ISSOKU SGIR High-Speed Ground Ball Screws C5

ISSOKU SGIR High-Speed Ground Ball Screws C5

High-speed inside-return ground ball screws in grade C5, stock items with unmachined ends.

Key features

  • Nut types: SGIR (high-speed ground)
  • Shaft diameters 15-25 mm
  • Codes include shaft length; stock standard lengths as listed
  • Axial clearance symbols as printed per size (T/Z, S/N or M2)
  • Lapped ball tracks for smooth, quiet running

Specifications

Accuracy standard JIS B 1192
Clearance T
Brand ISSOKU
Product type Ball Screws
Series SGIR
Designations listed 27
Units mm, kN
Source ISSOKU Ball Screw catalogue (HANSAN edition), p. 269-275
SGIR1520TC5T-0650 Size: 15 x 20 mm | Shaft length: 650 mm | Stroke: 500 mm | Ca: 4.36 kN | C0a: 7.67 kN
SGIR1520TC5T-0850 Size: 15 x 20 mm | Shaft length: 850 mm | Stroke: 700 mm | Ca: 4.36 kN | C0a: 7.67 kN
SGIR1520TC5T-1050 Size: 15 x 20 mm | Shaft length: 1050 mm | Stroke: 900 mm | Ca: 4.36 kN | C0a: 7.67 kN
SGIR1520TC5T-1250 Size: 15 x 20 mm | Shaft length: 1250 mm | Stroke: 1100 mm | Ca: 4.36 kN | C0a: 7.67 kN
SGIR1520TC5T-1450 Size: 15 x 20 mm | Shaft length: 1450 mm | Stroke: 1300 mm | Ca: 4.36 kN | C0a: 7.67 kN
SGIR1530TC5T-0650 Size: 15 x 30 mm | Shaft length: 650 mm | Stroke: 470 mm | Ca: 4.26 kN | C0a: 7.96 kN
SGIR1530TC5T-0950 Size: 15 x 30 mm | Shaft length: 950 mm | Stroke: 770 mm | Ca: 4.26 kN | C0a: 7.96 kN
SGIR1530TC5T-1250 Size: 15 x 30 mm | Shaft length: 1250 mm | Stroke: 1070 mm | Ca: 4.26 kN | C0a: 7.96 kN
SGIR1530TC5T-1550 Size: 15 x 30 mm | Shaft length: 1550 mm | Stroke: 1370 mm | Ca: 4.26 kN | C0a: 7.96 kN
SGIR2020TC5T-0900 Size: 20 x 20 mm | Shaft length: 900 mm | Stroke: 730 mm | Ca: 5.23 kN | C0a: 10.6 kN
SGIR2020TC5T-1300 Size: 20 x 20 mm | Shaft length: 1300 mm | Stroke: 1130 mm | Ca: 5.23 kN | C0a: 10.6 kN
SGIR2020TC5T-1700 Size: 20 x 20 mm | Shaft length: 1700 mm | Stroke: 1530 mm | Ca: 5.23 kN | C0a: 10.6 kN
SGIR2020TC5T-2100 Size: 20 x 20 mm | Shaft length: 2100 mm | Stroke: 1930 mm | Ca: 5.23 kN | C0a: 10.6 kN
SGIR2030TC5T-0900 Size: 20 x 30 mm | Shaft length: 900 mm | Stroke: 730 mm | Ca: 5.23 kN | C0a: 10.6 kN
SGIR2030TC5T-1300 Size: 20 x 30 mm | Shaft length: 1300 mm | Stroke: 1130 mm | Ca: 5.23 kN | C0a: 10.6 kN
SGIR2030TC5T-1700 Size: 20 x 30 mm | Shaft length: 1700 mm | Stroke: 1530 mm | Ca: 5.23 kN | C0a: 10.6 kN
SGIR2030TC5T-2100 Size: 20 x 30 mm | Shaft length: 2100 mm | Stroke: 1930 mm | Ca: 5.23 kN | C0a: 10.6 kN
SGIR2040TC5T-1100 Size: 20 x 40 mm | Shaft length: 1100 mm | Stroke: 870 mm | Ca: 5.44 kN | C0a: 12.5 kN
SGIR2040TC5T-1500 Size: 20 x 40 mm | Shaft length: 1500 mm | Stroke: 1270 mm | Ca: 5.44 kN | C0a: 12.5 kN
SGIR2040TC5T-1900 Size: 20 x 40 mm | Shaft length: 1900 mm | Stroke: 1670 mm | Ca: 5.44 kN | C0a: 12.5 kN
SGIR2040TC5T-2100 Size: 20 x 40 mm | Shaft length: 2100 mm | Stroke: 1870 mm | Ca: 5.44 kN | C0a: 12.5 kN
SGIR2520TC5T-1100 Size: 25 x 20 mm | Shaft length: 1100 mm | Stroke: 910 mm | Ca: 5.89 kN | C0a: 13.5 kN
SGIR2520TC5T-1600 Size: 25 x 20 mm | Shaft length: 1600 mm | Stroke: 1410 mm | Ca: 5.89 kN | C0a: 13.5 kN
SGIR2520TC5T-2100 Size: 25 x 20 mm | Shaft length: 2100 mm | Stroke: 1910 mm | Ca: 5.89 kN | C0a: 13.5 kN
SGIR2550TC5T-1100 Size: 25 x 50 mm | Shaft length: 1100 mm | Stroke: 830 mm | Ca: 5.33 kN | C0a: 13.2 kN
SGIR2550TC5T-1600 Size: 25 x 50 mm | Shaft length: 1600 mm | Stroke: 1330 mm | Ca: 5.33 kN | C0a: 13.2 kN
SGIR2550TC5T-2100 Size: 25 x 50 mm | Shaft length: 2100 mm | Stroke: 1830 mm | Ca: 5.33 kN | C0a: 13.2 kN
Ball ScrewsISSOKU
27 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

