Dongyang Chain Grain Conveyor Chain with Cleaner

Dongyang Chain Grain Conveyor Chain with Cleaner

This flow conveyor chain is designed specifically for grain handling.

Key features

  • It combines flight attachments with cleaner attachments on a roller conveyor chain
  • Sizes from 75 mm to 200 mm pitch are listed with conveyor types FK 110 to FK 450
DY 03075-S Conveyor type: FK 110 | Pitch: 75 mm | Roller dia.: 15.9 mm | Inner width: 16.1 mm | Plate height: 22 mm | Plate thickness: 3.2 mm | Attachment span 2X: 95 mm | Attachment height S: 20 mm | Cleaner width CX: 105 mm | Cleaner height CS: 28 mm | Weight: 2.1 kg/m | Avg. tensile strength: 30,000 kgf
DY 430-S Conveyor type: FK 150 | Pitch: 101.6 mm | Roller dia.: 20.1 mm | Inner width: 22.6 mm | Plate height: 25.4 mm | Plate thickness: 4.8 mm | Attachment span 2X: 135 mm | Attachment height S: 22 mm | Cleaner width CX: 145 mm | Cleaner height CS: 32 mm | Weight: 3.4 kg/m | Avg. tensile strength: 5,500 kgf
DY 450-S Conveyor type: FK 150 | Pitch: 101.6 mm | Roller dia.: 22.2 mm | Inner width: 27 mm | Plate height: 28.6 mm | Plate thickness: 6.3 mm | Attachment span 2X: 135 mm | Attachment height S: 25 mm | Cleaner width CX: 145 mm | Cleaner height CS: 34 mm | Weight: 5.0 kg/m | Avg. tensile strength: 8,000 kgf
DY 08125-S Conveyor type: FK 200 | Pitch: 125 mm | Roller dia.: 22.2 mm | Inner width: 27 mm | Plate height: 28.6 mm | Plate thickness: 6.3 mm | Attachment span 2X: 185 mm | Attachment height S: 25 mm | Cleaner width CX: 195 mm | Cleaner height CS: 34 mm | Weight: 5.0 kg/m | Avg. tensile strength: 8,000 kgf
DY 10125-S Conveyor type: FK 200 / FK 240 | Pitch: 125 mm | Roller dia.: 29 mm | Inner width: 30 mm | Plate height: 38.1 mm | Plate thickness: 6.3 mm | Attachment span 2X: 185 / 225 mm | Attachment height S: 34 mm | Cleaner width CX: 195 / 235 mm | Cleaner height CS: 47 mm | Weight: 6.8 / 7.3 kg/m | Avg. tensile strength: 11,500 kgf
DY 10150-S Conveyor type: FK 270 / FK 320 | Pitch: 150 mm | Roller dia.: 29 mm | Inner width: 30 mm | Plate height: 38.1 mm | Plate thickness: 6.3 mm | Attachment span 2X: 250 / 300 mm | Attachment height S: 34 mm | Cleaner width CX: 265 / 315 mm | Cleaner height CS: 47 mm | Weight: 6.9 / 7.2 kg/m | Avg. tensile strength: 11,500 kgf
DY 6205-S Conveyor type: FK 270 | Pitch: 152.4 mm | Roller dia.: 34.9 mm | Inner width: 37.1 mm | Plate height: 44.5 mm | Plate thickness: 7.9 mm | Attachment span 2X: 250 mm | Attachment height S: 38 mm | Cleaner width CX: 265 mm | Cleaner height CS: 53 mm | Weight: 10.5 kg/m | Avg. tensile strength: 19,000 kgf
DY 12200-S Conveyor type: FK 350 | Pitch: 200 mm | Roller dia.: 34.9 mm | Inner width: 37.1 mm | Plate height: 44.5 mm | Plate thickness: 7.9 mm | Attachment span 2X: 330 mm | Attachment height S: 38 mm | Cleaner width CX: 345 mm | Cleaner height CS: 53 mm | Weight: 10.3 kg/m | Avg. tensile strength: 19,000 kgf
DY 17200-S Conveyor type: FK 350 / FK 450 | Pitch: 200 mm | Roller dia.: 40.1 mm | Inner width: 51.4 mm | Plate height: 50.8 mm | Plate thickness: 9.5 mm | Attachment span 2X: 330 / 430 mm | Attachment height S: 46 mm | Cleaner width CX: 345 / 445 mm | Cleaner height CS: 58 mm | Weight: 14.0 / 16.0 kg/m | Avg. tensile strength: 25,000 kgf
DY 26200S Conveyor type: FK 450 | Pitch: 200 mm | Roller dia.: 44.5 mm | Inner width: 57.2 mm | Plate height: 63.5 mm | Plate thickness: 9.5 mm | Attachment span 2X: 430 mm | Attachment height S: 58 mm | Cleaner width CX: 445 mm | Cleaner height CS: 68 mm | Weight: 21.0 kg/m | Avg. tensile strength: 32,000 kgf
Flow Conveyor ChainsDongyang Chain
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Dongyang Chain Grain Conveyor Chain with Cleaner

