JIB UCFCC2 Round Flange Units (Light Series, Set Screw)

JIB UCFCC2 Round Flange Units (Light Series, Set Screw)

JIB UCFCC2 round flange units combine a compact round flange cartridge (FCC) housing with a UC set-screw insert bearing. Shaft sizes and housing designations follow the JIB dimension tables.

Key features

  • Compact round flange cartridge (FCC) housing
  • Fitted with UC set-screw insert bearing
  • Self-aligning spherical outside diameter compensates for shaft misalignment
  • Pre-greased, sealed deep groove ball bearing insert
  • Metric and inch shaft sizes as listed (inch sizes marked with -dash numbers in 1/16 in)

Specifications

Product Mounted ball bearing unit (round flange unit)
Unit series UCFCC2
Housing compact round flange cartridge (FCC) housing
Insert bearing UC set-screw insert bearing
Codes 38 sizes
Source JIB Ball Bearing Units catalogue, p. 64
UCFCC201 Shaft: 12 mm | Bearing: UC201 | Housing: FCC204 | Mass: 0.54 kg
UCFCC201-8 Shaft: 1/2 in | Bearing: UC201-8 | Housing: FCC204 | Mass: 0.54 kg
UCFCC202 Shaft: 15 mm | Bearing: UC202 | Housing: FCC204 | Mass: 0.54 kg
UCFCC202-10 Shaft: 5/8 in | Bearing: UC202-10 | Housing: FCC204 | Mass: 0.54 kg
UCFCC203 Shaft: 17 mm | Bearing: UC203 | Housing: FCC204 | Mass: 0.54 kg
UCFCC204-12 Shaft: 3/4 in | Bearing: UC204-12 | Housing: FCC204 | Mass: 0.54 kg
UCFCC204 Shaft: 20 mm | Bearing: UC204 | Housing: FCC204 | Mass: 0.54 kg
UCFCC205-14 Shaft: 7/8 in | Bearing: UC205-14 | Housing: FCC205 | Mass: 0.78 kg
UCFCC205-15 Shaft: 15/16 in | Bearing: UC205-15 | Housing: FCC205 | Mass: 0.78 kg
UCFCC205 Shaft: 25 mm | Bearing: UC205 | Housing: FCC205 | Mass: 0.78 kg
UCFCC205-16 Shaft: 1 in | Bearing: UC205-16 | Housing: FCC205 | Mass: 0.78 kg
UCFCC206-18 Shaft: 1-1/8 in | Bearing: UC206-18 | Housing: FCC206 | Mass: 0.96 kg
UCFCC206 Shaft: 30 mm | Bearing: UC206 | Housing: FCC206 | Mass: 0.96 kg
UCFCC206-19 Shaft: 1-3/16 in | Bearing: UC206-19 | Housing: FCC206 | Mass: 0.96 kg
