JIB UKTX Take-Up Units (Medium Series, Adapter Mount)

JIB UKTX Take-Up Units (Medium Series, Adapter Mount)

JIB UKTX take-up units combine a cast iron take-up (T) housing with a UK tapered-bore insert bearing on adapter sleeve. Shaft sizes and housing designations follow the JIB dimension tables.

Key features

  • Cast iron take-up (T) housing with adapter-mounted insert
  • Fitted with UK tapered-bore insert bearing on adapter sleeve
  • Self-aligning spherical outside diameter compensates for shaft misalignment
  • Pre-greased, sealed deep groove ball bearing insert
  • Adapter sleeve mounting locks the bearing on plain shafts without set screws

Specifications

Product Mounted ball bearing unit (take-up unit)
Unit series UKTX
Housing cast iron take-up (T) housing
Insert bearing UK tapered-bore insert bearing on adapter sleeve
Codes 12 sizes
Adapter sleeve H23 series (ordered separately or as set)
Source JIB Ball Bearing Units catalogue, p. 93
UKTX05 Shaft: 20 mm (adapter) | Bearing: UKX05 | Housing: TX05 | Mass: 1.3 kg
UKTX06 Shaft: 25 mm (adapter) | Bearing: UKX06 | Housing: TX06 | Mass: 1.7 kg
UKTX07 Shaft: 30 mm (adapter) | Bearing: UKX07 | Housing: TX07 | Mass: 2.6 kg
UKTX08 Shaft: 35 mm (adapter) | Bearing: UKX08 | Housing: TX08 | Mass: 2.6 kg
UKTX09 Shaft: 40 mm (adapter) | Bearing: UKX09 | Housing: TX09 | Mass: 2.9 kg
UKTX10 Shaft: 45 mm (adapter) | Bearing: UKX10 | Housing: TX10 | Mass: 4.4 kg
UKTX11 Shaft: 50 mm (adapter) | Bearing: UKX11 | Housing: TX11 | Mass: 5.1 kg
UKTX12 Shaft: 55 mm (adapter) | Bearing: UKX12 | Housing: TX12 | Mass: 7.3 kg
UKTX13 Shaft: 60 mm (adapter) | Bearing: UKX13 | Housing: TX13 | Mass: 7.2 kg
UKTX15 Shaft: 65 mm (adapter) | Bearing: UKX15 | Housing: TX15 | Mass: 8.4 kg
UKTX16 Shaft: 70 mm (adapter) | Bearing: UKX16 | Housing: TX16 | Mass: 11.8 kg
UKTX17 Shaft: 75 mm (adapter) | Bearing: UKX17 | Housing: TX17 | Mass: 11.4 kg
Mounted Bearing UnitsJIB
12 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

JIB UKTX Take-Up Units (Medium Series, Adapter Mount)

Brand JIB·Mounted Bearing Units

Available part numbers (12)

UKTX05, UKTX06, UKTX07, UKTX08, UKTX09, UKTX10, UKTX11, UKTX12, UKTX13, UKTX15 + 2 more — see full table ↓

How to order

Send the JIB part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
UKTX05Shaft: 20 mm (adapter) | Bearing: UKX05 | Housing: TX05 | Mass: 1.3 kg
UKTX06Shaft: 25 mm (adapter) | Bearing: UKX06 | Housing: TX06 | Mass: 1.7 kg
UKTX07Shaft: 30 mm (adapter) | Bearing: UKX07 | Housing: TX07 | Mass: 2.6 kg
UKTX08Shaft: 35 mm (adapter) | Bearing: UKX08 | Housing: TX08 | Mass: 2.6 kg
UKTX09Shaft: 40 mm (adapter) | Bearing: UKX09 | Housing: TX09 | Mass: 2.9 kg
UKTX10Shaft: 45 mm (adapter) | Bearing: UKX10 | Housing: TX10 | Mass: 4.4 kg
UKTX11Shaft: 50 mm (adapter) | Bearing: UKX11 | Housing: TX11 | Mass: 5.1 kg
UKTX12Shaft: 55 mm (adapter) | Bearing: UKX12 | Housing: TX12 | Mass: 7.3 kg
UKTX13Shaft: 60 mm (adapter) | Bearing: UKX13 | Housing: TX13 | Mass: 7.2 kg
UKTX15Shaft: 65 mm (adapter) | Bearing: UKX15 | Housing: TX15 | Mass: 8.4 kg
UKTX16Shaft: 70 mm (adapter) | Bearing: UKX16 | Housing: TX16 | Mass: 11.8 kg
UKTX17Shaft: 75 mm (adapter) | Bearing: UKX17 | Housing: TX17 | Mass: 11.4 kg