Brand Dongyang Chain·Flow Conveyor Chains

Available part numbers (10)

DY 03075-S, DY 430-S, DY 450-S, DY 08125-S, DY 10125-S, DY 10150-S, DY 6205-S, DY 12200-S, DY 17200-S, DY 26200S

How to order

Send the Dongyang Chain part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
DY 03075-SConveyor type: FK 110 | Pitch: 75 mm | Roller dia.: 15.9 mm | Inner width: 16.1 mm | Plate height: 22 mm | Plate thickness: 3.2 mm | Attachment span 2X: 95 mm | Attachment height S: 20 mm | Cleaner width CX: 105 mm | Cleaner height CS: 28 mm | Weight: 2.1 kg/m | Avg. tensile strength: 30,000 kgf
DY 430-SConveyor type: FK 150 | Pitch: 101.6 mm | Roller dia.: 20.1 mm | Inner width: 22.6 mm | Plate height: 25.4 mm | Plate thickness: 4.8 mm | Attachment span 2X: 135 mm | Attachment height S: 22 mm | Cleaner width CX: 145 mm | Cleaner height CS: 32 mm | Weight: 3.4 kg/m | Avg. tensile strength: 5,500 kgf
DY 450-SConveyor type: FK 150 | Pitch: 101.6 mm | Roller dia.: 22.2 mm | Inner width: 27 mm | Plate height: 28.6 mm | Plate thickness: 6.3 mm | Attachment span 2X: 135 mm | Attachment height S: 25 mm | Cleaner width CX: 145 mm | Cleaner height CS: 34 mm | Weight: 5.0 kg/m | Avg. tensile strength: 8,000 kgf
DY 08125-SConveyor type: FK 200 | Pitch: 125 mm | Roller dia.: 22.2 mm | Inner width: 27 mm | Plate height: 28.6 mm | Plate thickness: 6.3 mm | Attachment span 2X: 185 mm | Attachment height S: 25 mm | Cleaner width CX: 195 mm | Cleaner height CS: 34 mm | Weight: 5.0 kg/m | Avg. tensile strength: 8,000 kgf
DY 10125-SConveyor type: FK 200 / FK 240 | Pitch: 125 mm | Roller dia.: 29 mm | Inner width: 30 mm | Plate height: 38.1 mm | Plate thickness: 6.3 mm | Attachment span 2X: 185 / 225 mm | Attachment height S: 34 mm | Cleaner width CX: 195 / 235 mm | Cleaner height CS: 47 mm | Weight: 6.8 / 7.3 kg/m | Avg. tensile strength: 11,500 kgf
DY 10150-SConveyor type: FK 270 / FK 320 | Pitch: 150 mm | Roller dia.: 29 mm | Inner width: 30 mm | Plate height: 38.1 mm | Plate thickness: 6.3 mm | Attachment span 2X: 250 / 300 mm | Attachment height S: 34 mm | Cleaner width CX: 265 / 315 mm | Cleaner height CS: 47 mm | Weight: 6.9 / 7.2 kg/m | Avg. tensile strength: 11,500 kgf
DY 6205-SConveyor type: FK 270 | Pitch: 152.4 mm | Roller dia.: 34.9 mm | Inner width: 37.1 mm | Plate height: 44.5 mm | Plate thickness: 7.9 mm | Attachment span 2X: 250 mm | Attachment height S: 38 mm | Cleaner width CX: 265 mm | Cleaner height CS: 53 mm | Weight: 10.5 kg/m | Avg. tensile strength: 19,000 kgf
DY 12200-SConveyor type: FK 350 | Pitch: 200 mm | Roller dia.: 34.9 mm | Inner width: 37.1 mm | Plate height: 44.5 mm | Plate thickness: 7.9 mm | Attachment span 2X: 330 mm | Attachment height S: 38 mm | Cleaner width CX: 345 mm | Cleaner height CS: 53 mm | Weight: 10.3 kg/m | Avg. tensile strength: 19,000 kgf
DY 17200-SConveyor type: FK 350 / FK 450 | Pitch: 200 mm | Roller dia.: 40.1 mm | Inner width: 51.4 mm | Plate height: 50.8 mm | Plate thickness: 9.5 mm | Attachment span 2X: 330 / 430 mm | Attachment height S: 46 mm | Cleaner width CX: 345 / 445 mm | Cleaner height CS: 58 mm | Weight: 14.0 / 16.0 kg/m | Avg. tensile strength: 25,000 kgf
DY 26200SConveyor type: FK 450 | Pitch: 200 mm | Roller dia.: 44.5 mm | Inner width: 57.2 mm | Plate height: 63.5 mm | Plate thickness: 9.5 mm | Attachment span 2X: 430 mm | Attachment height S: 58 mm | Cleaner width CX: 445 mm | Cleaner height CS: 68 mm | Weight: 21.0 kg/m | Avg. tensile strength: 32,000 kgf
