a heavier and stronger chain.

Key features

  • Typical uses are cement elevators and elevators or conveyors in sawmills and other high-wear environments
  • This roller-less bush chain has a long service life and low maintenance
  • Its parts are heat treated for wear resistance
  • Straight and offset sidebar versions are shown, with F, K1, K2, K3 and K44 attachments
DYBS 188 Pitch: 66.27 mm | Avg. tensile strength: 11,350 kgf | Weight: 5.7 kg/m | Pin dia.: 12.7 mm | Pin length L1/L2: 31.2/36.3 mm | Plate height: 28.6 mm | Plate thickness: 6.3 mm | Bush dia.: 22.4 mm | Inner width: 27.2 mm | Attachments available: A22 / K1 / K2
DYBS 3283 Pitch: 101.6 mm | Avg. tensile strength: 11,350 kgf | Weight: 4.6 kg/m | Pin dia.: 12.7 mm | Pin length L1/L2: 34.5/37.9 mm | Plate height: 28.6 mm | Plate thickness: 6.3 mm | Bush dia.: 20.1 mm | Inner width: 33.3 mm | Attachments available: K2
DYBS 131 Pitch: 78.11 mm | Avg. tensile strength: 18,160 kgf | Weight: 11.0 kg/m | Pin dia.: 15.9 mm | Pin length L1/L2: 41.2/48.3 mm | Plate height: 38.1 mm | Plate thickness: 9.5 mm | Bush dia.: 31.8 mm | Inner width: 32.8 mm | Attachments available: K2
DYBS 3825 Pitch: 101.6 mm | Avg. tensile strength: 18,160 kgf | Weight: 8.8 kg/m | Pin dia.: 15.9 mm | Pin length L1/L2: 39.1/43.9 mm | Plate height: 38.1 mm | Plate thickness: 7.9 mm | Bush dia.: 29.5 mm | Inner width: 36.6 mm | Attachments available: K2
DYBS 2103 Pitch: 78.11 mm | Avg. tensile strength: 18,160 kgf | Weight: 8.3 kg/m | Pin dia.: 19.05 mm | Pin length L1/L2: 33.8/43.2 mm | Plate height: 38.1 mm | Plate thickness: 6.3 mm | Bush dia.: 31.8 mm | Inner width: 35.1 mm | Attachments available: F29
DYBS 110 Pitch: 152.4 mm | Avg. tensile strength: 18,160 kgf | Weight: 10.3 kg/m | Pin dia.: 15.9 mm | Pin length L1/L2: 51.8/59.2 mm | Plate height: 38.1 mm | Plate thickness: 9.5 mm | Bush dia.: 31.8 mm | Inner width: 54.1 mm | Attachments available: K2
DYBS 102B Pitch: 101.6 mm | Avg. tensile strength: 18,160 kgf | Weight: 10.3 kg/m | Pin dia.: 15.9 mm | Pin length L1/L2: 51.8/59.2 mm | Plate height: 38.1 mm | Plate thickness: 9.5 mm | Bush dia.: 25.4 mm | Inner width: 54.1 mm | Attachments available: K2
DYBS 102 1/2 Pitch: 102.62 mm | Avg. tensile strength: 22,700 kgf | Weight: 14.0 kg/m | Pin dia.: 19.05 mm | Pin length L1/L2: 53.9/58.9 mm | Plate height: 44.5 mm | Plate thickness: 9.5 mm | Bush dia.: 35.1 mm | Inner width: 57.2 mm | Attachments available: K2
DYBS 111 Pitch: 120.9 mm | Avg. tensile strength: 22,700 kgf | Weight: 15.2 kg/m | Pin dia.: 19.05 mm | Pin length L1/L2: 59.4/64.8 mm | Plate height: 50.8 mm | Plate thickness: 9.5 mm | Bush dia.: 36.6 mm | Inner width: 66.8 mm | Attachments available: K2
DYBS 111 Special Pitch: - mm | Avg. tensile strength: 22,700 kgf | Weight: 13.1 kg/m | Pin dia.: 19.05 mm | Pin length L1/L2: 59.4/64.8 mm | Plate height: 50.8 mm | Plate thickness: 9.5 mm | Bush dia.: 36.6 mm | Inner width: 66.8 mm | Attachments available: K2
DYBS 844 Pitch: 152.4 mm | Avg. tensile strength: 31,780 kgf | Weight: 15.5 kg/m | Pin dia.: 19.05 mm | Pin length L1/L2: 62.7/69.1 mm | Plate height: 50.8 mm | Plate thickness: 12.7 mm | Bush dia.: 30.2 mm | Inner width: 63.5 mm | Attachments available: K2
DYBS 856 Pitch: 152.4 mm | Avg. tensile strength: 45,400 kgf | Weight: 24.6 kg/m | Pin dia.: 25.4 mm | Pin length L1/L2: 73.7/78.2 mm | Plate height: 63.5 mm | Plate thickness: 12.7 mm | Bush dia.: 44.5 mm | Inner width: 76.2 mm | Attachments available: K2 / K3 / K6 / K24 / K35
DYBS 2857 Pitch: 152.4 mm | Avg. tensile strength: 59,020 kgf | Weight: 31.2 kg/m | Pin dia.: 25.4 mm | Pin length L1/L2: 73.7/78.2 mm | Plate height: 82.6 mm | Plate thickness: 12.7 mm | Bush dia.: 44.5 mm | Inner width: 76.2 mm | Attachments available: K44
DYBS 150 Plus Pitch: 153.67 mm | Avg. tensile strength: 45,400 kgf | Weight: 24.7 kg/m | Pin dia.: 25.4 mm | Pin length L1/L2: 78.0/83.6 mm | Plate height: 50.8 mm | Plate thickness: 12.7 mm | Bush dia.: 44.5 mm | Inner width: 85.1 mm | Attachments available: K2 / K3
DYBS 850 Pitch: 152.4 mm | Avg. tensile strength: 72,640 kgf | Weight: 35.0 kg/m | Pin dia.: 33.35 mm | Pin length L1/L2: 75.2/81.8 mm | Plate height: 76.2 mm | Plate thickness: 16 mm | Bush dia.: 50.8 mm | Inner width: 57.2 mm
DYBS 2859 Pitch: 152.4 mm | Avg. tensile strength: 90,800 kgf | Weight: 50.6 kg/m | Pin dia.: 31.8 mm | Pin length L1/L2: 92.7/100.8 mm | Plate height: 101.6 mm | Plate thickness: 16 mm | Bush dia.: 60.2 mm | Inner width: 95.3 mm | Attachments available: K44
DYBS 2864 Pitch: 177.8 mm | Avg. tensile strength: 90,800 kgf | Weight: 46.1 kg/m | Pin dia.: 31.8 mm | Pin length L1/L2: 92.7/100.8 mm | Plate height: 101.6 mm | Plate thickness: 16 mm | Bush dia.: 60.2 mm | Inner width: 95.3 mm | Attachments available: K44
Bucket Elevator ChainsDongyang Chain
17 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Dongyang Chain DYBS Bushed Elevator Chain

Brand Dongyang Chain·Bucket Elevator Chains

Available part numbers (17)

DYBS 188, DYBS 3283, DYBS 131, DYBS 3825, DYBS 2103, DYBS 110, DYBS 102B, DYBS 102 1/2, DYBS 111, DYBS 111 Special + 7 more — see full table ↓
