Dongyang Chain Sugar Mill Bushed Roller Chain

Dongyang Chain Sugar Mill Bushed Roller Chain

This bushed roller chain is for sugar plants and is listed in chain types 3 to 12 with straight, offset and scalloped sidebars.

Key features

  • Hyper versions give higher strength
  • A1, A2, K1, K2 and A22 attachments and bucket-wing or flight-wing attachments are available
  • Weights on page 63 are given per foot and on page 67 per metre
DY578 Chain type: 3 | Pitch: 66.27 mm | Roller dia.: 22.2 mm | Roller width: 27 mm | Pin dia.: 9.53 mm | Pin length L1/L2: 25/29 mm | Plate height: 25.4 mm | Plate thickness: 4 mm | Avg. tensile strength: 4,500 kgf | Weight: 1.0 kg/ft
DY40 Chain type: 3 | Pitch: 78.11 mm | Roller dia.: 31.75 mm | Roller width: 38.1 mm | Pin dia.: 15.9 mm | Pin length L1/L2: 42.5/46.8 mm | Plate height: 38.1 mm | Plate thickness: 7.9 mm | Avg. tensile strength: 13,000 kgf | Weight: 3.1 kg/ft
DY40 Hyper Chain type: 3 | Pitch: 78.11 mm | Roller dia.: 31.75 mm | Roller width: 38.1 mm | Pin dia.: 15.7 mm | Pin length L1/L2: 46/51.6 mm | Plate height: 41.3 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 34,000 kgf | Weight: 3.8 kg/ft
DY60 Chain type: 5 | Pitch: 102.6 mm | Roller dia.: 50.8 mm | Roller width: 33.3 mm | Pin dia.: 17.5 mm | Pin length L1/L2: 41.7/47.2 mm | Plate height: 38.1 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 14,900 kgf | Weight: 3.9 kg/ft | Attachments available: A1 / K1
DY124 Chain type: 3 | Pitch: 103.2 mm | Roller dia.: 44.45 mm | Roller width: 49.2 mm | Pin dia.: 22.2 mm | Pin length L1/L2: 42.9/46.6 mm | Plate height: 54.0 mm | Plate thickness: 12.7 mm | Avg. tensile strength: 27,000 kgf | Weight: 7.2 kg/ft
DY124 Hyper Chain type: 3 | Pitch: 103.2 mm | Roller dia.: 44.45 mm | Roller width: 49.2 mm | Pin dia.: 22.2 mm | Pin length L1/L2: 64.3/73.0 mm | Plate height: 58.7 mm | Plate thickness: 15.9 mm | Avg. tensile strength: 57,000 kgf | Weight: 7.4 kg/ft
DY126 Chain type: 5 | Pitch: 152.4 mm | Roller dia.: 50.8 mm | Roller width: 31.0 mm | Pin dia.: 14.3 mm | Pin length L1/L2: 34.9/38.9 mm | Plate height: 38.1 mm | Plate thickness: 6.3 mm | Avg. tensile strength: 9,500 kgf | Weight: 2.3 kg/ft | Attachments available: A22
DY1131 Chain type: 5 | Pitch: 152.4 mm | Roller dia.: 76.2 mm | Roller width: 38.1 mm | Pin dia.: 19.05 mm | Pin length L1/L2: 46.8/51.6 mm | Plate height: 50.8 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 21,000 kgf | Weight: 5.7 kg/ft | Attachments available: A2 / K2 / A22
