Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| AMS1014MH | Teeth: 3 | D (mm): 14 | d (mm): 12 | l (mm): 30 | L (mm): 120 | ap max (mm): 11 | Weight (kg): 0.16 | Inserts APMT0602: 3 | Stock: Yes | ||
| AMS1016MH | Teeth: 3 | D (mm): 16 | d (mm): 14 | l (mm): 30 | L (mm): 140 | ap max (mm): 11 | Weight (kg): 0.20 | Inserts APMT0602: 3 | Stock: Yes | ||
| AMS1018MH | Teeth: 3 | D (mm): 18 | d (mm): 16 | l (mm): 30 | L (mm): 140 | ap max (mm): 11 | Weight (kg): 0.21 | Inserts APMT0602: 3 | Stock: Yes | ||
| AMS15020MH | Teeth: 3 | D (mm): 20 | d (mm): 20 | l (mm): 35 | L (mm): 140 | ap max (mm): 17 | Weight (kg): 0.31 | Inserts APMT0602: 1 | Inserts APMT0903: 2 | Stock: Yes |
Need a different model, or a part not listed here? Send us your parts list →
