Inovance AC703 ICP Motion Controller

Inovance AC703 ICP Motion Controller

The AC703 is a compact, fanless industrial PC-based motion controller running CODESYS-based InoProShop on Linux/RT.

Key features

  • Its EtherCAT master controls 32 axes at a 1 ms cycle and up to 128 slave stations, including GR10, GL10 and GL20 remote I/O
  • PLCopen, CAM, CNC and robot motion components are supported, programmed in ST, LD, SFC and CFC
  • Two Gigabit Ethernet ports provide EtherNet/IP, OPC UA and Modbus TCP, and a built-in Webvisu server enables remote commissioning and IIoT functions
  • Built-in safe shutdown stores registers in non-volatile memory on power loss

Specifications

CPU Intel J1900, 2.0 GHz
Memory 4 GB DDR3, 64 GB mSATA SSD, 64 MB SPI flash
EtherCAT 1x master, 32 axes at 1 ms, max. 128 stations
Ethernet 2x Gigabit (EtherNet/IP, OPC UA server, Modbus TCP)
Serial 1x RS485, 1x RS232
DI/DO 8 high-speed DI (200 kHz) / 4 high-speed DO (200 kHz)
OS Linux/RT
Power supply 24 V DC (-15% to +20%)
Cooling Fanless
Operating temperature -5 to 55 °C
Dimensions H x W x D 160 x 55 x 147 mm
Mass 1.3 kg
Inovance AC703 ICP Motion Controller reference 2
AC703 CPU: Intel J1900, 2.0 GHz | Memory: 4 GB DDR3, 64 GB mSATA SSD, 64 MB SPI flash | EtherCAT: 1x master, 32 axes at 1 ms, max. 128 stations | Ethernet: 2x Gigabit (EtherNet/IP, OPC UA server, Modbus TCP) | Serial: 1x RS485, 1x RS232 | DI/DO: 8 high-speed DI (200 kHz) / 4 high-speed DO (200 kHz) | OS: Linux/RT | Power supply: 24 V DC (-15% to +20%) | Cooling: Fanless | Operating temperature: -5 to 55 °C | Dimensions H x W x D: 160 x 55 x 147 mm | Mass: 1.3 kg