DY2184 Chain type: 4 | Pitch: 152.4 mm | Roller dia.: 76.2 mm | Roller width: 34.9 mm | Pin dia.: 22.2 mm | Pin length L1/L2: 45.2/53.2 mm | Plate height: 50.8 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 21,000 kgf | Weight: 5.6 kg/ft | Attachments available: A22
DY996 Chain type: 5 | Pitch: 152.4 mm | Roller dia.: 69.9 mm | Roller width: 38.1 mm | Pin dia.: 19.05 mm | Pin length L1/L2: 46.8/51.6 mm | Plate height: 50.8 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 31,700 kgf | Weight: 5.4 kg/ft | Attachments available: K2
DY960 Chain type: 5 | Pitch: 152.4 mm | Roller dia.: 69.9 mm | Roller width: 38.1 mm | Pin dia.: 21.8 mm | Pin length L1/L2: 51.6/61.1 mm | Plate height: 57.2 mm | Plate thickness: 12.7 mm | Avg. tensile strength: 34,000 kgf | Weight: 9.5 kg/ft | Attachments available: K1 / K2
DY2184 hyper Chain type: 4 | Pitch: 152.4 mm | Roller dia.: 76.2 mm | Roller width: 34.9 mm | Pin dia.: 22.2 mm | Pin length L1/L2: 46.6/48.8 mm | Plate height: 50.8 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 36,700 kgf | Weight: 5.8 kg/ft | Attachments available: A22
DY1796 Chain type: 5 | Pitch: 152.4 mm | Roller dia.: 69.9 mm | Roller width: 38.1 mm | Pin dia.: 22.2 mm | Pin length L1/L2: 45.2/54.8 mm | Plate height: 57.2 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 38,500 kgf | Weight: 7.7 kg/ft | Attachments available: K2
DY960 Hyper Chain type: 5 | Pitch: 152.4 mm | Roller dia.: 69.9 mm | Roller width: 38.1 mm | Pin dia.: 21.8 mm | Pin length L1/L2: 51.6/61.1 mm | Plate height: 57.2 mm | Plate thickness: 12.7 mm | Avg. tensile strength: 43,000 kgf | Weight: 9.5 kg/ft | Attachments available: K1 / K2
DY1796 Hyper Chain type: 5 | Pitch: 152.4 mm | Roller dia.: 76.2 mm | Roller width: 38.1 mm | Pin dia.: 22.2 mm | Pin length L1/L2: 46.0/55.2 mm | Plate height: 57.2 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 47,600 kgf | Weight: 7.8 kg/ft | Attachments available: K2
DY800 Chain type: 5 | Pitch: 203.2 mm | Roller dia.: 88.9 mm | Roller width: 46.0 mm | Pin dia.: 25.1 mm | Pin length L1/L2: 57.9/60.3 mm | Plate height: 76.2 mm | Plate thickness: 12.7 mm | Avg. tensile strength: 75,700 kgf | Weight: 9.1 kg/ft | Attachments available: K1
DY40H Chain type: 8 | Pitch: 78.11 mm | Roller dia.: 31.75 mm | Roller width: 18.1 mm | Pin dia.: 15.88 mm | Pin length L1/L2: 40.05/46.65 mm | Plate height: 38.0 mm | Plate thickness: 8.0 mm | Min. breaking strength: 19,500 kgf | Weight: 10.2 kg/m
