JIB SALP2 Pillow Block Units (Light Series, Eccentric Collar)

JIB SALP2 pillow block units combine a pressed steel pillow block (LP) housing with a SA eccentric locking collar insert bearing. Shaft sizes and housing designations follow the JIB dimension tables.

Key features

Pressed steel pillow block (LP) housing with SA eccentric-collar insert
Fitted with SA eccentric locking collar insert bearing
Compact light-duty unit for conveyors, agricultural and general machinery
Pre-greased, sealed deep groove ball bearing insert
Metric and inch shaft sizes as listed (inch sizes marked with -dash numbers in 1/16 in)

Specifications

Product	Mounted ball bearing unit (pillow block unit)
Unit series	SALP2
Housing	pressed steel pillow block (LP) housing
Insert bearing	SA eccentric locking collar insert bearing
Codes	20 sizes
Source	JIB Ball Bearing Units catalogue, p. 100

SALP201		Shaft: 12 mm \| Bearing: SA201 \| Housing: LP203 \| Mass: 0.39 kg
SALP201-8		Shaft: 1/2 in \| Bearing: SA201-8 \| Housing: LP203 \| Mass: 0.39 kg
SALP202		Shaft: 15 mm \| Bearing: SA202 \| Housing: LP203 \| Mass: 0.39 kg
SALP202-10		Shaft: 5/8 in \| Bearing: SA202-10 \| Housing: LP203 \| Mass: 0.39 kg
SALP203		Shaft: 17 mm \| Bearing: SA203 \| Housing: LP203 \| Mass: 0.39 kg
SALP204-12		Shaft: 3/4 in \| Bearing: SA204-12 \| Housing: LP204 \| Mass: 0.51 kg
SALP204		Shaft: 20 mm \| Bearing: SA204 \| Housing: LP204 \| Mass: 0.51 kg
SALP205-14		Shaft: 7/8 in \| Bearing: SA205-14 \| Housing: LP205 \| Mass: 0.61 kg
SALP205		Shaft: 25 mm \| Bearing: SA205 \| Housing: LP205 \| Mass: 0.61 kg
SALP205-16		Shaft: 1 in \| Bearing: SA205-16 \| Housing: LP205 \| Mass: 0.61 kg
SALP206-18		Shaft: 1-1/8 in \| Bearing: SA206-18 \| Housing: LP206 \| Mass: 0.72 kg
SALP206		Shaft: 30 mm \| Bearing: SA206 \| Housing: LP206 \| Mass: 0.72 kg
SALP206-19		Shaft: 1-3/16 in \| Bearing: SA206-19 \| Housing: LP206 \| Mass: 0.72 kg
SALP206-20		Shaft: 1-1/4 in \| Bearing: SA206-20 \| Housing: LP206 \| Mass: 0.72 kg
SALP207-20		Shaft: 1-1/4 in \| Bearing: SA207-20 \| Housing: LP207 \| Mass: 1.02 kg
SALP207-22		Shaft: 1-3/8 in \| Bearing: SA207-22 \| Housing: LP207 \| Mass: 1.02 kg
SALP207		Shaft: 35 mm \| Bearing: SA207 \| Housing: LP207 \| Mass: 1.02 kg
SALP207-23		Shaft: 1-7/16 in \| Bearing: SA207-23 \| Housing: LP207 \| Mass: 1.02 kg
SALP208-24		Shaft: 1-1/2 in \| Bearing: SA208-24 \| Housing: LP208 \| Mass: 1.87 kg
SALP208		Shaft: 40 mm \| Bearing: SA208 \| Housing: LP208 \| Mass: 1.87 kg

Mounted Bearing UnitsJIB

20 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

JIB SALP2 Pillow Block Units (Light Series, Eccentric Collar)

Brand JIB·Mounted Bearing Units

Available part numbers (20)

SALP201, SALP201-8, SALP202, SALP202-10, SALP203, SALP204-12, SALP204, SALP205-14, SALP205, SALP205-16 + 10 more — see full table ↓

How to order

Send the JIB part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
