Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| UB503010 | R (mm): 0.5 | D (mm): 1 | Shank d (mm): 6 | Flute length (mm): 1 | L (mm): 50 | ||
| UB503015 | R (mm): 0.75 | D (mm): 1.5 | Shank d (mm): 6 | Flute length (mm): 1.5 | L (mm): 50 | ||
| UB503020 | R (mm): 1 | D (mm): 2 | Shank d (mm): 6 | Flute length (mm): 2 | L (mm): 50 | ||
| UB503030 | R (mm): 1.5 | D (mm): 3 | Shank d (mm): 6 | Flute length (mm): 3 | L (mm): 60 | ||
| UB503040 | R (mm): 2 | D (mm): 4 | Shank d (mm): 6 | Flute length (mm): 4 | L (mm): 70 | ||
| UB503050 | R (mm): 2.5 | D (mm): 5 | Shank d (mm): 6 | Flute length (mm): 5 | L (mm): 80 | ||
| UB503060 | R (mm): 3 | D (mm): 6 | Shank d (mm): 6 | Flute length (mm): 6 | L (mm): 90 | ||
| UB503080 | R (mm): 4 | D (mm): 8 | Shank d (mm): 8 | Flute length (mm): 8 | L (mm): 100 | ||
| UB503100 | R (mm): 5 | D (mm): 10 | Shank d (mm): 10 | Flute length (mm): 10 | L (mm): 100 | ||
| UB503120 | R (mm): 6 | D (mm): 12 | Shank d (mm): 12 | Flute length (mm): 12 | L (mm): 110 |
Need a different model, or a part not listed here? Send us your parts list →
