Korloy U-Star 2 Flute Neck Type Radius End Mill UR512

Korloy U-Star 2 Flute Neck Type Radius End Mill UR512

Solid carbide end mill of the U-Star series for mold and die machining of HRC30~50 medium hardness steel and die steel.

Key features

  • Carbide substrate for medium hardness steel cutting
  • AlCrN based multilayer coating for wear and oxidation resistance
  • S-curved gash shape disperses cutting force
  • Helix angle 30°
  • Radius tolerance ±0.01; ±0.01 (Corner R)
  • h5 shank tolerance

Specifications

Series line U-Star End Mill
Flutes 2
Coating AlCrN
Helix angle 30°
ØD tolerance Ø0.2~Ø6: 0~-0.012mm; Ø8~Ø20: 0~-0.015mm
Shank tolerance h5
Radius tolerance ±0.01; ±0.01 (Corner R)
Workpiece (excellent) Alloy steel HB225~325, Pre-hardened steel HRC30~50
Workpiece (good) Carbon steel ~ HB225, Hardened steel SKD61~HRC55, Cast iron ~FCD500
UR512002002005 R (mm): 0.02 | ØD (mm): 0.2 | Ød (mm): 4 | ℓ1 (mm): 0.3 | ℓ2 (mm): 0.5 | L (mm): 40
UR51200200201 R (mm): 0.02 | ØD (mm): 0.2 | Ød (mm): 4 | ℓ1 (mm): 0.3 | ℓ2 (mm): 1 | L (mm): 40
UR512002002015 R (mm): 0.02 | ØD (mm): 0.2 | Ød (mm): 4 | ℓ1 (mm): 0.3 | ℓ2 (mm): 1.5 | L (mm): 40
UR51200200202 R (mm): 0.02 | ØD (mm): 0.2 | Ød (mm): 4 | ℓ1 (mm): 0.3 | ℓ2 (mm): 2 | L (mm): 40
UR512002005005 R (mm): 0.05 | ØD (mm): 0.2 | Ød (mm): 4 | ℓ1 (mm): 0.3 | ℓ2 (mm): 0.5 | L (mm): 40
UR51200200501 R (mm): 0.05 | ØD (mm): 0.2 | Ød (mm): 4 | ℓ1 (mm): 0.3 | ℓ2 (mm): 1 | L (mm): 40
UR512002005015 R (mm): 0.05 | ØD (mm): 0.2 | Ød (mm): 4 | ℓ1 (mm): 0.3 | ℓ2 (mm): 1.5 | L (mm): 40
UR51200200502 R (mm): 0.05 | ØD (mm): 0.2 | Ød (mm): 4 | ℓ1 (mm): 0.3 | ℓ2 (mm): 2 | L (mm): 40
UR51200300201 R (mm): 0.02 | ØD (mm): 0.3 | Ød (mm): 4 | ℓ1 (mm): 0.5 | ℓ2 (mm): 1 | L (mm): 40
UR51200300202 R (mm): 0.02 | ØD (mm): 0.3 | Ød (mm): 4 | ℓ1 (mm): 0.5 | ℓ2 (mm): 2 | L (mm): 40
UR51200300203 R (mm): 0.02 | ØD (mm): 0.3 | Ød (mm): 4 | ℓ1 (mm): 0.5 | ℓ2 (mm): 3 | L (mm): 40
UR51200300501 R (mm): 0.05 | ØD (mm): 0.3 | Ød (mm): 4 | ℓ1 (mm): 0.5 | ℓ2 (mm): 1 | L (mm): 40
UR51200300502 R (mm): 0.05 | ØD (mm): 0.3 | Ød (mm): 4 | ℓ1 (mm): 0.5 | ℓ2 (mm): 2 | L (mm): 40
UR51200300503 R (mm): 0.05 | ØD (mm): 0.3 | Ød (mm): 4 | ℓ1 (mm): 0.5 | ℓ2 (mm): 3 | L (mm): 40
UR51200400501 R (mm): 0.05 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 1 | L (mm): 40
UR512004005015 R (mm): 0.05 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 1.5 | L (mm): 40
UR51200400502 R (mm): 0.05 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 2 | L (mm): 40
UR512004005025 R (mm): 0.05 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 2.5 | L (mm): 40
UR51200400503 R (mm): 0.05 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 3 | L (mm): 40
UR51200400504 R (mm): 0.05 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 4 | L (mm): 40
UR5120040101 R (mm): 0.1 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 1 | L (mm): 40
UR51200401015 R (mm): 0.1 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 1.5 | L (mm): 40
UR5120040102 R (mm): 0.1 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 2 | L (mm): 40
UR51200401025 R (mm): 0.1 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 2.5 | L (mm): 40
UR5120040103 R (mm): 0.1 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 3 | L (mm): 40
UR5120040104 R (mm): 0.1 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 4 | L (mm): 40
UR51200500501 R (mm): 0.05 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 1 | L (mm): 45
UR512005005015 R (mm): 0.05 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 1.5 | L (mm): 45
UR51200500502 R (mm): 0.05 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 2 | L (mm): 45
UR512005005025 R (mm): 0.05 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 2.5 | L (mm): 45
UR51200500503 R (mm): 0.05 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 3 | L (mm): 45
UR51200500504 R (mm): 0.05 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 4 | L (mm): 45
UR51200500505 R (mm): 0.05 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 5 | L (mm): 45
UR51200500506 R (mm): 0.05 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 6 | L (mm): 45
UR5120050101 R (mm): 0.1 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 1 | L (mm): 45
UR51200501015 R (mm): 0.1 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 1.5 | L (mm): 45
UR5120050102 R (mm): 0.1 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 2 | L (mm): 45
