Korloy Pro-X Mill Aluminum Milling Insert XEKT

Korloy Pro-X Mill Aluminum Milling Insert XEKT

Pro-X Mill for high speed aluminum machining with XEKT inserts.

Key features

  • Strong clamping due to concave insert seat
  • Buffed insert for good chip flow
  • High rake angle for good surface finish
  • Designed for high speed aluminum machining
XEKT19M504FR-MA H01 Chip breaker: MA | l1 (mm): 1.4 | t (mm): 5 | r (mm): 0.4 | d1 (mm): 4.4 | Grade: H01 | Stock: Yes
XEKT19M508FR-MA H01 Chip breaker: MA | l1 (mm): 1.0 | t (mm): 5 | r (mm): 0.8 | d1 (mm): 4.4 | Grade: H01 | Stock: Yes
XEKT19M512FR-MA H01 Chip breaker: MA | l1 (mm): 0.6 | t (mm): 5 | r (mm): 1.2 | d1 (mm): 4.4 | Grade: H01 | Stock: Yes
XEKT19M516FR-MA H01 Chip breaker: MA | l1 (mm): 0.5 | t (mm): 5 | r (mm): 1.6 | d1 (mm): 4.4 | Grade: H01 | Stock: Yes
XEKT19M520FR-MA H01 Chip breaker: MA | l1 (mm): 0.5 | t (mm): 5 | r (mm): 2.0 | d1 (mm): 4.4 | Grade: H01 | Stock: Yes
XEKT19M530FR-MA H01 Chip breaker: MA | l1 (mm): 0.7 | t (mm): 5 | r (mm): 3.0 | d1 (mm): 4.4 | Grade: H01 | Stock: Yes
XEKT19M532FR-MA H01 Chip breaker: MA | l1 (mm): 0.5 | t (mm): 5 | r (mm): 3.2 | d1 (mm): 4.4 | Grade: H01 | Stock: Yes
XEKT19M540FR-MA H01 Chip breaker: MA | l1 (mm): 0.5 | t (mm): 5 | r (mm): 4.0 | d1 (mm): 4.4 | Grade: H01 | Stock: Yes
XEKT19M550FR-MA H01 Chip breaker: MA | l1 (mm): 0.4 | t (mm): 5 | r (mm): 5.0 | d1 (mm): 4.4 | Grade: H01 | Stock: Yes
XEKT250604FR-MA H01 Chip breaker: MA | l1 (mm): 1.5 | t (mm): 6.35 | r (mm): 0.4 | d1 (mm): 6.0 | Grade: H01 | Stock: Yes
XEKT250608FR-MA H01 Chip breaker: MA | l1 (mm): 1.2 | t (mm): 6.35 | r (mm): 0.8 | d1 (mm): 6.0 | Grade: H01 | Stock: Yes
XEKT250612FR-MA H01 Chip breaker: MA | l1 (mm): 0.8 | t (mm): 6.35 | r (mm): 1.2 | d1 (mm): 6.0 | Grade: H01 | Stock: Yes
XEKT250620FR-MA H01 Chip breaker: MA | l1 (mm): 0.5 | t (mm): 6.35 | r (mm): 2.0 | d1 (mm): 6.0 | Grade: H01 | Stock: Yes
XEKT250632FR-MA H01 Chip breaker: MA | l1 (mm): 0.4 | t (mm): 6.35 | r (mm): 3.2 | d1 (mm): 6.0 | Grade: H01 | Stock: Yes
XEKT250650FR-MA H01 Chip breaker: MA | l1 (mm): 0.4 | t (mm): 6.35 | r (mm): 5.0 | d1 (mm): 6.0 | Grade: H01 | Stock: Yes
Milling InsertsKorloy
15 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Korloy Pro-X Mill Aluminum Milling Insert XEKT

Brand Korloy·Milling Inserts

Available part numbers (15)

XEKT19M504FR-MA H01, XEKT19M508FR-MA H01, XEKT19M512FR-MA H01, XEKT19M516FR-MA H01, XEKT19M520FR-MA H01, XEKT19M530FR-MA H01, XEKT19M532FR-MA H01, XEKT19M540FR-MA H01, XEKT19M550FR-MA H01, XEKT250604FR-MA H01 + 5 more — see full table ↓

How to order

Send the Korloy part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
XEKT19M504FR-MA H01Chip breaker: MA | l1 (mm): 1.4 | t (mm): 5 | r (mm): 0.4 | d1 (mm): 4.4 | Grade: H01 | Stock: Yes
XEKT19M508FR-MA H01Chip breaker: MA | l1 (mm): 1.0 | t (mm): 5 | r (mm): 0.8 | d1 (mm): 4.4 | Grade: H01 | Stock: Yes
XEKT19M512FR-MA H01Chip breaker: MA | l1 (mm): 0.6 | t (mm): 5 | r (mm): 1.2 | d1 (mm): 4.4 | Grade: H01 | Stock: Yes
XEKT19M516FR-MA H01Chip breaker: MA | l1 (mm): 0.5 | t (mm): 5 | r (mm): 1.6 | d1 (mm): 4.4 | Grade: H01 | Stock: Yes
XEKT19M520FR-MA H01Chip breaker: MA | l1 (mm): 0.5 | t (mm): 5 | r (mm): 2.0 | d1 (mm): 4.4 | Grade: H01 | Stock: Yes
XEKT19M530FR-MA H01Chip breaker: MA | l1 (mm): 0.7 | t (mm): 5 | r (mm): 3.0 | d1 (mm): 4.4 | Grade: H01 | Stock: Yes
XEKT19M532FR-MA H01Chip breaker: MA | l1 (mm): 0.5 | t (mm): 5 | r (mm): 3.2 | d1 (mm): 4.4 | Grade: H01 | Stock: Yes
XEKT19M540FR-MA H01Chip breaker: MA | l1 (mm): 0.5 | t (mm): 5 | r (mm): 4.0 | d1 (mm): 4.4 | Grade: H01 | Stock: Yes
XEKT19M550FR-MA H01Chip breaker: MA | l1 (mm): 0.4 | t (mm): 5 | r (mm): 5.0 | d1 (mm): 4.4 | Grade: H01 | Stock: Yes
XEKT250604FR-MA H01Chip breaker: MA | l1 (mm): 1.5 | t (mm): 6.35 | r (mm): 0.4 | d1 (mm): 6.0 | Grade: H01 | Stock: Yes
XEKT250608FR-MA H01Chip breaker: MA | l1 (mm): 1.2 | t (mm): 6.35 | r (mm): 0.8 | d1 (mm): 6.0 | Grade: H01 | Stock: Yes
XEKT250612FR-MA H01Chip breaker: MA | l1 (mm): 0.8 | t (mm): 6.35 | r (mm): 1.2 | d1 (mm): 6.0 | Grade: H01 | Stock: Yes
XEKT250620FR-MA H01Chip breaker: MA | l1 (mm): 0.5 | t (mm): 6.35 | r (mm): 2.0 | d1 (mm): 6.0 | Grade: H01 | Stock: Yes
XEKT250632FR-MA H01Chip breaker: MA | l1 (mm): 0.4 | t (mm): 6.35 | r (mm): 3.2 | d1 (mm): 6.0 | Grade: H01 | Stock: Yes
XEKT250650FR-MA H01Chip breaker: MA | l1 (mm): 0.4 | t (mm): 6.35 | r (mm): 5.0 | d1 (mm): 6.0 | Grade: H01 | Stock: Yes
