JIB UKFL2 Oval Flange Units (Light Series, Adapter Mount)

JIB UKFL2 Oval Flange Units (Light Series, Adapter Mount)

JIB UKFL2 oval flange units combine a cast iron 2-bolt oval flange (FL) housing with a UK tapered-bore insert bearing on adapter sleeve. Shaft sizes and housing designations follow the JIB dimension tables.

Key features

  • Cast iron 2-bolt oval flange (FL) housing with adapter-mounted insert
  • Fitted with UK tapered-bore insert bearing on adapter sleeve
  • Self-aligning spherical outside diameter compensates for shaft misalignment
  • Pre-greased, sealed deep groove ball bearing insert
  • Adapter sleeve mounting locks the bearing on plain shafts without set screws

Specifications

Product Mounted ball bearing unit (oval flange unit)
Unit series UKFL2
Housing cast iron 2-bolt oval flange (FL) housing
Insert bearing UK tapered-bore insert bearing on adapter sleeve
Codes 13 sizes
Adapter sleeve H23 series (ordered separately or as set)
Source JIB Ball Bearing Units catalogue, p. 89
UKFL205 Shaft: 20 mm (adapter) | Bearing: UK205 | Housing: FL205 | Mass: 0.68 kg
UKFL206 Shaft: 25 mm (adapter) | Bearing: UK206 | Housing: FL206 | Mass: 0.97 kg
UKFL207 Shaft: 30 mm (adapter) | Bearing: UK207 | Housing: FL207 | Mass: 1.3 kg
UKFL208 Shaft: 35 mm (adapter) | Bearing: UK208 | Housing: FL208 | Mass: 1.6 kg
UKFL209 Shaft: 40 mm (adapter) | Bearing: UK209 | Housing: FL209 | Mass: 2 kg
UKFL210 Shaft: 45 mm (adapter) | Bearing: UK210 | Housing: FL210 | Mass: 2.3 kg
UKFL211 Shaft: 50 mm (adapter) | Bearing: UK211 | Housing: FL211 | Mass: 3.3 kg
UKFL212 Shaft: 55 mm (adapter) | Bearing: UK212 | Housing: FL212 | Mass: 4.1 kg
UKFL213 Shaft: 60 mm (adapter) | Bearing: UK213 | Housing: FL213 | Mass: 5 kg
UKFL215 Shaft: 65 mm (adapter) | Bearing: UK215 | Housing: FL215 | Mass: 6.6 kg
UKFL216 Shaft: 70 mm (adapter) | Bearing: UK216 | Housing: FL216 | Mass: 8.1 kg
UKFL217 Shaft: 75 mm (adapter) | Bearing: UK217 | Housing: FL217 | Mass: 9.9 kg
UKFL218 Shaft: 80 mm (adapter) | Bearing: UK218 | Housing: FL218 | Mass: 12.2 kg
Mounted Bearing UnitsJIB
13 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

JIB UKFL2 Oval Flange Units (Light Series, Adapter Mount)

Brand JIB·Mounted Bearing Units

Available part numbers (13)

UKFL205, UKFL206, UKFL207, UKFL208, UKFL209, UKFL210, UKFL211, UKFL212, UKFL213, UKFL215 + 3 more — see full table ↓

How to order

Send the JIB part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
UKFL205Shaft: 20 mm (adapter) | Bearing: UK205 | Housing: FL205 | Mass: 0.68 kg
UKFL206Shaft: 25 mm (adapter) | Bearing: UK206 | Housing: FL206 | Mass: 0.97 kg
UKFL207Shaft: 30 mm (adapter) | Bearing: UK207 | Housing: FL207 | Mass: 1.3 kg
UKFL208Shaft: 35 mm (adapter) | Bearing: UK208 | Housing: FL208 | Mass: 1.6 kg
UKFL209Shaft: 40 mm (adapter) | Bearing: UK209 | Housing: FL209 | Mass: 2 kg
UKFL210Shaft: 45 mm (adapter) | Bearing: UK210 | Housing: FL210 | Mass: 2.3 kg
UKFL211Shaft: 50 mm (adapter) | Bearing: UK211 | Housing: FL211 | Mass: 3.3 kg
UKFL212Shaft: 55 mm (adapter) | Bearing: UK212 | Housing: FL212 | Mass: 4.1 kg
UKFL213Shaft: 60 mm (adapter) | Bearing: UK213 | Housing: FL213 | Mass: 5 kg
UKFL215Shaft: 65 mm (adapter) | Bearing: UK215 | Housing: FL215 | Mass: 6.6 kg
UKFL216Shaft: 70 mm (adapter) | Bearing: UK216 | Housing: FL216 | Mass: 8.1 kg
UKFL217Shaft: 75 mm (adapter) | Bearing: UK217 | Housing: FL217 | Mass: 9.9 kg
UKFL218Shaft: 80 mm (adapter) | Bearing: UK218 | Housing: FL218 | Mass: 12.2 kg
