Inovance SV660F Series PROFINET Servo Drive (INT, 0.2-7.5 kW)

Inovance SV660F Series PROFINET Servo Drive (INT, 0.2-7.5 kW)

SV660F-INT general-purpose AC servo drive with PROFINET communication for MS1 23-bit servo motors.

Key features

  • 23-bit multi-turn absolute encoder support with MS1-R motors
  • 3.0 kHz speed loop bandwidth
  • PROFIdrive telegrams 1, 2, 3, 102, 105, 111, 750 (SV660F)
  • STO (SIL3) selectable on SV660F
  • Frame sizes A to E, 0.2 kW to 7.5 kW

Specifications

Series SV660 general-purpose servo drive
Command interface PROFINET RT/IRT (PROFIdrive)
Encoder support 23-bit multi-turn absolute (MS1)
Speed loop bandwidth 3.0 kHz
Voltage classes S: 200-240 V, T: 380-440 V
Mounting I: base-mounted
Power range 0.2-7.5 kW
Source Inovance SV660-INT 19120591 A02, p. 1-2; Servo System Overview 19120627 A00, p. 11-12
SV660FS1R6I-INT Rated power: 0.2 kW | Rated current: 1.6 A | Max current: 5.8 A | Input: 1-ph 200-240 V | Frame: Size A | Variant: International
SV660FS1R6I-FS-INT Rated power: 0.2 kW | Rated current: 1.6 A | Max current: 5.8 A | Input: 1-ph 200-240 V | Frame: Size A | Variant: International, with STO
SV660FS2R8I-INT Rated power: 0.4 kW | Rated current: 2.8 A | Max current: 10.1 A | Input: 1-ph 200-240 V | Frame: Size A | Variant: International
SV660FS2R8I-FS-INT Rated power: 0.4 kW | Rated current: 2.8 A | Max current: 10.1 A | Input: 1-ph 200-240 V | Frame: Size A | Variant: International, with STO
SV660FS5R5I-INT Rated power: 0.75 kW | Rated current: 5.5 A | Max current: 16.9 A | Input: 1-ph 200-240 V | Frame: Size B | Variant: International
SV660FS5R5I-FS-INT Rated power: 0.75 kW | Rated current: 5.5 A | Max current: 16.9 A | Input: 1-ph 200-240 V | Frame: Size B | Variant: International, with STO
SV660FS7R6I-INT Rated power: 1.0 kW | Rated current: 7.6 A | Max current: 23.0 A | Input: 1/3-ph 200-240 V | Frame: Size C | Variant: International
SV660FS7R6I-FS-INT Rated power: 1.0 kW | Rated current: 7.6 A | Max current: 23.0 A | Input: 1/3-ph 200-240 V | Frame: Size C | Variant: International, with STO
SV660FS012I-INT Rated power: 1.5 kW | Rated current: 11.6 A | Max current: 32.0 A | Input: 1/3-ph 200-240 V | Frame: Size D | Variant: International
SV660FS012I-FS-INT Rated power: 1.5 kW | Rated current: 11.6 A | Max current: 32.0 A | Input: 1/3-ph 200-240 V | Frame: Size D | Variant: International, with STO
SV660FT3R5I-INT Rated power: 1.0 kW | Rated current: 3.5 A | Max current: 11.0 A | Input: 3-ph 380-440 V | Frame: Size C | Variant: International
SV660FT3R5I-FS-INT Rated power: 1.0 kW | Rated current: 3.5 A | Max current: 11.0 A | Input: 3-ph 380-440 V | Frame: Size C | Variant: International, with STO
SV660FT5R4I-INT Rated power: 1.5 kW | Rated current: 5.4 A | Max current: 14.0 A | Input: 3-ph 380-440 V | Frame: Size C | Variant: International
SV660FT5R4I-FS-INT Rated power: 1.5 kW | Rated current: 5.4 A | Max current: 14.0 A | Input: 3-ph 380-440 V | Frame: Size C | Variant: International, with STO
SV660FT8R4I-INT Rated power: 2.0 kW | Rated current: 8.4 A | Max current: 20.0 A | Input: 3-ph 380-440 V | Frame: Size D | Variant: International
SV660FT8R4I-FS-INT Rated power: 2.0 kW | Rated current: 8.4 A | Max current: 20.0 A | Input: 3-ph 380-440 V | Frame: Size D | Variant: International, with STO
SV660FT012I-INT Rated power: 3.0 kW | Rated current: 11.9 A | Max current: 29.75 A | Input: 3-ph 380-440 V | Frame: Size D | Variant: International
SV660FT012I-FS-INT Rated power: 3.0 kW | Rated current: 11.9 A | Max current: 29.75 A | Input: 3-ph 380-440 V | Frame: Size D | Variant: International, with STO
SV660FT017I-INT Rated power: 5.0 kW | Rated current: 16.5 A | Max current: 41.25 A | Input: 3-ph 380-440 V | Frame: Size E | Variant: International
SV660FT017I-FS-INT Rated power: 5.0 kW | Rated current: 16.5 A | Max current: 41.25 A | Input: 3-ph 380-440 V | Frame: Size E | Variant: International, with STO
SV660FT021I-INT Rated power: 6.0 kW | Rated current: 20.8 A | Max current: 52.12 A | Input: 3-ph 380-440 V | Frame: Size E | Variant: International
SV660FT021I-FS-INT Rated power: 6.0 kW | Rated current: 20.8 A | Max current: 52.12 A | Input: 3-ph 380-440 V | Frame: Size E | Variant: International, with STO
SV660FT026I-INT Rated power: 7.5 kW | Rated current: 25.7 A | Max current: 64.25 A | Input: 3-ph 380-440 V | Frame: Size E | Variant: International
SV660FT026I-FS-INT Rated power: 7.5 kW | Rated current: 25.7 A | Max current: 64.25 A | Input: 3-ph 380-440 V | Frame: Size E | Variant: International, with STO
Servo DrivesInovance
24 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Inovance SV660F Series PROFINET Servo Drive (INT, 0.2-7.5 kW)

