HIWIN TMN E Low-Profile Torque Motor Tables (Encoder, 4.2-39.6 N·m)

HIWIN TMN E Low-Profile Torque Motor Tables (Encoder, 4.2-39.6 N·m)

HIWIN TMN low-profile, outer-rotating torque-motor rotary tables with optical encoder feedback (E type). Zero-backlash direct drive for indexing, inspection and assembly axes.

Key features

  • Direct drive: no gearbox, zero backlash, high rigidity
  • Integrated optical encoder
  • High positioning accuracy and repeatability
  • Ready-to-mount rotary table with bearing
  • Matched to HIWIN D1-N / D2 servo drives

Specifications

Series TMN
Type Torque motor rotary table
Feedback Optical encoder
Motor drive HIWIN servo drive (matched)
Cooling Natural convection
Source HIWIN Torque Motor (Direct Drive Motor) Technical Information MR99TE01-1510, pp.13-15
TMN42E Cont. torque: 1.4 N·m | Peak torque: 4.2 N·m | Max speed: 700 rpm
TMN71E Cont. torque: 3.7 N·m | Peak torque: 11.1 N·m | Max speed: 600 rpm
TMN93E Cont. torque: 13.2 N·m | Peak torque: 39.6 N·m | Max speed: 500 rpm
Torque MotorsHIWIN
3 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

HIWIN TMN E Low-Profile Torque Motor Tables (Encoder, 4.2-39.6 N·m)

Brand HIWIN·Torque Motors

Available part numbers (3)

TMN42E, TMN71E, TMN93E

How to order

Send the HIWIN part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
TMN42ECont. torque: 1.4 N·m | Peak torque: 4.2 N·m | Max speed: 700 rpm
TMN71ECont. torque: 3.7 N·m | Peak torque: 11.1 N·m | Max speed: 600 rpm
TMN93ECont. torque: 13.2 N·m | Peak torque: 39.6 N·m | Max speed: 500 rpm
