• Korloy H-Star 4 Flute Long Neck Type Flat End Mill ESLNS40
1 1

Korloy H-Star 4 Flute Long Neck Type Flat End Mill ESLNS40

Korloy H-Star 4 Flute Long Neck Type Flat End Mill ESLNS40

Solid carbide end mill of the H-Star series for high speed and high hardness machining (HRC50~63).

Key features

  • Ultra-fine WC + Co 9% high hardness substrate
  • AlTiN coating for wear and frictional heat resistance
  • Edge treatment for chipping resistance in hardened steel
  • Helix angle 30°
  • h5 shank tolerance

Specifications

Series line H-Star End Mill
Flutes 4
Coating AlTiN
Helix angle 30°
ØD tolerance All sizes: 0~-0.012mm
Shank tolerance h5
Workpiece (excellent) Hardened steel SKD61~HRC55, Hardened steel SKD11 HRC55~63
Workpiece (good) Pre-hardened steel HRC30~50, Copper
ESLNS4010-4 ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 4 | D3 (mm): 0.96 | θ (deg): 7.7 | L (mm): 50 | Effective length at 0.5° (mm): 5.1 | Effective length at 1° (mm): 5.5 | Effective length at 1.5° (mm): 5.8 | Effective length at 2° (mm): 6.1 | Effective length at 3° (mm): 6.6
ESLNS4010-6 ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 6 | D3 (mm): 0.96 | θ (deg): 6.6 | L (mm): 50 | Effective length at 0.5° (mm): 7.2 | Effective length at 1° (mm): 7.7 | Effective length at 1.5° (mm): 8.1 | Effective length at 2° (mm): 8.4 | Effective length at 3° (mm): 9.1
ESLNS4010-8 ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 8 | D3 (mm): 0.96 | θ (deg): 5.7 | L (mm): 50 | Effective length at 0.5° (mm): 9.4 | Effective length at 1° (mm): 9.9 | Effective length at 1.5° (mm): 10.4 | Effective length at 2° (mm): 10.7 | Effective length at 3° (mm): 11.4
ESLNS4010-10 ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 10 | D3 (mm): 0.96 | θ (deg): 5 | L (mm): 50 | Effective length at 0.5° (mm): 11.5 | Effective length at 1° (mm): 12.1 | Effective length at 1.5° (mm): 12.6 | Effective length at 2° (mm): 13 | Effective length at 3° (mm): 13.7
ESLNS4015-4 ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.25 | ℓ2 (mm): 4 | D3 (mm): 1.44 | θ (deg): 7.2 | L (mm): 50 | Effective length at 0.5° (mm): 5.2 | Effective length at 1° (mm): 5.5 | Effective length at 1.5° (mm): 5.9 | Effective length at 2° (mm): 6.2 | Effective length at 3° (mm): 6.7
ESLNS4015-6 ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.25 | ℓ2 (mm): 6 | D3 (mm): 1.44 | θ (deg): 6 | L (mm): 50 | Effective length at 0.5° (mm): 7.3 | Effective length at 1° (mm): 7.8 | Effective length at 1.5° (mm): 8.1 | Effective length at 2° (mm): 8.5 | Effective length at 3° (mm): 9.1
ESLNS4015-8 ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.25 | ℓ2 (mm): 8 | D3 (mm): 1.44 | θ (deg): 5.1 | L (mm): 50 | Effective length at 0.5° (mm): 9.4 | Effective length at 1° (mm): 10 | Effective length at 1.5° (mm): 10.4 | Effective length at 2° (mm): 10.8 | Effective length at 3° (mm): 11.5
ESLNS4015-10 ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.25 | ℓ2 (mm): 10 | D3 (mm): 1.44 | θ (deg): 4.5 | L (mm): 50 | Effective length at 0.5° (mm): 11.6 | Effective length at 1° (mm): 12.1 | Effective length at 1.5° (mm): 12.6 | Effective length at 2° (mm): 13 | Effective length at 3° (mm): 13.8
ESLNS4015-12 ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.25 | ℓ2 (mm): 12 | D3 (mm): 1.44 | θ (deg): 4 | L (mm): 55 | Effective length at 0.5° (mm): 13.7 | Effective length at 1° (mm): 14.3 | Effective length at 1.5° (mm): 14.8 | Effective length at 2° (mm): 15.3 | Effective length at 3° (mm): 16.1
