Hwang Hae HAG Axial Air Gap Brake Motors (0.1-5.5 kW)

Hwang Hae HAG Axial Air Gap Brake Motors (0.1-5.5 kW)

Hwang Hae Electric HAG axial air gap (AG) brake motors: flat, pancake-style 4-pole motors with integrated brake for compact hoisting and positioning drives.

Key features

  • Axial air gap construction for a short, flat motor
  • Integrated brake with manual brake release
  • 4-pole, 0.1 to 5.5 kW
  • 200/220 V, 50/60 Hz
  • CE and UL marked, RoHS compliant per catalogue

Specifications

Construction Axial air gap brake motor
Poles 4
Output range 0.1-5.5 kW
Voltage 200 V 50/60 Hz, 220 V 60 Hz
Rated speed 1,380-1,420 rpm (50 Hz), 1,680-1,720 rpm (60 Hz)
Rating Continuous to 0.4 kW; short-time ratings on larger frames
Source Hwang Hae AG Brake Motor catalogue
HAG-15F Output: 0.1 kW, 4P | Rating: Continuous | Bearings: 6202ZZ / 6002ZZ
HAG-20F Output: 0.2 kW, 4P | Current: 1.45 A (200 V 50 Hz) | Speed: 1380/1680 rpm (50/60 Hz) | Rating: Continuous | Bearings: 6204ZZ / 6004ZZ
HAG-20D Output: 0.4 kW, 4P | Current: 2.5 A (200 V 50 Hz) | Speed: 1380/1680 rpm (50/60 Hz) | Rating: Continuous | Bearings: 6204ZZ / 6004ZZ
HAG-20D1 Output: 0.55 kW, 4P | Current: 3.8 A (200 V 50 Hz) | Speed: 1400/1680 rpm (50/60 Hz) | Rating: 30 min | Bearings: 6204ZZ / 6004ZZ
HAG-25D Output: 0.75 kW, 4P | Current: 4.8 A (200 V 50 Hz) | Speed: 1400/1690 rpm (50/60 Hz) | Rating: Continuous | Bearings: 6206ZZ / 6006ZZ
HAG-27D1 Output: 1.5 kW, 4P | Current: 8.4 A (200 V 50 Hz) | Speed: 1400/1690 rpm (50/60 Hz) | Rating: 1 h | Bearings: 6207ZZ / 6007Z
HAG-27D2 Output: 2.2 kW, 4P | Current: 14.5 A (200 V 50 Hz) | Speed: 1420/1690 rpm (50/60 Hz) | Rating: 30 min | Bearings: 6207ZZ / 6007ZZ
HAG-27D3 Output: 3.7 kW, 4P | Current: 26.0 A (200 V 50 Hz) | Speed: 1420/1700 rpm (50/60 Hz) | Rating: 15 min | Bearings: 6207ZZ / 6007ZZ
HAG-30D Output: 5.5 kW, 4P | Rating: 5 min | Bearings: 6207ZZ / 6007ZZ
Brake MotorsHwang Hae Electric
9 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Hwang Hae HAG Axial Air Gap Brake Motors (0.1-5.5 kW)

Brand Hwang Hae Electric·Brake Motors

Available part numbers (9)

HAG-15F, HAG-20F, HAG-20D, HAG-20D1, HAG-25D, HAG-27D1, HAG-27D2, HAG-27D3, HAG-30D
