FAG JK0S Integral Tapered Roller Bearings (Sealed One Side)

FAG JK0S Integral Tapered Roller Bearings (Sealed One Side)

Single row tapered roller bearings of integral design JK0S, sealed on one side and supplied with a snap ring (BR) on the outer ring for simple axial location.

Key features

  • Non-separable integral design, sealed on one side
  • Outer ring snap ring for axial location in the housing
  • Supports combined radial and one-direction axial loads
  • Greased and ready to fit

Specifications

Brand FAG
Product type Tapered Roller Bearings
Series JK0S
Design Integral, one side sealed
Bore d 30 - 80 mm
Outside diameter D 55 - 125 mm
Source FAG Rolling Bearings HR 1 catalogue, p. 500-501
JK0S030 d: 30 mm | D: 55 mm | B: 19 mm | Cr: 38.5 kN | C0r: 46.5 kN | Snap ring: BR55
JK0S040 d: 40 mm | D: 68 mm | B: 21 mm | Cr: 53 kN | C0r: 71 kN | Snap ring: BR68
JK0S050 d: 50 mm | D: 80 mm | B: 22 mm | Cr: 64 kN | C0r: 93 kN | Snap ring: BR80
JK0S060 d: 60 mm | D: 95 mm | B: 26 mm | Cr: 82 kN | C0r: 123 kN | Snap ring: BR95
JK0S070-A d: 70 mm | D: 110 mm | B: 27 mm | Cr: 104 kN | C0r: 159 kN | Snap ring: BR110
JK0S080-A d: 80 mm | D: 125 mm | B: 30 mm | Cr: 137 kN | C0r: 211 kN | Snap ring: BR125
Tapered Roller BearingsFAG
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

FAG JK0S Integral Tapered Roller Bearings (Sealed One Side)

Brand FAG·Tapered Roller Bearings

Available part numbers (6)

JK0S030, JK0S040, JK0S050, JK0S060, JK0S070-A, JK0S080-A

How to order

Send the FAG part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
JK0S030d: 30 mm | D: 55 mm | B: 19 mm | Cr: 38.5 kN | C0r: 46.5 kN | Snap ring: BR55
JK0S040d: 40 mm | D: 68 mm | B: 21 mm | Cr: 53 kN | C0r: 71 kN | Snap ring: BR68
JK0S050d: 50 mm | D: 80 mm | B: 22 mm | Cr: 64 kN | C0r: 93 kN | Snap ring: BR80
JK0S060d: 60 mm | D: 95 mm | B: 26 mm | Cr: 82 kN | C0r: 123 kN | Snap ring: BR95
JK0S070-Ad: 70 mm | D: 110 mm | B: 27 mm | Cr: 104 kN | C0r: 159 kN | Snap ring: BR110
JK0S080-Ad: 80 mm | D: 125 mm | B: 30 mm | Cr: 137 kN | C0r: 211 kN | Snap ring: BR125
