Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| TCRS070 | No. of flutes: 4 | D (mm): 7.0 | l (mm): 20 | L (mm): 150 | Morse taper No.: 1 | ||
| TCRS080 | No. of flutes: 4 | D (mm): 8.0 | l (mm): 20 | L (mm): 150 | Morse taper No.: 1 | ||
| TCRS090 | No. of flutes: 4 | D (mm): 9.0 | l (mm): 20 | L (mm): 160 | Morse taper No.: 1 | ||
| TCRS100 | No. of flutes: 4 | D (mm): 10.0 | l (mm): 25 | L (mm): 160 | Morse taper No.: 1 | ||
| TCRS110 | No. of flutes: 4 | D (mm): 11.0 | l (mm): 25 | L (mm): 170 | Morse taper No.: 1 | ||
| TCRS120 | No. of flutes: 4 | D (mm): 12.0 | l (mm): 25 | L (mm): 170 | Morse taper No.: 1 | ||
| TCRS130 | No. of flutes: 4 | D (mm): 13.0 | l (mm): 25 | L (mm): 180 | Morse taper No.: 1 | ||
| TCRS140 | No. of flutes: 6 | D (mm): 14.0 | l (mm): 25 | L (mm): 190 | Morse taper No.: 1 | ||
| TCRS150 | No. of flutes: 6 | D (mm): 15.0 | l (mm): 30 | L (mm): 200 | Morse taper No.: 2 | ||
| TCRS160 | No. of flutes: 6 | D (mm): 16.0 | l (mm): 30 | L (mm): 200 | Morse taper No.: 2 | ||
| TCRS180 | No. of flutes: 6 | D (mm): 18.0 | l (mm): 30 | L (mm): 220 | Morse taper No.: 2 | ||
| TCRS200 | No. of flutes: 6 | D (mm): 20.0 | l (mm): 40 | L (mm): 230 | Morse taper No.: 2 | ||
| TCRS250 | No. of flutes: 6 | D (mm): 25.0 | l (mm): 40 | L (mm): 260 | Morse taper No.: 3 | ||
| TCRS280 | No. of flutes: 8 | D (mm): 28.0 | l (mm): 40 | L (mm): 270 | Morse taper No.: 3 | ||
| TCRS300 | No. of flutes: 8 | D (mm): 30.0 | l (mm): 50 | L (mm): 290 | Morse taper No.: 3 |
Need a different model, or a part not listed here? Send us your parts list →
