Inovance AC800 Series Book-Size High-Performance Motion Controller

Inovance AC800 Series Book-Size High-Performance Motion Controller

The AC800 series is a book-size, PC-based high-performance controller for large multi-axis machines, programmed with CODESYS-based InoProShop.

Key features

  • Models range from Intel Celeron to Core i5/i7 processors with 4 GB DDR4 and 64-128 GB SSD
  • Dual EtherCAT masters synchronize up to 256 axes (32 axes at 500 µs on AC810), with PLCopen, CAM, CNC and robot motion libraries
  • EtherNet/IP, OPC UA and Modbus TCP are supported, plus RS485/RS232 Modbus RTU master/slave
  • Remote I/O is expanded over EtherCAT with GL10 and GR10 modules, and a UPS option preserves data on power failure

Specifications

Memory DDR4 4 GB
Ethernet 2x LAN (Modbus TCP, UDP, OPC UA)
Serial 1x RS485 + 1x RS232
Program / data memory 128 MB / 128 MB, 5 MB retentive (UPS)
Power supply 24 V DC
Inovance AC800 Series Book-Size High-Performance Motion Controller reference 2
AC810-0122-U0R0 CPU: Intel Core i5 | Memory: DDR4 4 GB | Storage: SSD 128 GB | EtherCAT: 2x master | Max. axes: 128 + 128 (256) | Ethernet: 2x LAN (Modbus TCP, UDP, OPC UA) | Serial: 1x RS485 + 1x RS232 | Program / data memory: 128 MB / 128 MB, 5 MB retentive (UPS) | Power supply: 24 V DC | Cooling fans: 2 long-life fans | Expansion slot: PCIe | Certification: CE
AC801-0221-U0R0 CPU: Intel Celeron 1.6 GHz | Memory: DDR4 4 GB | Storage: SSD 64 GB | EtherCAT: 1x master | Max. axes: 48 (32 axes at 1 ms sync) | Ethernet: 2x LAN (Modbus TCP, UDP, OPC UA) | Serial: 1x RS485 + 1x RS232 | Program / data memory: 128 MB / 128 MB, 5 MB retentive (UPS) | Power supply: 24 V DC | Cooling fans: None | Expansion slot: No PCI slot | Certification: CE
AC802-0222-U0R0 CPU: Intel Celeron 1.6 GHz | Memory: DDR4 4 GB | Storage: SSD 128 GB | EtherCAT: 2x master | Max. axes: 64 + 64 (128) | Ethernet: 2x LAN (Modbus TCP, UDP, OPC UA) | Serial: 1x RS485 + 1x RS232 | Program / data memory: 128 MB / 128 MB, 5 MB retentive (UPS) | Power supply: 24 V DC | Cooling fans: None | Expansion slot: PCIe | Certification: CE
AC812-0322-U0R0 CPU: Intel Core i7 2.7 GHz | Memory: DDR4 4 GB | Storage: SSD 128 GB | EtherCAT: 2x master | Max. axes: 128 + 128 (256) | Ethernet: 2x LAN (Modbus TCP, UDP, OPC UA) | Serial: 1x RS485 + 1x RS232 | Program / data memory: 128 MB / 128 MB, 5 MB retentive (UPS) | Power supply: 24 V DC | Cooling fans: 2 long-life fans | Expansion slot: PCIe
Motion ControllersInovance
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Inovance AC800 Series Book-Size High-Performance Motion Controller

Brand Inovance·Motion Controllers

Available part numbers (4)

AC810-0122-U0R0, AC801-0221-U0R0, AC802-0222-U0R0, AC812-0322-U0R0

How to order

Send the Inovance part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
Inovance AC800 Series Book-Size High-Performance Motion Controller reference 2
0 selected
RFQ List (0)
Product codeSpec
AC810-0122-U0R0CPU: Intel Core i5 | Memory: DDR4 4 GB | Storage: SSD 128 GB | EtherCAT: 2x master | Max. axes: 128 + 128 (256) | Ethernet: 2x LAN (Modbus TCP, UDP, OPC UA) | Serial: 1x RS485 + 1x RS232 | Program / data memory: 128 MB / 128 MB, 5 MB retentive (UPS) | Power supply: 24 V DC | Cooling fans: 2 long-life fans | Expansion slot: PCIe | Certification: CE
AC801-0221-U0R0CPU: Intel Celeron 1.6 GHz | Memory: DDR4 4 GB | Storage: SSD 64 GB | EtherCAT: 1x master | Max. axes: 48 (32 axes at 1 ms sync) | Ethernet: 2x LAN (Modbus TCP, UDP, OPC UA) | Serial: 1x RS485 + 1x RS232 | Program / data memory: 128 MB / 128 MB, 5 MB retentive (UPS) | Power supply: 24 V DC | Cooling fans: None | Expansion slot: No PCI slot | Certification: CE
AC802-0222-U0R0CPU: Intel Celeron 1.6 GHz | Memory: DDR4 4 GB | Storage: SSD 128 GB | EtherCAT: 2x master | Max. axes: 64 + 64 (128) | Ethernet: 2x LAN (Modbus TCP, UDP, OPC UA) | Serial: 1x RS485 + 1x RS232 | Program / data memory: 128 MB / 128 MB, 5 MB retentive (UPS) | Power supply: 24 V DC | Cooling fans: None | Expansion slot: PCIe | Certification: CE
AC812-0322-U0R0CPU: Intel Core i7 2.7 GHz | Memory: DDR4 4 GB | Storage: SSD 128 GB | EtherCAT: 2x master | Max. axes: 128 + 128 (256) | Ethernet: 2x LAN (Modbus TCP, UDP, OPC UA) | Serial: 1x RS485 + 1x RS232 | Program / data memory: 128 MB / 128 MB, 5 MB retentive (UPS) | Power supply: 24 V DC | Cooling fans: 2 long-life fans | Expansion slot: PCIe
