Fuji Electric SZ Contactor Option Units (Interlock, Counter, IC Drive)

Fuji Electric SZ Contactor Option Units (Interlock, Counter, IC Drive)

Option units for New SC and NEO SC contactors: mechanical interlocks, reversing wiring kits, IC-output coil drive units, 3-phase parallel terminal plates, operation counters, phase-failure detectors and delayed release units.

Key features

  • Mechanical interlock and reversing wiring kits for building reversing contactors
  • Relay or SSR type coil drive units for PLC/IC outputs (DC24V)
  • Parallel terminal plates for single-phase resistive loads
  • Operation counters with preset alarm output
  • Delayed release units for momentary power dips

Specifications

Series New SC / NEO SC
Delayed release N-frame Rated AC100-110V or AC200-230V, 50/60Hz
Supply Separately sold part
Code format SZ- + option code (SY-F phase failure)
Coil drive input DC24V
Source Fuji Electric New SC / NEO SC contactor catalogue, p. 26-27, 42-44
SZ-RM Part: Mechanical interlock unit | Detail: - | Applies to: SC-03~N3
SZ-RW1 Part: Reversing wiring kit (main circuit) | Detail: - | Applies to: SC-03, 0
SZ-RW2 Part: Reversing wiring kit (main circuit) | Detail: - | Applies to: SC-05
SZ-RW3 Part: Reversing wiring kit (main circuit) | Detail: - | Applies to: SC-4-0, 4-1
SZ-RW4 Part: Reversing wiring kit (main circuit) | Detail: - | Applies to: SC-5-1
SZ-RW5 Part: Reversing wiring kit (main circuit) | Detail: - | Applies to: SC-N1, N2
SZ-RW6 Part: Reversing wiring kit (main circuit) | Detail: - | Applies to: SC-N2S, N3
SZ-CD1 Part: IC coil drive (relay) | Detail: DC24V 0.2W | Applies to: SC-03~5-1, SH-4, 5
SZ-CD3 Part: IC coil drive (relay) | Detail: DC24V 0.2W | Applies to: SC-N1~N3
SZ-CD5 Part: IC coil drive (relay) | Detail: DC24V 0.2W | Applies to: SC-N4~N12
SZ-03/CD2-24 Part: IC coil drive (SSR) | Detail: DC24V 0.36W | Applies to: SC-03~5-1, SH-4, 5
SZ-CD4 Part: IC coil drive (SSR) | Detail: DC24V 0.36W | Applies to: SC-N1~N3
SZ-CD6A Part: IC coil drive (SSR) | Detail: DC24V 0.36W | Applies to: SC-N4~N12
SZ-SP1 Part: 3-phase parallel terminal plate | Detail: - | Applies to: SC-03, 0, 05
SZ-SP2 Part: 3-phase parallel terminal plate | Detail: - | Applies to: SC-4-0, 4-1, 5-1
SZ-SP3 Part: 3-phase parallel terminal plate | Detail: - | Applies to: SC-N1, N2
SZ-SP4 Part: 3-phase parallel terminal plate | Detail: - | Applies to: SC-N2S, N3
SZ-SP5 Part: 3-phase parallel terminal plate | Detail: - | Applies to: SC-N4, N5
SZ-SP6 Part: 3-phase parallel terminal plate | Detail: - | Applies to: SC-N6
SZ-SP7 Part: 3-phase parallel terminal plate | Detail: - | Applies to: SC-N7
SZ-SP8 Part: 3-phase parallel terminal plate | Detail: - | Applies to: SC-N8, N10
SZ-SP9 Part: 3-phase parallel terminal plate | Detail: - | Applies to: SC-N11, N12
SZ-SP10 Part: 3-phase parallel terminal plate | Detail: - | Applies to: SC-N14
SZ-SP11 Part: 3-phase parallel terminal plate | Detail: - | Applies to: SC-N16
SZ-J Part: Operation counter | Detail: 7 digits, no output | Applies to: SC-03~N3, SH-4, 5
SZ-J1 Part: Operation counter | Detail: output at 100x10k ops | Applies to: SC-03~5-1, SH-4, 5
SZ-J2 Part: Operation counter | Detail: output at 200x10k ops | Applies to: SC-03~5-1, SH-4, 5
SZ-J3 Part: Operation counter | Detail: output at 300x10k ops | Applies to: SC-03~5-1, SH-4, 5
SZ-J4 Part: Operation counter | Detail: output at 400x10k ops | Applies to: SC-03~5-1, SH-4, 5
SZ-J5 Part: Operation counter | Detail: output at 500x10k ops | Applies to: SC-03~5-1, SH-4, 5
SZ-J6 Part: Operation counter | Detail: output at 600x10k ops | Applies to: SC-03~5-1, SH-4, 5
SZ-J7 Part: Operation counter | Detail: output at 700x10k ops | Applies to: SC-03~5-1, SH-4, 5
SZ-J8 Part: Operation counter | Detail: output at 800x10k ops | Applies to: SC-03~5-1, SH-4, 5
SY-F-A3/M Part: Phase failure detector | Detail: AC100-120V, 1c | Applies to: SC-03~N16
SY-F-A4/M Part: Phase failure detector | Detail: AC200-240V, 1c | Applies to: SC-03~N16
SZ-DE100 Part: Delayed release unit | Detail: AC100V | Applies to: SC-03/G~5-1/G, SH-4/G, 5/G
SZ-DE110 Part: Delayed release unit | Detail: AC110V | Applies to: SC-03/G~5-1/G, SH-4/G, 5/G
SZ-DE200 Part: Delayed release unit | Detail: AC200V | Applies to: SC-03/G~5-1/G, SH-4/G, 5/G
SZ-DE220 Part: Delayed release unit | Detail: AC220-230V | Applies to: SC-03/G~5-1/G, SH-4/G, 5/G
SZ-N1/GDE Part: Delayed release unit | Detail: - | Applies to: SC-N1/G, N2/G
SZ-N2S/GDE Part: Delayed release unit | Detail: - | Applies to: SC-N2S/G, N3/G
SZ-N5/DE Part: Delayed release unit | Detail: - | Applies to: SC-N4/SE, N5
SZ-N6/DE Part: Delayed release unit | Detail: - | Applies to: SC-N6, N7
SZ-N8/DE Part: Delayed release unit | Detail: - | Applies to: SC-N8, N10
SZ-N11/DE Part: Delayed release unit | Detail: - | Applies to: SC-N11, N12
SZ-N14/DE Part: Delayed release unit | Detail: - | Applies to: SC-N14
