HIWIN TMY6 Torque Motor Rotary Tables (Peak 24-72 N·m)

HIWIN TMY6 Torque Motor Rotary Tables (Peak 24-72 N·m)

HIWIN TMY6 series torque-motor rotary tables with integrated high-resolution absolute resolver. Zero-backlash direct drive for indexing, inspection and assembly axes.

Key features

  • Direct drive: no gearbox, zero backlash, high rigidity
  • Integrated absolute resolver
  • High positioning accuracy and repeatability
  • Ready-to-mount rotary table with bearing
  • Matched to HIWIN D1-N / D2 servo drives

Specifications

Series TMY
Type Torque motor rotary table
Feedback Absolute resolver
Motor drive HIWIN servo drive (matched)
Cooling Natural convection
Source HIWIN Torque Motor (Direct Drive Motor) Technical Information MR99TE01-1510, p.10
TMY63 Cont. torque: 8 N·m | Peak torque: 24 N·m | Max speed: 300 rpm
TMY65 Cont. torque: 16 N·m | Peak torque: 48 N·m | Max speed: 300 rpm
TMY68 Cont. torque: 24 N·m | Peak torque: 72 N·m | Max speed: 300 rpm
Torque MotorsHIWIN
3 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

HIWIN TMY6 Torque Motor Rotary Tables (Peak 24-72 N·m)

Brand HIWIN·Torque Motors

Available part numbers (3)

TMY63, TMY65, TMY68

How to order

Send the HIWIN part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
TMY63Cont. torque: 8 N·m | Peak torque: 24 N·m | Max speed: 300 rpm
TMY65Cont. torque: 16 N·m | Peak torque: 48 N·m | Max speed: 300 rpm
TMY68Cont. torque: 24 N·m | Peak torque: 72 N·m | Max speed: 300 rpm