UCFCC206-20 Shaft: 1-1/4 in | Bearing: UC206-20 | Housing: FCC206 | Mass: 0.96 kg
UCFCC207-20 Shaft: 1-1/4 in | Bearing: UC207-20 | Housing: FCC207 | Mass: 1.24 kg
UCFCC207-21 Shaft: 1-5/16 in | Bearing: UC207-21 | Housing: FCC207 | Mass: 1.24 kg
UCFCC207-22 Shaft: 1-3/8 in | Bearing: UC207-22 | Housing: FCC207 | Mass: 1.24 kg
UCFCC207 Shaft: 35 mm | Bearing: UC207 | Housing: FCC207 | Mass: 1.24 kg
UCFCC207-23 Shaft: 1-7/16 in | Bearing: UC207-23 | Housing: FCC207 | Mass: 1.24 kg
UCFCC208-24 Shaft: 1-1/2 in | Bearing: UC208-24 | Housing: FCC208 | Mass: 1.66 kg
UCFCC208-25 Shaft: 1-9/16 in | Bearing: UC208-25 | Housing: FCC208 | Mass: 1.66 kg
UCFCC208 Shaft: 40 mm | Bearing: UC208 | Housing: FCC208 | Mass: 1.66 kg
UCFCC209-26 Shaft: 1-5/8 in | Bearing: UC209-26 | Housing: FCC209 | Mass: 2.08 kg
UCFCC209-27 Shaft: 1-11/16 in | Bearing: UC209-27 | Housing: FCC209 | Mass: 2.08 kg
UCFCC209-28 Shaft: 1-3/4 in | Bearing: UC209-28 | Housing: FCC209 | Mass: 2.08 kg
UCFCC209 Shaft: 45 mm | Bearing: UC209 | Housing: FCC209 | Mass: 2.08 kg
UCFCC210-30 Shaft: 1-7/8 in | Bearing: UC210-30 | Housing: FCC210 | Mass: 2.24 kg
UCFCC210-31 Shaft: 1-15/16 in | Bearing: UC210-31 | Housing: FCC210 | Mass: 2.24 kg
UCFCC210 Shaft: 50 mm | Bearing: UC210 | Housing: FCC210 | Mass: 2.24 kg
UCFCC211-32 Shaft: 2 in | Bearing: UC211-32 | Housing: FCC211 | Mass: 3.2 kg
UCFCC211-34 Shaft: 2-1/8 in | Bearing: UC211-34 | Housing: FCC211 | Mass: 3.2 kg
UCFCC211 Shaft: 55 mm | Bearing: UC211 | Housing: FCC211 | Mass: 3.2 kg
UCFCC211-35 Shaft: 2-3/16 in | Bearing: UC211-35 | Housing: FCC211 | Mass: 3.2 kg
UCFCC212-36 Shaft: 2-1/4 in | Bearing: UC212-36 | Housing: FCC212 | Mass: 3.92 kg
UCFCC212 Shaft: 60 mm | Bearing: UC212 | Housing: FCC212 | Mass: 3.92 kg
UCFCC212-38 Shaft: 2-3/8 in | Bearing: UC212-38 | Housing: FCC212 | Mass: 3.92 kg
UCFCC212-39 Shaft: 2-7/16 in | Bearing: UC212-39 | Housing: FCC212 | Mass: 3.92 kg
Mounted Bearing UnitsJIB
38 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

