Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| CSPH3060-045 | D (mm): 6.3 | Shank d (mm): 5 | D1 (mm): 1.5 | L (mm): 45 | Point angle: 90° | ||
| CSPH3080-050 | D (mm): 8.3 | Shank d (mm): 6 | D1 (mm): 2.0 | L (mm): 50 | Point angle: 90° | ||
| CSPH3100-050 | D (mm): 10.4 | Shank d (mm): 6 | D1 (mm): 2.5 | L (mm): 50 | Point angle: 90° | ||
| CSPH3120-056 | D (mm): 12.4 | Shank d (mm): 8 | D1 (mm): 2.8 | L (mm): 56 | Point angle: 90° | ||
| CSPH3160-060 | D (mm): 16.5 | Shank d (mm): 10 | D1 (mm): 3.2 | L (mm): 60 | Point angle: 90° | ||
| CSPH3200-063 | D (mm): 20.5 | Shank d (mm): 10 | D1 (mm): 3.5 | L (mm): 63 | Point angle: 90° | ||
| CSPH3250-068 | D (mm): 25.0 | Shank d (mm): 10 | D1 (mm): 3.8 | L (mm): 68 | Point angle: 90° |
Need a different model, or a part not listed here? Send us your parts list →
