Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| SR50706005 | R (mm): 0.5 | D (mm): 6 | Shank d (mm): 6 | Flute length (mm): 15 | L (mm): 60 | ||
| SR50708005 | R (mm): 0.5 | D (mm): 8 | Shank d (mm): 8 | Flute length (mm): 20 | L (mm): 70 | ||
| SR50710005 | R (mm): 0.5 | D (mm): 10 | Shank d (mm): 10 | Flute length (mm): 25 | L (mm): 75 | ||
| SR50712005 | R (mm): 0.5 | D (mm): 12 | Shank d (mm): 12 | Flute length (mm): 30 | L (mm): 80 | ||
| SR50716005 | R (mm): 0.5 | D (mm): 16 | Shank d (mm): 16 | Flute length (mm): 42 | L (mm): 100 | ||
| SR50720005 | R (mm): 0.5 | D (mm): 20 | Shank d (mm): 20 | Flute length (mm): 48 | L (mm): 100 |
Need a different model, or a part not listed here? Send us your parts list →