JIB UCFCC2 Round Flange Units (Light Series, Set Screw)

Brand JIB·Mounted Bearing Units

Available part numbers (38)

UCFCC201, UCFCC201-8, UCFCC202, UCFCC202-10, UCFCC203, UCFCC204-12, UCFCC204, UCFCC205-14, UCFCC205-15, UCFCC205 + 28 more — see full table ↓

How to order

Send the JIB part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
UCFCC201Shaft: 12 mm | Bearing: UC201 | Housing: FCC204 | Mass: 0.54 kg
UCFCC201-8Shaft: 1/2 in | Bearing: UC201-8 | Housing: FCC204 | Mass: 0.54 kg
UCFCC202Shaft: 15 mm | Bearing: UC202 | Housing: FCC204 | Mass: 0.54 kg
UCFCC202-10Shaft: 5/8 in | Bearing: UC202-10 | Housing: FCC204 | Mass: 0.54 kg
UCFCC203Shaft: 17 mm | Bearing: UC203 | Housing: FCC204 | Mass: 0.54 kg
UCFCC204-12Shaft: 3/4 in | Bearing: UC204-12 | Housing: FCC204 | Mass: 0.54 kg
UCFCC204Shaft: 20 mm | Bearing: UC204 | Housing: FCC204 | Mass: 0.54 kg
UCFCC205-14Shaft: 7/8 in | Bearing: UC205-14 | Housing: FCC205 | Mass: 0.78 kg
UCFCC205-15Shaft: 15/16 in | Bearing: UC205-15 | Housing: FCC205 | Mass: 0.78 kg
UCFCC205Shaft: 25 mm | Bearing: UC205 | Housing: FCC205 | Mass: 0.78 kg
UCFCC205-16Shaft: 1 in | Bearing: UC205-16 | Housing: FCC205 | Mass: 0.78 kg
UCFCC206-18Shaft: 1-1/8 in | Bearing: UC206-18 | Housing: FCC206 | Mass: 0.96 kg
UCFCC206Shaft: 30 mm | Bearing: UC206 | Housing: FCC206 | Mass: 0.96 kg
UCFCC206-19Shaft: 1-3/16 in | Bearing: UC206-19 | Housing: FCC206 | Mass: 0.96 kg
UCFCC206-20Shaft: 1-1/4 in | Bearing: UC206-20 | Housing: FCC206 | Mass: 0.96 kg
UCFCC207-20Shaft: 1-1/4 in | Bearing: UC207-20 | Housing: FCC207 | Mass: 1.24 kg
UCFCC207-21Shaft: 1-5/16 in | Bearing: UC207-21 | Housing: FCC207 | Mass: 1.24 kg
UCFCC207-22Shaft: 1-3/8 in | Bearing: UC207-22 | Housing: FCC207 | Mass: 1.24 kg
UCFCC207Shaft: 35 mm | Bearing: UC207 | Housing: FCC207 | Mass: 1.24 kg
UCFCC207-23Shaft: 1-7/16 in | Bearing: UC207-23 | Housing: FCC207 | Mass: 1.24 kg
UCFCC208-24Shaft: 1-1/2 in | Bearing: UC208-24 | Housing: FCC208 | Mass: 1.66 kg
UCFCC208-25Shaft: 1-9/16 in | Bearing: UC208-25 | Housing: FCC208 | Mass: 1.66 kg
UCFCC208Shaft: 40 mm | Bearing: UC208 | Housing: FCC208 | Mass: 1.66 kg
UCFCC209-26Shaft: 1-5/8 in | Bearing: UC209-26 | Housing: FCC209 | Mass: 2.08 kg
UCFCC209-27Shaft: 1-11/16 in | Bearing: UC209-27 | Housing: FCC209 | Mass: 2.08 kg
UCFCC209-28Shaft: 1-3/4 in | Bearing: UC209-28 | Housing: FCC209 | Mass: 2.08 kg
UCFCC209Shaft: 45 mm | Bearing: UC209 | Housing: FCC209 | Mass: 2.08 kg
UCFCC210-30Shaft: 1-7/8 in | Bearing: UC210-30 | Housing: FCC210 | Mass: 2.24 kg
UCFCC210-31Shaft: 1-15/16 in | Bearing: UC210-31 | Housing: FCC210 | Mass: 2.24 kg
UCFCC210Shaft: 50 mm | Bearing: UC210 | Housing: FCC210 | Mass: 2.24 kg
UCFCC211-32Shaft: 2 in | Bearing: UC211-32 | Housing: FCC211 | Mass: 3.2 kg
UCFCC211-34Shaft: 2-1/8 in | Bearing: UC211-34 | Housing: FCC211 | Mass: 3.2 kg
UCFCC211Shaft: 55 mm | Bearing: UC211 | Housing: FCC211 | Mass: 3.2 kg
UCFCC211-35Shaft: 2-3/16 in | Bearing: UC211-35 | Housing: FCC211 | Mass: 3.2 kg
UCFCC212-36Shaft: 2-1/4 in | Bearing: UC212-36 | Housing: FCC212 | Mass: 3.92 kg
UCFCC212Shaft: 60 mm | Bearing: UC212 | Housing: FCC212 | Mass: 3.92 kg
UCFCC212-38Shaft: 2-3/8 in | Bearing: UC212-38 | Housing: FCC212 | Mass: 3.92 kg
UCFCC212-39Shaft: 2-7/16 in | Bearing: UC212-39 | Housing: FCC212 | Mass: 3.92 kg