ESLNS4015-14 ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.25 | ℓ2 (mm): 14 | D3 (mm): 1.44 | θ (deg): 3.6 | L (mm): 55 | Effective length at 0.5° (mm): 15.8 | Effective length at 1° (mm): 16.5 | Effective length at 1.5° (mm): 17 | Effective length at 2° (mm): 17.5 | Effective length at 3° (mm): 18.7
ESLNS4015-16 ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.25 | ℓ2 (mm): 16 | D3 (mm): 1.44 | θ (deg): 3.3 | L (mm): 55 | Effective length at 0.5° (mm): 17.9 | Effective length at 1° (mm): 18.6 | Effective length at 1.5° (mm): 19.2 | Effective length at 2° (mm): 19.7
ESLNS4015-18 ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.25 | ℓ2 (mm): 18 | D3 (mm): 1.44 | θ (deg): 3 | L (mm): 60 | Effective length at 0.5° (mm): 20 | Effective length at 1° (mm): 20.7 | Effective length at 1.5° (mm): 21.3 | Effective length at 2° (mm): 21.9
ESLNS4015-20 ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.25 | ℓ2 (mm): 20 | D3 (mm): 1.44 | θ (deg): 2.8 | L (mm): 60 | Effective length at 0.5° (mm): 22 | Effective length at 1° (mm): 22.9 | Effective length at 1.5° (mm): 23.5 | Effective length at 2° (mm): 24.1
ESLNS4015-25 ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.25 | ℓ2 (mm): 25 | D3 (mm): 1.44 | θ (deg): 2.4 | L (mm): 65 | Effective length at 0.5° (mm): 27.3 | Effective length at 1° (mm): 28.1 | Effective length at 1.5° (mm): 28.8 | Effective length at 2° (mm): 30
ESLNS4020-4 ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 4 | D3 (mm): 1.92 | θ (deg): 6.5 | L (mm): 50 | Effective length at 0.5° (mm): 5.3 | Effective length at 1° (mm): 5.6 | Effective length at 1.5° (mm): 5.9 | Effective length at 2° (mm): 6.2 | Effective length at 3° (mm): 6.7
ESLNS4020-6 ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 6 | D3 (mm): 1.92 | θ (deg): 5.3 | L (mm): 50 | Effective length at 0.5° (mm): 7.4 | Effective length at 1° (mm): 7.8 | Effective length at 1.5° (mm): 8.2 | Effective length at 2° (mm): 8.5 | Effective length at 3° (mm): 9.1
ESLNS4020-8 ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 8 | D3 (mm): 1.92 | θ (deg): 4.5 | L (mm): 50 | Effective length at 0.5° (mm): 9.5 | Effective length at 1° (mm): 10 | Effective length at 1.5° (mm): 10.4 | Effective length at 2° (mm): 10.8 | Effective length at 3° (mm): 11.5
ESLNS4020-10 ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 10 | D3 (mm): 1.92 | θ (deg): 3.9 | L (mm): 50 | Effective length at 0.5° (mm): 11.6 | Effective length at 1° (mm): 12.2 | Effective length at 1.5° (mm): 12.7 | Effective length at 2° (mm): 13.1 | Effective length at 3° (mm): 13.8
ESLNS4020-12 ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 12 | D3 (mm): 1.92 | θ (deg): 3.4 | L (mm): 55 | Effective length at 0.5° (mm): 13.7 | Effective length at 1° (mm): 14.3 | Effective length at 1.5° (mm): 14.9 | Effective length at 2° (mm): 15.3 | Effective length at 3° (mm): 16.1
ESLNS4020-14 ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 14 | D3 (mm): 1.92 | θ (deg): 3.1 | L (mm): 55 | Effective length at 0.5° (mm): 15.8 | Effective length at 1° (mm): 16.5 | Effective length at 1.5° (mm): 17 | Effective length at 2° (mm): 17.5 | Effective length at 3° (mm): 18.8
ESLNS4020-16 ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 16 | D3 (mm): 1.92 | θ (deg): 2.8 | L (mm): 55 | Effective length at 0.5° (mm): 17.9 | Effective length at 1° (mm): 18.6 | Effective length at 1.5° (mm): 19.2 | Effective length at 2° (mm): 19.7
