Dongyang Chain UK Type Chain for Sugar Plants

Dongyang Chain UK Type Chain for Sugar Plants

These are UK-pattern roller chains for sugar plants, offered as Type A (straight sidebar) and Type B (offset sidebar).

Key features

  • All sizes have a 101.6 mm or 152.4 mm pitch
  • A2, K2, AS2 and AS20 attachments are available depending on the chain
0904 Chain type: A | Pitch: 101.6 mm | Roller dia.: 50.8 mm | Roller width: 29.4 mm | Pin dia.: 17.5 mm | Pin length: 79.4 mm | Plate height: 44.5 mm | Plate thickness: 7.9 mm | Avg. tensile strength: 18,150 kgf | Weight: 16.07 kg/m | Attachments available: A2 / K2 / AS2 / AS20
0906 Chain type: A, B | Pitch: 152.4 mm | Roller dia.: 69.9 mm | Roller width: 36.5 mm | Pin dia.: 19.0 mm | Pin length: 95.3 mm | Plate height: 50.8 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 18,150 kgf | Weight: 16.67 kg/m | Attachments available: A2 / K2 / AS2 / AS20
09060 Chain type: A, B | Pitch: 152.4 mm | Roller dia.: 69.9 mm | Roller width: 36.5 mm | Pin dia.: 19.0 mm | Pin length: 95.3 mm | Plate height: 50.8 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 27,200 kgf | Weight: 16.67 kg/m | Attachments available: A2 / K2 / AS2 / AS20
09061 Chain type: A, B | Pitch: 152.4 mm | Roller dia.: 69.9 mm | Roller width: 36.5 mm | Pin dia.: 19.0 mm | Pin length: 95.3 mm | Plate height: 57.2 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 38,600 kgf | Weight: 17.86 kg/m | Attachments available: A2 / AS2
DY600 Chain type: B | Pitch: 152.4 mm | Roller dia.: 69.9 mm | Roller width: 36.5 mm | Pin dia.: 22.2 mm | Pin length: 100.0 mm | Plate height: 58.4 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 45,400 kgf | Attachments available: K2 (attachment chain only)
09063 Chain type: A | Pitch: 152.4 mm | Roller dia.: 76.2 mm | Roller width: 36.5 mm | Pin dia.: 22.8 mm | Pin length: 101.6 mm | Plate height: 61.9 mm | Plate thickness: 10.3 mm | Avg. tensile strength: 63,500 kgf | Attachments available: K2
Sugar Mill ChainsDongyang Chain
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Dongyang Chain UK Type Chain for Sugar Plants

Brand Dongyang Chain·Sugar Mill Chains

Available part numbers (6)

0904, 0906, 09060, 09061, DY600, 09063

How to order

Send the Dongyang Chain part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
0904Chain type: A | Pitch: 101.6 mm | Roller dia.: 50.8 mm | Roller width: 29.4 mm | Pin dia.: 17.5 mm | Pin length: 79.4 mm | Plate height: 44.5 mm | Plate thickness: 7.9 mm | Avg. tensile strength: 18,150 kgf | Weight: 16.07 kg/m | Attachments available: A2 / K2 / AS2 / AS20
0906Chain type: A, B | Pitch: 152.4 mm | Roller dia.: 69.9 mm | Roller width: 36.5 mm | Pin dia.: 19.0 mm | Pin length: 95.3 mm | Plate height: 50.8 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 18,150 kgf | Weight: 16.67 kg/m | Attachments available: A2 / K2 / AS2 / AS20
09060Chain type: A, B | Pitch: 152.4 mm | Roller dia.: 69.9 mm | Roller width: 36.5 mm | Pin dia.: 19.0 mm | Pin length: 95.3 mm | Plate height: 50.8 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 27,200 kgf | Weight: 16.67 kg/m | Attachments available: A2 / K2 / AS2 / AS20
09061Chain type: A, B | Pitch: 152.4 mm | Roller dia.: 69.9 mm | Roller width: 36.5 mm | Pin dia.: 19.0 mm | Pin length: 95.3 mm | Plate height: 57.2 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 38,600 kgf | Weight: 17.86 kg/m | Attachments available: A2 / AS2
DY600Chain type: B | Pitch: 152.4 mm | Roller dia.: 69.9 mm | Roller width: 36.5 mm | Pin dia.: 22.2 mm | Pin length: 100.0 mm | Plate height: 58.4 mm | Plate thickness: 9.5 mm | Avg. tensile strength: 45,400 kgf | Attachments available: K2 (attachment chain only)
09063Chain type: A | Pitch: 152.4 mm | Roller dia.: 76.2 mm | Roller width: 36.5 mm | Pin dia.: 22.8 mm | Pin length: 101.6 mm | Plate height: 61.9 mm | Plate thickness: 10.3 mm | Avg. tensile strength: 63,500 kgf | Attachments available: K2