UR51200501025 R (mm): 0.1 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 2.5 | L (mm): 45
UR5120050103 R (mm): 0.1 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 3 | L (mm): 45
UR5120050104 R (mm): 0.1 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 4 | L (mm): 45
UR5120050105 R (mm): 0.1 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 5 | L (mm): 45
UR5120050106 R (mm): 0.1 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 6 | L (mm): 45
UR51200600502 R (mm): 0.05 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 2 | L (mm): 45
UR51200600503 R (mm): 0.05 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 3 | L (mm): 45
UR51200600504 R (mm): 0.05 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 4 | L (mm): 45
UR51200600506 R (mm): 0.05 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 6 | L (mm): 45
UR51200600508 R (mm): 0.05 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 8 | L (mm): 45
UR51200600510 R (mm): 0.05 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 10 | L (mm): 45
UR5120060102 R (mm): 0.1 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 2 | L (mm): 45
UR5120060103 R (mm): 0.1 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 3 | L (mm): 45
UR5120060104 R (mm): 0.1 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 4 | L (mm): 45
UR5120060106 R (mm): 0.1 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 6 | L (mm): 45
UR5120060108 R (mm): 0.1 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 8 | L (mm): 45
UR5120060110 R (mm): 0.1 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 10 | L (mm): 45
UR5120060202 R (mm): 0.2 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 2 | L (mm): 45
UR5120060203 R (mm): 0.2 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 3 | L (mm): 45
UR5120060204 R (mm): 0.2 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 4 | L (mm): 45
UR5120060206 R (mm): 0.2 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 6 | L (mm): 45
UR5120060208 R (mm): 0.2 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 8 | L (mm): 45
UR5120060210 R (mm): 0.2 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 10 | L (mm): 45
UR51200700502 R (mm): 0.05 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 2 | L (mm): 45
UR51200700504 R (mm): 0.05 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 4 | L (mm): 45
UR51200700506 R (mm): 0.05 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 6 | L (mm): 45
UR51200700508 R (mm): 0.05 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 8 | L (mm): 45
UR51200700510 R (mm): 0.05 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 10 | L (mm): 45
UR5120070102 R (mm): 0.1 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 2 | L (mm): 45
UR5120070104 R (mm): 0.1 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 4 | L (mm): 45
UR5120070106 R (mm): 0.1 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 6 | L (mm): 45
UR5120070108 R (mm): 0.1 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 8 | L (mm): 45
UR5120070110 R (mm): 0.1 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 10 | L (mm): 45
UR5120070202 R (mm): 0.2 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 2 | L (mm): 45
UR5120070204 R (mm): 0.2 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 4 | L (mm): 45
UR5120070206 R (mm): 0.2 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 6 | L (mm): 45
UR5120070208 R (mm): 0.2 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 8 | L (mm): 45
UR5120070210 R (mm): 0.2 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 10 | L (mm): 45
UR51200800502 R (mm): 0.05 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 2 | L (mm): 45
UR51200800503 R (mm): 0.05 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 3 | L (mm): 45
UR51200800504 R (mm): 0.05 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 4 | L (mm): 45
UR51200800506 R (mm): 0.05 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 6 | L (mm): 45
UR51200800508 R (mm): 0.05 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 8 | L (mm): 45
UR51200800510 R (mm): 0.05 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 10 | L (mm): 45
UR5120080102 R (mm): 0.1 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 2 | L (mm): 45
UR5120080103 R (mm): 0.1 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 3 | L (mm): 45
UR5120080104 R (mm): 0.1 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 4 | L (mm): 45