ESLNS4020-18 ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 18 | D3 (mm): 1.92 | θ (deg): 2.6 | L (mm): 60 | Effective length at 0.5° (mm): 20 | Effective length at 1° (mm): 20.8 | Effective length at 1.5° (mm): 21.4 | Effective length at 2° (mm): 21.9
ESLNS4020-20 ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 20 | D3 (mm): 1.92 | θ (deg): 2.4 | L (mm): 60 | Effective length at 0.5° (mm): 22.1 | Effective length at 1° (mm): 22.9 | Effective length at 1.5° (mm): 23.5 | Effective length at 2° (mm): 24.1
ESLNS4020-25 ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 25 | D3 (mm): 1.92 | θ (deg): 2 | L (mm): 65 | Effective length at 0.5° (mm): 27.3 | Effective length at 1° (mm): 28.2 | Effective length at 1.5° (mm): 28.9
ESLNS4020-30 ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 30 | D3 (mm): 1.92 | θ (deg): 1.7 | L (mm): 70 | Effective length at 0.5° (mm): 32.5 | Effective length at 1° (mm): 33.4 | Effective length at 1.5° (mm): 34.4
ESLNS4025-8 ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 3.75 | ℓ2 (mm): 8 | D3 (mm): 2.4 | θ (deg): 3.7 | L (mm): 50 | Effective length at 0.5° (mm): 9.6 | Effective length at 1° (mm): 10.1 | Effective length at 1.5° (mm): 10.5 | Effective length at 2° (mm): 10.9 | Effective length at 3° (mm): 11.5
ESLNS4025-10 ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 3.75 | ℓ2 (mm): 10 | D3 (mm): 2.4 | θ (deg): 3.1 | L (mm): 50 | Effective length at 0.5° (mm): 11.7 | Effective length at 1° (mm): 12.2 | Effective length at 1.5° (mm): 12.7 | Effective length at 2° (mm): 13.1 | Effective length at 3° (mm): 13.8
ESLNS4025-12 ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 3.75 | ℓ2 (mm): 12 | D3 (mm): 2.4 | θ (deg): 2.7 | L (mm): 55 | Effective length at 0.5° (mm): 13.8 | Effective length at 1° (mm): 14.4 | Effective length at 1.5° (mm): 14.9 | Effective length at 2° (mm): 15.3
ESLNS4025-14 ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 3.75 | ℓ2 (mm): 14 | D3 (mm): 2.4 | θ (deg): 2.4 | L (mm): 55 | Effective length at 0.5° (mm): 15.9 | Effective length at 1° (mm): 16.5 | Effective length at 1.5° (mm): 17.1 | Effective length at 2° (mm): 17.5
ESLNS4025-16 ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 3.75 | ℓ2 (mm): 16 | D3 (mm): 2.4 | θ (deg): 2.2 | L (mm): 55 | Effective length at 0.5° (mm): 18 | Effective length at 1° (mm): 18.7 | Effective length at 1.5° (mm): 19.2 | Effective length at 2° (mm): 19.7
ESLNS4025-18 ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 3.75 | ℓ2 (mm): 18 | D3 (mm): 2.4 | θ (deg): 2 | L (mm): 60 | Effective length at 0.5° (mm): 20.1 | Effective length at 1° (mm): 20.8 | Effective length at 1.5° (mm): 21.4
ESLNS4025-20 ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 3.75 | ℓ2 (mm): 20 | D3 (mm): 2.4 | θ (deg): 1.8 | L (mm): 60 | Effective length at 0.5° (mm): 22.1 | Effective length at 1° (mm): 22.9 | Effective length at 1.5° (mm): 23.5
ESLNS4025-25 ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 3.75 | ℓ2 (mm): 25 | D3 (mm): 2.4 | θ (deg): 1.5 | L (mm): 65 | Effective length at 0.5° (mm): 27.3 | Effective length at 1° (mm): 28.2
ESLNS4025-30 ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 3.75 | ℓ2 (mm): 30 | D3 (mm): 2.4 | θ (deg): 1.3 | L (mm): 70 | Effective length at 0.5° (mm): 32.6 | Effective length at 1° (mm): 33.5