Brand Inovance·Servo Drives

Available part numbers (24)

SV660FS1R6I-INT, SV660FS1R6I-FS-INT, SV660FS2R8I-INT, SV660FS2R8I-FS-INT, SV660FS5R5I-INT, SV660FS5R5I-FS-INT, SV660FS7R6I-INT, SV660FS7R6I-FS-INT, SV660FS012I-INT, SV660FS012I-FS-INT + 14 more — see full table ↓

How to order

Send the Inovance part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SV660FS1R6I-INTRated power: 0.2 kW | Rated current: 1.6 A | Max current: 5.8 A | Input: 1-ph 200-240 V | Frame: Size A | Variant: International
SV660FS1R6I-FS-INTRated power: 0.2 kW | Rated current: 1.6 A | Max current: 5.8 A | Input: 1-ph 200-240 V | Frame: Size A | Variant: International, with STO
SV660FS2R8I-INTRated power: 0.4 kW | Rated current: 2.8 A | Max current: 10.1 A | Input: 1-ph 200-240 V | Frame: Size A | Variant: International
SV660FS2R8I-FS-INTRated power: 0.4 kW | Rated current: 2.8 A | Max current: 10.1 A | Input: 1-ph 200-240 V | Frame: Size A | Variant: International, with STO
SV660FS5R5I-INTRated power: 0.75 kW | Rated current: 5.5 A | Max current: 16.9 A | Input: 1-ph 200-240 V | Frame: Size B | Variant: International
SV660FS5R5I-FS-INTRated power: 0.75 kW | Rated current: 5.5 A | Max current: 16.9 A | Input: 1-ph 200-240 V | Frame: Size B | Variant: International, with STO
SV660FS7R6I-INTRated power: 1.0 kW | Rated current: 7.6 A | Max current: 23.0 A | Input: 1/3-ph 200-240 V | Frame: Size C | Variant: International
SV660FS7R6I-FS-INTRated power: 1.0 kW | Rated current: 7.6 A | Max current: 23.0 A | Input: 1/3-ph 200-240 V | Frame: Size C | Variant: International, with STO
SV660FS012I-INTRated power: 1.5 kW | Rated current: 11.6 A | Max current: 32.0 A | Input: 1/3-ph 200-240 V | Frame: Size D | Variant: International
SV660FS012I-FS-INTRated power: 1.5 kW | Rated current: 11.6 A | Max current: 32.0 A | Input: 1/3-ph 200-240 V | Frame: Size D | Variant: International, with STO
SV660FT3R5I-INTRated power: 1.0 kW | Rated current: 3.5 A | Max current: 11.0 A | Input: 3-ph 380-440 V | Frame: Size C | Variant: International
SV660FT3R5I-FS-INTRated power: 1.0 kW | Rated current: 3.5 A | Max current: 11.0 A | Input: 3-ph 380-440 V | Frame: Size C | Variant: International, with STO
SV660FT5R4I-INTRated power: 1.5 kW | Rated current: 5.4 A | Max current: 14.0 A | Input: 3-ph 380-440 V | Frame: Size C | Variant: International
SV660FT5R4I-FS-INTRated power: 1.5 kW | Rated current: 5.4 A | Max current: 14.0 A | Input: 3-ph 380-440 V | Frame: Size C | Variant: International, with STO
SV660FT8R4I-INTRated power: 2.0 kW | Rated current: 8.4 A | Max current: 20.0 A | Input: 3-ph 380-440 V | Frame: Size D | Variant: International
SV660FT8R4I-FS-INTRated power: 2.0 kW | Rated current: 8.4 A | Max current: 20.0 A | Input: 3-ph 380-440 V | Frame: Size D | Variant: International, with STO
SV660FT012I-INTRated power: 3.0 kW | Rated current: 11.9 A | Max current: 29.75 A | Input: 3-ph 380-440 V | Frame: Size D | Variant: International
SV660FT012I-FS-INTRated power: 3.0 kW | Rated current: 11.9 A | Max current: 29.75 A | Input: 3-ph 380-440 V | Frame: Size D | Variant: International, with STO
SV660FT017I-INTRated power: 5.0 kW | Rated current: 16.5 A | Max current: 41.25 A | Input: 3-ph 380-440 V | Frame: Size E | Variant: International
SV660FT017I-FS-INTRated power: 5.0 kW | Rated current: 16.5 A | Max current: 41.25 A | Input: 3-ph 380-440 V | Frame: Size E | Variant: International, with STO
SV660FT021I-INTRated power: 6.0 kW | Rated current: 20.8 A | Max current: 52.12 A | Input: 3-ph 380-440 V | Frame: Size E | Variant: International
SV660FT021I-FS-INTRated power: 6.0 kW | Rated current: 20.8 A | Max current: 52.12 A | Input: 3-ph 380-440 V | Frame: Size E | Variant: International, with STO
SV660FT026I-INTRated power: 7.5 kW | Rated current: 25.7 A | Max current: 64.25 A | Input: 3-ph 380-440 V | Frame: Size E | Variant: International
SV660FT026I-FS-INTRated power: 7.5 kW | Rated current: 25.7 A | Max current: 64.25 A | Input: 3-ph 380-440 V | Frame: Size E | Variant: International, with STO
