HSG HG6 Gearheads (60 mm, 1/3-1/250, D-cut / Key Shaft)

HSG HG6 Gearheads (60 mm, 1/3-1/250, D-cut / Key Shaft)

HSG HG6 parallel-shaft gearheads for 60 mm HM6 DC motors, in 25 ratios from 1/3 to 1/250 with D-cut or keyed 8 mm output shaft.

Key features

  • Ratios 1/3 to 1/250
  • Max. permissible torque 3 N-m (30 kgf-cm)
  • 8 mm output shaft, D-cut (D) or key (K) type
  • Fits HSG HM6 gear-type (pinion) DC motors
  • Low noise and low vibration

Specifications

Frame 60 mm square
Compatible motors HSG HM6 (10-30 W)
Gear ratios 1/3-1/250
Max. torque 3 N-m (30 kgf-cm)
Output shaft 8 mm, D-cut or key
Length 31 mm (1/3-1/18), 41 mm (1/20-1/250)
Source HSG HSG DC Motor Catalog (0318EN), p.6
HG6-3D Ratio: 1/3 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-3K Ratio: 1/3 | Shaft: Key 8 mm | Frame: 60 mm
HG6-3.6D Ratio: 1/3.6 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-3.6K Ratio: 1/3.6 | Shaft: Key 8 mm | Frame: 60 mm
HG6-5D Ratio: 1/5 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-5K Ratio: 1/5 | Shaft: Key 8 mm | Frame: 60 mm
HG6-6D Ratio: 1/6 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-6K Ratio: 1/6 | Shaft: Key 8 mm | Frame: 60 mm
HG6-7.5D Ratio: 1/7.5 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-7.5K Ratio: 1/7.5 | Shaft: Key 8 mm | Frame: 60 mm
HG6-9D Ratio: 1/9 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-9K Ratio: 1/9 | Shaft: Key 8 mm | Frame: 60 mm
HG6-10D Ratio: 1/10 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-10K Ratio: 1/10 | Shaft: Key 8 mm | Frame: 60 mm
HG6-12.5D Ratio: 1/12.5 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-12.5K Ratio: 1/12.5 | Shaft: Key 8 mm | Frame: 60 mm
HG6-15D Ratio: 1/15 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-15K Ratio: 1/15 | Shaft: Key 8 mm | Frame: 60 mm
HG6-18D Ratio: 1/18 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-18K Ratio: 1/18 | Shaft: Key 8 mm | Frame: 60 mm
HG6-20D Ratio: 1/20 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-20K Ratio: 1/20 | Shaft: Key 8 mm | Frame: 60 mm
HG6-25D Ratio: 1/25 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-25K Ratio: 1/25 | Shaft: Key 8 mm | Frame: 60 mm
HG6-30D Ratio: 1/30 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-30K Ratio: 1/30 | Shaft: Key 8 mm | Frame: 60 mm
HG6-36D Ratio: 1/36 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-36K Ratio: 1/36 | Shaft: Key 8 mm | Frame: 60 mm
HG6-40D Ratio: 1/40 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-40K Ratio: 1/40 | Shaft: Key 8 mm | Frame: 60 mm
HG6-50D Ratio: 1/50 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-50K Ratio: 1/50 | Shaft: Key 8 mm | Frame: 60 mm
HG6-60D Ratio: 1/60 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-60K Ratio: 1/60 | Shaft: Key 8 mm | Frame: 60 mm
HG6-75D Ratio: 1/75 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-75K Ratio: 1/75 | Shaft: Key 8 mm | Frame: 60 mm
HG6-90D Ratio: 1/90 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-90K Ratio: 1/90 | Shaft: Key 8 mm | Frame: 60 mm
HG6-100D Ratio: 1/100 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-100K Ratio: 1/100 | Shaft: Key 8 mm | Frame: 60 mm
HG6-120D Ratio: 1/120 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-120K Ratio: 1/120 | Shaft: Key 8 mm | Frame: 60 mm
HG6-150D Ratio: 1/150 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-150K Ratio: 1/150 | Shaft: Key 8 mm | Frame: 60 mm
HG6-180D Ratio: 1/180 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-180K Ratio: 1/180 | Shaft: Key 8 mm | Frame: 60 mm
HG6-200D Ratio: 1/200 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-200K Ratio: 1/200 | Shaft: Key 8 mm | Frame: 60 mm
HG6-250D Ratio: 1/250 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-250K Ratio: 1/250 | Shaft: Key 8 mm | Frame: 60 mm
GearheadsHSG
50 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