ESLNS4030-8 ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 8 | D3 (mm): 2.88 | θ (deg): 5.6 | L (mm): 55 | Effective length at 0.5° (mm): 9.6 | Effective length at 1° (mm): 10.1 | Effective length at 1.5° (mm): 10.5 | Effective length at 2° (mm): 10.9 | Effective length at 3° (mm): 11.5
ESLNS4030-10 ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 10 | D3 (mm): 2.88 | θ (deg): 5 | L (mm): 55 | Effective length at 0.5° (mm): 11.7 | Effective length at 1° (mm): 12.3 | Effective length at 1.5° (mm): 12.7 | Effective length at 2° (mm): 13.1 | Effective length at 3° (mm): 13.8
ESLNS4030-12 ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 12 | D3 (mm): 2.88 | θ (deg): 4.5 | L (mm): 60 | Effective length at 0.5° (mm): 13.8 | Effective length at 1° (mm): 14.4 | Effective length at 1.5° (mm): 14.9 | Effective length at 2° (mm): 15.4 | Effective length at 3° (mm): 16.3
ESLNS4030-14 ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 14 | D3 (mm): 2.88 | θ (deg): 4.1 | L (mm): 60 | Effective length at 0.5° (mm): 15.9 | Effective length at 1° (mm): 16.6 | Effective length at 1.5° (mm): 17.1 | Effective length at 2° (mm): 17.6 | Effective length at 3° (mm): 18.9
ESLNS4030-16 ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 16 | D3 (mm): 2.88 | θ (deg): 3.7 | L (mm): 60 | Effective length at 0.5° (mm): 18 | Effective length at 1° (mm): 18.7 | Effective length at 1.5° (mm): 19.3 | Effective length at 2° (mm): 19.8 | Effective length at 3° (mm): 21.6
ESLNS4030-18 ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 18 | D3 (mm): 2.88 | θ (deg): 3.4 | L (mm): 60 | Effective length at 0.5° (mm): 20.1 | Effective length at 1° (mm): 20.8 | Effective length at 1.5° (mm): 21.4 | Effective length at 2° (mm): 21.9 | Effective length at 3° (mm): 24.2
ESLNS4030-20 ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 20 | D3 (mm): 2.88 | θ (deg): 3.2 | L (mm): 65 | Effective length at 0.5° (mm): 22.2 | Effective length at 1° (mm): 23 | Effective length at 1.5° (mm): 23.6 | Effective length at 2° (mm): 24.2 | Effective length at 3° (mm): 26.9
ESLNS4030-25 ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 25 | D3 (mm): 2.88 | θ (deg): 2.7 | L (mm): 70 | Effective length at 0.5° (mm): 27.4 | Effective length at 1° (mm): 28.2 | Effective length at 1.5° (mm): 28.9 | Effective length at 2° (mm): 30.2
ESLNS4030-30 ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 30 | D3 (mm): 2.88 | θ (deg): 2.4 | L (mm): 75 | Effective length at 0.5° (mm): 32.6 | Effective length at 1° (mm): 33.5 | Effective length at 1.5° (mm): 34.5 | Effective length at 2° (mm): 36.2
ESLNS4030-35 ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 35 | D3 (mm): 2.88 | θ (deg): 2.1 | L (mm): 80 | Effective length at 0.5° (mm): 37.7 | Effective length at 1° (mm): 38.7 | Effective length at 1.5° (mm): 40.2 | Effective length at 2° (mm): 42.2
ESLNS4030-40 ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 40 | D3 (mm): 2.88 | θ (deg): 1.9 | L (mm): 90 | Effective length at 0.5° (mm): 42.9 | Effective length at 1° (mm): 43.9 | Effective length at 1.5° (mm): 45.9
ESLNS4040-12 ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 12 | D3 (mm): 3.85 | θ (deg): 3.4 | L (mm): 60 | Effective length at 0.5° (mm): 13.9 | Effective length at 1° (mm): 14.5 | Effective length at 1.5° (mm): 15 | Effective length at 2° (mm): 15.4 | Effective length at 3° (mm): 16.3
