Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| CSNC1100-048 | D (mm): 10.0 | Shank d (mm): 6 | Diameter range (mm): 2.0~9.0 | L (mm): 48 | Point angle: 90° | ||
| CSNC1150-054 | D (mm): 15.0 | Shank d (mm): 8 | Diameter range (mm): 2.0~14.0 | L (mm): 54 | Point angle: 90° | ||
| CSNC1200-059 | D (mm): 20.0 | Shank d (mm): 10 | Diameter range (mm): 2.0~19.0 | L (mm): 59 | Point angle: 90° | ||
| CSNC1250-069 | D (mm): 25.0 | Shank d (mm): 12 | Diameter range (mm): 3.0~24.0 | L (mm): 69 | Point angle: 90° | ||
| CSNC1300-077 | D (mm): 30.0 | Shank d (mm): 12 | Diameter range (mm): 4.0~29.0 | L (mm): 77 | Point angle: 90° |
Need a different model, or a part not listed here? Send us your parts list →
