HSG HGM6 DC Geared Motors (60 mm, 10-30 W, 1/3-1/250)

HSG HGM6 DC Geared Motors (60 mm, 10-30 W, 1/3-1/250)

HSG HGM6 geared motor sets combine an HM6 60 mm 24 VDC motor with an HG6 parallel-shaft gearhead, ratios 1/3 to 1/250. Gear ratios are optimised for each motor for low noise and vibration.

Key features

  • 25 gear ratios from 1/3 to 1/250
  • Maximum permissible gearhead torque 3 N-m (30 kgf-cm)
  • Gearhead output shaft 8 mm, D-cut (HG6-( )D) or key (HG6-( )K)
  • Low noise and low vibration
  • Order motor and HG6 gearhead by ratio

Specifications

Frame 60 mm square
Motor HM6 series, 24 VDC
Output 10 W, 15 W, 30 W
Gear ratios 1/3-1/250 (25 steps)
Max. gearhead torque 3 N-m (30 kgf-cm)
Gearhead length 31 mm (1/3-1/18), 41 mm (1/20-1/250)
Gearhead HG6-( )D / HG6-( )K
Source HSG HSG DC Motor Catalog (0318EN), p.6
HGM6-1024A Motor: 10 W, 24 VDC | Gearhead: HG6-( ) | Ratio: 1/3-1/250 | Speed: 1100-13 rpm
HGM6-1524A Motor: 15 W, 24 VDC | Gearhead: HG6-( ) | Ratio: 1/3-1/250 | Speed: 1133-14 rpm
HGM6-3024A Motor: 30 W, 24 VDC | Gearhead: HG6-( ) | Ratio: 1/3-1/250 | Speed: 1133-14 rpm
DC Geared MotorsHSG
3 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

HSG HGM6 DC Geared Motors (60 mm, 10-30 W, 1/3-1/250)

Brand HSG·DC Geared Motors

Available part numbers (3)

HGM6-1024A, HGM6-1524A, HGM6-3024A

How to order

Send the HSG part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
HGM6-1024AMotor: 10 W, 24 VDC | Gearhead: HG6-( ) | Ratio: 1/3-1/250 | Speed: 1100-13 rpm
HGM6-1524AMotor: 15 W, 24 VDC | Gearhead: HG6-( ) | Ratio: 1/3-1/250 | Speed: 1133-14 rpm
HGM6-3024AMotor: 30 W, 24 VDC | Gearhead: HG6-( ) | Ratio: 1/3-1/250 | Speed: 1133-14 rpm