ISSOKU SGIR High-Speed Ground Ball Screws C5

Brand ISSOKU·Ball Screws

Available part numbers (27)

SGIR1520TC5T-0650, SGIR1520TC5T-0850, SGIR1520TC5T-1050, SGIR1520TC5T-1250, SGIR1520TC5T-1450, SGIR1530TC5T-0650, SGIR1530TC5T-0950, SGIR1530TC5T-1250, SGIR1530TC5T-1550, SGIR2020TC5T-0900 + 17 more — see full table ↓

How to order

Send the ISSOKU part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SGIR1520TC5T-0650Size: 15 x 20 mm | Shaft length: 650 mm | Stroke: 500 mm | Ca: 4.36 kN | C0a: 7.67 kN
SGIR1520TC5T-0850Size: 15 x 20 mm | Shaft length: 850 mm | Stroke: 700 mm | Ca: 4.36 kN | C0a: 7.67 kN
SGIR1520TC5T-1050Size: 15 x 20 mm | Shaft length: 1050 mm | Stroke: 900 mm | Ca: 4.36 kN | C0a: 7.67 kN
SGIR1520TC5T-1250Size: 15 x 20 mm | Shaft length: 1250 mm | Stroke: 1100 mm | Ca: 4.36 kN | C0a: 7.67 kN
SGIR1520TC5T-1450Size: 15 x 20 mm | Shaft length: 1450 mm | Stroke: 1300 mm | Ca: 4.36 kN | C0a: 7.67 kN
SGIR1530TC5T-0650Size: 15 x 30 mm | Shaft length: 650 mm | Stroke: 470 mm | Ca: 4.26 kN | C0a: 7.96 kN
SGIR1530TC5T-0950Size: 15 x 30 mm | Shaft length: 950 mm | Stroke: 770 mm | Ca: 4.26 kN | C0a: 7.96 kN
SGIR1530TC5T-1250Size: 15 x 30 mm | Shaft length: 1250 mm | Stroke: 1070 mm | Ca: 4.26 kN | C0a: 7.96 kN
SGIR1530TC5T-1550Size: 15 x 30 mm | Shaft length: 1550 mm | Stroke: 1370 mm | Ca: 4.26 kN | C0a: 7.96 kN
SGIR2020TC5T-0900Size: 20 x 20 mm | Shaft length: 900 mm | Stroke: 730 mm | Ca: 5.23 kN | C0a: 10.6 kN
SGIR2020TC5T-1300Size: 20 x 20 mm | Shaft length: 1300 mm | Stroke: 1130 mm | Ca: 5.23 kN | C0a: 10.6 kN
SGIR2020TC5T-1700Size: 20 x 20 mm | Shaft length: 1700 mm | Stroke: 1530 mm | Ca: 5.23 kN | C0a: 10.6 kN
SGIR2020TC5T-2100Size: 20 x 20 mm | Shaft length: 2100 mm | Stroke: 1930 mm | Ca: 5.23 kN | C0a: 10.6 kN
SGIR2030TC5T-0900Size: 20 x 30 mm | Shaft length: 900 mm | Stroke: 730 mm | Ca: 5.23 kN | C0a: 10.6 kN
SGIR2030TC5T-1300Size: 20 x 30 mm | Shaft length: 1300 mm | Stroke: 1130 mm | Ca: 5.23 kN | C0a: 10.6 kN
SGIR2030TC5T-1700Size: 20 x 30 mm | Shaft length: 1700 mm | Stroke: 1530 mm | Ca: 5.23 kN | C0a: 10.6 kN
SGIR2030TC5T-2100Size: 20 x 30 mm | Shaft length: 2100 mm | Stroke: 1930 mm | Ca: 5.23 kN | C0a: 10.6 kN
SGIR2040TC5T-1100Size: 20 x 40 mm | Shaft length: 1100 mm | Stroke: 870 mm | Ca: 5.44 kN | C0a: 12.5 kN
SGIR2040TC5T-1500Size: 20 x 40 mm | Shaft length: 1500 mm | Stroke: 1270 mm | Ca: 5.44 kN | C0a: 12.5 kN
SGIR2040TC5T-1900Size: 20 x 40 mm | Shaft length: 1900 mm | Stroke: 1670 mm | Ca: 5.44 kN | C0a: 12.5 kN
SGIR2040TC5T-2100Size: 20 x 40 mm | Shaft length: 2100 mm | Stroke: 1870 mm | Ca: 5.44 kN | C0a: 12.5 kN
SGIR2520TC5T-1100Size: 25 x 20 mm | Shaft length: 1100 mm | Stroke: 910 mm | Ca: 5.89 kN | C0a: 13.5 kN
SGIR2520TC5T-1600Size: 25 x 20 mm | Shaft length: 1600 mm | Stroke: 1410 mm | Ca: 5.89 kN | C0a: 13.5 kN
SGIR2520TC5T-2100Size: 25 x 20 mm | Shaft length: 2100 mm | Stroke: 1910 mm | Ca: 5.89 kN | C0a: 13.5 kN
SGIR2550TC5T-1100Size: 25 x 50 mm | Shaft length: 1100 mm | Stroke: 830 mm | Ca: 5.33 kN | C0a: 13.2 kN
SGIR2550TC5T-1600Size: 25 x 50 mm | Shaft length: 1600 mm | Stroke: 1330 mm | Ca: 5.33 kN | C0a: 13.2 kN
SGIR2550TC5T-2100Size: 25 x 50 mm | Shaft length: 2100 mm | Stroke: 1830 mm | Ca: 5.33 kN | C0a: 13.2 kN