DY124H Chain type: 8 | Pitch: 103.20 mm | Roller dia.: 44.45 mm | Roller width: 49.1 mm | Pin dia.: 22.23 mm | Pin length L1/L2: 57.0/66.0 mm | Plate height: 54.0 mm | Plate thickness: 12.7 mm | Min. breaking strength: 57,000 kgf | Weight: 22.4 kg/m
DY266 Chain type: 8 | Pitch: 103.20 mm | Roller dia.: 44.45 mm | Roller width: 49.2 mm | Pin dia.: 22.23 mm | Pin length L1/L2: 57.0/66.0 mm | Plate height: 54.0 mm | Plate thickness: 12.7 mm | Min. breaking strength: 54,000 kgf | Weight: 22.5 kg/m
DY1113 Chain type: 9 | Pitch: 102.60 mm | Roller dia.: 50.8 mm | Roller width: 37.5 mm | Pin dia.: 17.5 mm | Pin length L1/L2: 38.0/45.0 mm | Plate height: 38.1 mm | Plate thickness: 6.3 mm | Min. breaking strength: 9,500 kgf | Weight: 10.2 kg/m
DY1124 Chain type: 9 | Pitch: 101.60 mm | Roller dia.: 50.8 mm | Roller width: 32.0 mm | Pin dia.: 12.7 mm | Pin length L1/L2: 37.7/42.8 mm | Plate height: 38.1 mm | Plate thickness: 7.9 mm | Min. breaking strength: 10,000 kgf | Weight: 11.0 kg/m
DY1125 Chain type: 9 | Pitch: 101.60 mm | Roller dia.: 50.8 mm | Roller width: 32.6 mm | Pin dia.: 17.5 mm | Pin length L1/L2: 39.5/45.1 mm | Plate height: 44.5 mm | Plate thickness: 7.9 mm | Min. breaking strength: 15,500 kgf | Weight: 12.7 kg/m
DY1130 Chain type: 9 | Pitch: 152.40 mm | Roller dia.: 63.5 mm | Roller width: 37.6 mm | Pin dia.: 19.05 mm | Pin length L1/L2: 38.5/45.6 mm | Plate height: 50.8 mm | Plate thickness: 6.3 mm | Min. breaking strength: 14,000 kgf | Weight: 12.8 kg/m
DY2124 Chain type: 12 | Pitch: 152.4 mm | Roller dia.: 69.8 mm | Roller width: 40.0 mm | Pin dia.: 19.05 mm | Pin length L1/L2: 46.1/53.6 mm | Plate height: 52.9 mm | Plate thickness: 9.5 mm | Min. breaking strength: 12,500 kgf | Weight: 26.0 kg/m
DY2188 Chain type: 11 | Pitch: 101.6 mm | Roller dia.: 44.45 mm | Roller width: 33.85 mm | Pin dia.: 15.88 mm | Pin length L1/L2: 39.9/46.1 mm | Plate height: 41. mm | Plate thickness: 7.9 mm | Min. breaking strength: 11,400 kgf | Weight: 11.0 kg/m
DY2315 Chain type: 11 | Pitch: 228.6 mm | Roller dia.: 76.2 mm | Roller width: 43.0 mm | Pin dia.: 22.0 mm | Pin length L1/L2: 49.0/58.0 mm | Plate height: 63.5 mm | Plate thickness: 9.5 mm | Min. breaking strength: 28,000 kgf | Weight: 18.3 kg/m
Sugar Mill ChainsDongyang Chain
26 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Dongyang Chain Sugar Mill Bushed Roller Chain