HSG HG6 Gearheads (60 mm, 1/3-1/250, D-cut / Key Shaft)

Brand HSG·Gearheads

Available part numbers (50)

HG6-3D, HG6-3K, HG6-3.6D, HG6-3.6K, HG6-5D, HG6-5K, HG6-6D, HG6-6K, HG6-7.5D, HG6-7.5K + 40 more — see full table ↓

How to order

Send the HSG part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
HG6-3DRatio: 1/3 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-3KRatio: 1/3 | Shaft: Key 8 mm | Frame: 60 mm
HG6-3.6DRatio: 1/3.6 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-3.6KRatio: 1/3.6 | Shaft: Key 8 mm | Frame: 60 mm
HG6-5DRatio: 1/5 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-5KRatio: 1/5 | Shaft: Key 8 mm | Frame: 60 mm
HG6-6DRatio: 1/6 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-6KRatio: 1/6 | Shaft: Key 8 mm | Frame: 60 mm
HG6-7.5DRatio: 1/7.5 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-7.5KRatio: 1/7.5 | Shaft: Key 8 mm | Frame: 60 mm
HG6-9DRatio: 1/9 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-9KRatio: 1/9 | Shaft: Key 8 mm | Frame: 60 mm
HG6-10DRatio: 1/10 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-10KRatio: 1/10 | Shaft: Key 8 mm | Frame: 60 mm
HG6-12.5DRatio: 1/12.5 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-12.5KRatio: 1/12.5 | Shaft: Key 8 mm | Frame: 60 mm
HG6-15DRatio: 1/15 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-15KRatio: 1/15 | Shaft: Key 8 mm | Frame: 60 mm
HG6-18DRatio: 1/18 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-18KRatio: 1/18 | Shaft: Key 8 mm | Frame: 60 mm
HG6-20DRatio: 1/20 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-20KRatio: 1/20 | Shaft: Key 8 mm | Frame: 60 mm
HG6-25DRatio: 1/25 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-25KRatio: 1/25 | Shaft: Key 8 mm | Frame: 60 mm
HG6-30DRatio: 1/30 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-30KRatio: 1/30 | Shaft: Key 8 mm | Frame: 60 mm
HG6-36DRatio: 1/36 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-36KRatio: 1/36 | Shaft: Key 8 mm | Frame: 60 mm
HG6-40DRatio: 1/40 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-40KRatio: 1/40 | Shaft: Key 8 mm | Frame: 60 mm
HG6-50DRatio: 1/50 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-50KRatio: 1/50 | Shaft: Key 8 mm | Frame: 60 mm
HG6-60DRatio: 1/60 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-60KRatio: 1/60 | Shaft: Key 8 mm | Frame: 60 mm
HG6-75DRatio: 1/75 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-75KRatio: 1/75 | Shaft: Key 8 mm | Frame: 60 mm
HG6-90DRatio: 1/90 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-90KRatio: 1/90 | Shaft: Key 8 mm | Frame: 60 mm
HG6-100DRatio: 1/100 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-100KRatio: 1/100 | Shaft: Key 8 mm | Frame: 60 mm
HG6-120DRatio: 1/120 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-120KRatio: 1/120 | Shaft: Key 8 mm | Frame: 60 mm
HG6-150DRatio: 1/150 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-150KRatio: 1/150 | Shaft: Key 8 mm | Frame: 60 mm
HG6-180DRatio: 1/180 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-180KRatio: 1/180 | Shaft: Key 8 mm | Frame: 60 mm
HG6-200DRatio: 1/200 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-200KRatio: 1/200 | Shaft: Key 8 mm | Frame: 60 mm
HG6-250DRatio: 1/250 | Shaft: D-cut 8 mm | Frame: 60 mm
HG6-250KRatio: 1/250 | Shaft: Key 8 mm | Frame: 60 mm
