JIB UKFX Square Flange Units (Medium Series, Adapter Mount)

JIB UKFX Square Flange Units (Medium Series, Adapter Mount)

JIB UKFX square flange units combine a cast iron 4-bolt square flange (F) housing with a UK tapered-bore insert bearing on adapter sleeve. Shaft sizes and housing designations follow the JIB dimension tables.

Key features

  • Cast iron 4-bolt square flange (F) housing with adapter-mounted insert
  • Fitted with UK tapered-bore insert bearing on adapter sleeve
  • Self-aligning spherical outside diameter compensates for shaft misalignment
  • Pre-greased, sealed deep groove ball bearing insert
  • Adapter sleeve mounting locks the bearing on plain shafts without set screws

Specifications

Product Mounted ball bearing unit (square flange unit)
Unit series UKFX
Housing cast iron 4-bolt square flange (F) housing
Insert bearing UK tapered-bore insert bearing on adapter sleeve
Codes 14 sizes
Adapter sleeve H23 series (ordered separately or as set)
Source JIB Ball Bearing Units catalogue, p. 83
UKFX05 Shaft: 20 mm (adapter) | Bearing: UKX05 | Housing: FX05 | Mass: 1.2 kg
UKFX06 Shaft: 25 mm (adapter) | Bearing: UKX06 | Housing: FX06 | Mass: 1.6 kg
UKFX07 Shaft: 30 mm (adapter) | Bearing: UKX07 | Housing: FX07 | Mass: 2 kg
UKFX08 Shaft: 35 mm (adapter) | Bearing: UKX08 | Housing: FX08 | Mass: 2.3 kg
UKFX09 Shaft: 40 mm (adapter) | Bearing: UKX09 | Housing: FX09 | Mass: 2.7 kg
UKFX10 Shaft: 45 mm (adapter) | Bearing: UKX10 | Housing: FX10 | Mass: 3.6 kg
UKFX11 Shaft: 50 mm (adapter) | Bearing: UKX11 | Housing: FX11 | Mass: 4.6 kg
UKFX12 Shaft: 55 mm (adapter) | Bearing: UKX12 | Housing: FX12 | Mass: 5.5 kg
UKFX13 Shaft: 60 mm (adapter) | Bearing: UKX13 | Housing: FX13 | Mass: 6 kg
UKFX15 Shaft: 65 mm (adapter) | Bearing: UKX15 | Housing: FX15 | Mass: 8.1 kg
UKFX16 Shaft: 70 mm (adapter) | Bearing: UKX16 | Housing: FX16 | Mass: 9.5 kg
UKFX17 Shaft: 75 mm (adapter) | Bearing: UKX17 | Housing: FX17 | Mass: 10.4 kg
UKFX18 Shaft: 80 mm (adapter) | Bearing: UKX18 | Housing: FX18 | Mass: 11.4 kg
UKFX20 Shaft: 90 mm (adapter) | Bearing: UKX20 | Housing: FX20 | Mass: 18.4 kg
Mounted Bearing UnitsJIB
14 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

JIB UKFX Square Flange Units (Medium Series, Adapter Mount)

Brand JIB·Mounted Bearing Units

Available part numbers (14)

UKFX05, UKFX06, UKFX07, UKFX08, UKFX09, UKFX10, UKFX11, UKFX12, UKFX13, UKFX15 + 4 more — see full table ↓

How to order

Send the JIB part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
UKFX05Shaft: 20 mm (adapter) | Bearing: UKX05 | Housing: FX05 | Mass: 1.2 kg
UKFX06Shaft: 25 mm (adapter) | Bearing: UKX06 | Housing: FX06 | Mass: 1.6 kg
UKFX07Shaft: 30 mm (adapter) | Bearing: UKX07 | Housing: FX07 | Mass: 2 kg
UKFX08Shaft: 35 mm (adapter) | Bearing: UKX08 | Housing: FX08 | Mass: 2.3 kg
UKFX09Shaft: 40 mm (adapter) | Bearing: UKX09 | Housing: FX09 | Mass: 2.7 kg
UKFX10Shaft: 45 mm (adapter) | Bearing: UKX10 | Housing: FX10 | Mass: 3.6 kg
UKFX11Shaft: 50 mm (adapter) | Bearing: UKX11 | Housing: FX11 | Mass: 4.6 kg
UKFX12Shaft: 55 mm (adapter) | Bearing: UKX12 | Housing: FX12 | Mass: 5.5 kg
UKFX13Shaft: 60 mm (adapter) | Bearing: UKX13 | Housing: FX13 | Mass: 6 kg
UKFX15Shaft: 65 mm (adapter) | Bearing: UKX15 | Housing: FX15 | Mass: 8.1 kg
UKFX16Shaft: 70 mm (adapter) | Bearing: UKX16 | Housing: FX16 | Mass: 9.5 kg
UKFX17Shaft: 75 mm (adapter) | Bearing: UKX17 | Housing: FX17 | Mass: 10.4 kg
UKFX18Shaft: 80 mm (adapter) | Bearing: UKX18 | Housing: FX18 | Mass: 11.4 kg
UKFX20Shaft: 90 mm (adapter) | Bearing: UKX20 | Housing: FX20 | Mass: 18.4 kg