Brand Dongyang Chain·Sugar Mill Chains

Available part numbers (26)

DY578, DY40, DY40 Hyper, DY60, DY124, DY124 Hyper, DY126, DY1131, DY2184, DY996 + 16 more — see full table ↓

How to order

Send the Dongyang Chain part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
DY578Chain type: 3 | Pitch: 66.27 mm | Roller dia.: 22.2 mm | Roller width: 27 mm | Pin dia.: 9.53 mm | Pin length L1/L2: 25/29 mm | Plate height: 25.4 mm | Plate thickness: 4 mm | Avg. tensile strength: 4,500 kgf | Weight: 1.0 kg/ft
DY40Chain type: 3 | Pitch: 78.11 mm | Roller dia.: 31.75 mm | Roller width: 38.1 mm | Pin dia.: 15.9 mm | Pin length L1/L2: 42.5/46.8 mm | Plate height: 38.1 mm | Plate thickness: 7.9 mm | Avg. tensile strength: 13,000 kgf | Weight: 3.1 kg/ft
DY40 HyperChain type: 3 | Pitch: 78.11 mm | Roller dia.: 31.75 mm | Roller width: 38.1 mm | Pin dia.: 15.7 mm | Pin length L1/L2: 46/51.6 mm | Plate height: 41.3 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 34,000 kgf | Weight: 3.8 kg/ft
DY60Chain type: 5 | Pitch: 102.6 mm | Roller dia.: 50.8 mm | Roller width: 33.3 mm | Pin dia.: 17.5 mm | Pin length L1/L2: 41.7/47.2 mm | Plate height: 38.1 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 14,900 kgf | Weight: 3.9 kg/ft | Attachments available: A1 / K1
DY124Chain type: 3 | Pitch: 103.2 mm | Roller dia.: 44.45 mm | Roller width: 49.2 mm | Pin dia.: 22.2 mm | Pin length L1/L2: 42.9/46.6 mm | Plate height: 54.0 mm | Plate thickness: 12.7 mm | Avg. tensile strength: 27,000 kgf | Weight: 7.2 kg/ft
DY124 HyperChain type: 3 | Pitch: 103.2 mm | Roller dia.: 44.45 mm | Roller width: 49.2 mm | Pin dia.: 22.2 mm | Pin length L1/L2: 64.3/73.0 mm | Plate height: 58.7 mm | Plate thickness: 15.9 mm | Avg. tensile strength: 57,000 kgf | Weight: 7.4 kg/ft
DY126Chain type: 5 | Pitch: 152.4 mm | Roller dia.: 50.8 mm | Roller width: 31.0 mm | Pin dia.: 14.3 mm | Pin length L1/L2: 34.9/38.9 mm | Plate height: 38.1 mm | Plate thickness: 6.3 mm | Avg. tensile strength: 9,500 kgf | Weight: 2.3 kg/ft | Attachments available: A22
DY1131Chain type: 5 | Pitch: 152.4 mm | Roller dia.: 76.2 mm | Roller width: 38.1 mm | Pin dia.: 19.05 mm | Pin length L1/L2: 46.8/51.6 mm | Plate height: 50.8 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 21,000 kgf | Weight: 5.7 kg/ft | Attachments available: A2 / K2 / A22
DY2184Chain type: 4 | Pitch: 152.4 mm | Roller dia.: 76.2 mm | Roller width: 34.9 mm | Pin dia.: 22.2 mm | Pin length L1/L2: 45.2/53.2 mm | Plate height: 50.8 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 21,000 kgf | Weight: 5.6 kg/ft | Attachments available: A22
DY996Chain type: 5 | Pitch: 152.4 mm | Roller dia.: 69.9 mm | Roller width: 38.1 mm | Pin dia.: 19.05 mm | Pin length L1/L2: 46.8/51.6 mm | Plate height: 50.8 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 31,700 kgf | Weight: 5.4 kg/ft | Attachments available: K2
DY960Chain type: 5 | Pitch: 152.4 mm | Roller dia.: 69.9 mm | Roller width: 38.1 mm | Pin dia.: 21.8 mm | Pin length L1/L2: 51.6/61.1 mm | Plate height: 57.2 mm | Plate thickness: 12.7 mm | Avg. tensile strength: 34,000 kgf | Weight: 9.5 kg/ft | Attachments available: K1 / K2
DY2184 hyperChain type: 4 | Pitch: 152.4 mm | Roller dia.: 76.2 mm | Roller width: 34.9 mm | Pin dia.: 22.2 mm | Pin length L1/L2: 46.6/48.8 mm | Plate height: 50.8 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 36,700 kgf | Weight: 5.8 kg/ft | Attachments available: A22