ESLNS4040-16 ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 16 | D3 (mm): 3.85 | θ (deg): 2.8 | L (mm): 60 | Effective length at 0.5° (mm): 18.1 | Effective length at 1° (mm): 18.8 | Effective length at 1.5° (mm): 19.3 | Effective length at 2° (mm): 19.8
ESLNS4040-20 ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 20 | D3 (mm): 3.85 | θ (deg): 2.3 | L (mm): 70 | Effective length at 0.5° (mm): 22.3 | Effective length at 1° (mm): 23 | Effective length at 1.5° (mm): 23.6 | Effective length at 2° (mm): 24.3
ESLNS4040-25 ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 25 | D3 (mm): 3.85 | θ (deg): 2 | L (mm): 70 | Effective length at 0.5° (mm): 27.4 | Effective length at 1° (mm): 28.3 | Effective length at 1.5° (mm): 28.9
ESLNS4040-30 ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 30 | D3 (mm): 3.85 | θ (deg): 1.7 | L (mm): 80 | Effective length at 0.5° (mm): 32.6 | Effective length at 1° (mm): 33.5 | Effective length at 1.5° (mm): 34.6
ESLNS4040-35 ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 35 | D3 (mm): 3.85 | θ (deg): 1.5 | L (mm): 80 | Effective length at 0.5° (mm): 37.8 | Effective length at 1° (mm): 38.8
ESLNS4040-40 ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 40 | D3 (mm): 3.85 | θ (deg): 1.3 | L (mm): 90 | Effective length at 0.5° (mm): 42.9 | Effective length at 1° (mm): 44
ESLNS4040-45 ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 45 | D3 (mm): 3.85 | θ (deg): 1.2 | L (mm): 90 | Effective length at 0.5° (mm): 48.1 | Effective length at 1° (mm): 49.4
ESLNS4040-50 ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 50 | D3 (mm): 3.85 | θ (deg): 1.1 | L (mm): 100 | Effective length at 0.5° (mm): 53.2 | Effective length at 1° (mm): 54.8
ESLNS4050-16 ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 7.5 | ℓ2 (mm): 16 | D3 (mm): 4.85 | θ (deg): 1.5 | L (mm): 60 | Effective length at 0.5° (mm): 18.1 | Effective length at 1° (mm): 18.8
ESLNS4050-20 ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 7.5 | ℓ2 (mm): 20 | D3 (mm): 4.85 | θ (deg): 1.3 | L (mm): 60 | Effective length at 0.5° (mm): 22.3 | Effective length at 1° (mm): 23
ESLNS4050-25 ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 7.5 | ℓ2 (mm): 25 | D3 (mm): 4.85 | θ (deg): 1.1 | L (mm): 70 | Effective length at 0.5° (mm): 27.4 | Effective length at 1° (mm): 28.3
ESLNS4050-30 ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 7.5 | ℓ2 (mm): 30 | D3 (mm): 4.85 | θ (deg): 0.9 | L (mm): 70 | Effective length at 0.5° (mm): 32.6
ESLNS4050-35 ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 7.5 | ℓ2 (mm): 35 | D3 (mm): 4.85 | θ (deg): 0.8 | L (mm): 80 | Effective length at 0.5° (mm): 37.8
ESLNS4050-40 ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 7.5 | ℓ2 (mm): 40 | D3 (mm): 4.85 | θ (deg): 0.7 | L (mm): 90 | Effective length at 0.5° (mm): 42.9
ESLNS4050-50 ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 7.5 | ℓ2 (mm): 50 | D3 (mm): 4.85 | θ (deg): 0.6 | L (mm): 100 | Effective length at 0.5° (mm): 53.2
End MillsKorloy
61 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Korloy H-Star 4 Flute Long Neck Type Flat End Mill ESLNS40

Brand Korloy·End Mills

Available part numbers (61)

ESLNS4010-4, ESLNS4010-6, ESLNS4010-8, ESLNS4010-10, ESLNS4015-4, ESLNS4015-6, ESLNS4015-8, ESLNS4015-10, ESLNS4015-12, ESLNS4015-14 + 51 more — see full table ↓

How to order

Send the Korloy part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