DY1796Chain type: 5 | Pitch: 152.4 mm | Roller dia.: 69.9 mm | Roller width: 38.1 mm | Pin dia.: 22.2 mm | Pin length L1/L2: 45.2/54.8 mm | Plate height: 57.2 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 38,500 kgf | Weight: 7.7 kg/ft | Attachments available: K2
DY960 HyperChain type: 5 | Pitch: 152.4 mm | Roller dia.: 69.9 mm | Roller width: 38.1 mm | Pin dia.: 21.8 mm | Pin length L1/L2: 51.6/61.1 mm | Plate height: 57.2 mm | Plate thickness: 12.7 mm | Avg. tensile strength: 43,000 kgf | Weight: 9.5 kg/ft | Attachments available: K1 / K2
DY1796 HyperChain type: 5 | Pitch: 152.4 mm | Roller dia.: 76.2 mm | Roller width: 38.1 mm | Pin dia.: 22.2 mm | Pin length L1/L2: 46.0/55.2 mm | Plate height: 57.2 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 47,600 kgf | Weight: 7.8 kg/ft | Attachments available: K2
DY800Chain type: 5 | Pitch: 203.2 mm | Roller dia.: 88.9 mm | Roller width: 46.0 mm | Pin dia.: 25.1 mm | Pin length L1/L2: 57.9/60.3 mm | Plate height: 76.2 mm | Plate thickness: 12.7 mm | Avg. tensile strength: 75,700 kgf | Weight: 9.1 kg/ft | Attachments available: K1
DY40HChain type: 8 | Pitch: 78.11 mm | Roller dia.: 31.75 mm | Roller width: 18.1 mm | Pin dia.: 15.88 mm | Pin length L1/L2: 40.05/46.65 mm | Plate height: 38.0 mm | Plate thickness: 8.0 mm | Min. breaking strength: 19,500 kgf | Weight: 10.2 kg/m
DY124HChain type: 8 | Pitch: 103.20 mm | Roller dia.: 44.45 mm | Roller width: 49.1 mm | Pin dia.: 22.23 mm | Pin length L1/L2: 57.0/66.0 mm | Plate height: 54.0 mm | Plate thickness: 12.7 mm | Min. breaking strength: 57,000 kgf | Weight: 22.4 kg/m
DY266Chain type: 8 | Pitch: 103.20 mm | Roller dia.: 44.45 mm | Roller width: 49.2 mm | Pin dia.: 22.23 mm | Pin length L1/L2: 57.0/66.0 mm | Plate height: 54.0 mm | Plate thickness: 12.7 mm | Min. breaking strength: 54,000 kgf | Weight: 22.5 kg/m
DY1113Chain type: 9 | Pitch: 102.60 mm | Roller dia.: 50.8 mm | Roller width: 37.5 mm | Pin dia.: 17.5 mm | Pin length L1/L2: 38.0/45.0 mm | Plate height: 38.1 mm | Plate thickness: 6.3 mm | Min. breaking strength: 9,500 kgf | Weight: 10.2 kg/m
DY1124Chain type: 9 | Pitch: 101.60 mm | Roller dia.: 50.8 mm | Roller width: 32.0 mm | Pin dia.: 12.7 mm | Pin length L1/L2: 37.7/42.8 mm | Plate height: 38.1 mm | Plate thickness: 7.9 mm | Min. breaking strength: 10,000 kgf | Weight: 11.0 kg/m
DY1125Chain type: 9 | Pitch: 101.60 mm | Roller dia.: 50.8 mm | Roller width: 32.6 mm | Pin dia.: 17.5 mm | Pin length L1/L2: 39.5/45.1 mm | Plate height: 44.5 mm | Plate thickness: 7.9 mm | Min. breaking strength: 15,500 kgf | Weight: 12.7 kg/m
DY1130Chain type: 9 | Pitch: 152.40 mm | Roller dia.: 63.5 mm | Roller width: 37.6 mm | Pin dia.: 19.05 mm | Pin length L1/L2: 38.5/45.6 mm | Plate height: 50.8 mm | Plate thickness: 6.3 mm | Min. breaking strength: 14,000 kgf | Weight: 12.8 kg/m
DY2124Chain type: 12 | Pitch: 152.4 mm | Roller dia.: 69.8 mm | Roller width: 40.0 mm | Pin dia.: 19.05 mm | Pin length L1/L2: 46.1/53.6 mm | Plate height: 52.9 mm | Plate thickness: 9.5 mm | Min. breaking strength: 12,500 kgf | Weight: 26.0 kg/m
DY2188Chain type: 11 | Pitch: 101.6 mm | Roller dia.: 44.45 mm | Roller width: 33.85 mm | Pin dia.: 15.88 mm | Pin length L1/L2: 39.9/46.1 mm | Plate height: 41. mm | Plate thickness: 7.9 mm | Min. breaking strength: 11,400 kgf | Weight: 11.0 kg/m
DY2315Chain type: 11 | Pitch: 228.6 mm | Roller dia.: 76.2 mm | Roller width: 43.0 mm | Pin dia.: 22.0 mm | Pin length L1/L2: 49.0/58.0 mm | Plate height: 63.5 mm | Plate thickness: 9.5 mm | Min. breaking strength: 28,000 kgf | Weight: 18.3 kg/m