UR5120080106 R (mm): 0.1 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 6 | L (mm): 45
UR5120080108 R (mm): 0.1 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 8 | L (mm): 45
UR5120080110 R (mm): 0.1 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 10 | L (mm): 45
UR5120080202 R (mm): 0.2 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 2 | L (mm): 45
UR5120080203 R (mm): 0.2 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 3 | L (mm): 45
UR5120080204 R (mm): 0.2 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 4 | L (mm): 45
UR5120080206 R (mm): 0.2 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 6 | L (mm): 45
UR5120080208 R (mm): 0.2 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 8 | L (mm): 45
UR5120080210 R (mm): 0.2 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 10 | L (mm): 45
UR51201000503 R (mm): 0.05 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 3 | L (mm): 50
UR51201000504 R (mm): 0.05 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 4 | L (mm): 50
UR51201000506 R (mm): 0.05 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 6 | L (mm): 50
UR51201000508 R (mm): 0.05 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 8 | L (mm): 50
UR51201000510 R (mm): 0.05 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 10 | L (mm): 50
UR51201000512 R (mm): 0.05 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 12 | L (mm): 50
UR51201000514 R (mm): 0.05 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 14 | L (mm): 50
UR51201000516 R (mm): 0.05 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 16 | L (mm): 50
UR51201000520 R (mm): 0.05 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 20 | L (mm): 50
UR5120100103 R (mm): 0.1 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 3 | L (mm): 50
UR5120100104 R (mm): 0.1 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 4 | L (mm): 50
UR5120100106 R (mm): 0.1 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 6 | L (mm): 50
UR5120100108 R (mm): 0.1 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 8 | L (mm): 50
UR5120100110 R (mm): 0.1 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 10 | L (mm): 50
UR5120100112 R (mm): 0.1 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 12 | L (mm): 50
UR5120100114 R (mm): 0.1 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 14 | L (mm): 50
UR5120100116 R (mm): 0.1 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 16 | L (mm): 50
UR5120100120 R (mm): 0.1 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 20 | L (mm): 50
UR5120100203 R (mm): 0.2 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 3 | L (mm): 50
UR5120100204 R (mm): 0.2 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 4 | L (mm): 50
UR5120100206 R (mm): 0.2 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 6 | L (mm): 50
UR5120100208 R (mm): 0.2 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 8 | L (mm): 50
UR5120100210 R (mm): 0.2 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 10 | L (mm): 50
UR5120100212 R (mm): 0.2 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 12 | L (mm): 50
UR5120100214 R (mm): 0.2 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 14 | L (mm): 50
UR5120100216 R (mm): 0.2 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 16 | L (mm): 50
UR5120100220 R (mm): 0.2 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 20 | L (mm): 50
UR5120100303 R (mm): 0.3 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 3 | L (mm): 50
UR5120100304 R (mm): 0.3 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 4 | L (mm): 50
UR5120100306 R (mm): 0.3 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 6 | L (mm): 50
UR5120100308 R (mm): 0.3 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 8 | L (mm): 50
UR5120100310 R (mm): 0.3 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 10 | L (mm): 50
UR5120100312 R (mm): 0.3 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 12 | L (mm): 50
UR5120100314 R (mm): 0.3 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 14 | L (mm): 50
UR5120100316 R (mm): 0.3 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 16 | L (mm): 50
UR5120100320 R (mm): 0.3 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 20 | L (mm): 50
UR51201200503 R (mm): 0.05 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 3 | L (mm): 50
UR51201200504 R (mm): 0.05 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 4 | L (mm): 50
UR51201200506 R (mm): 0.05 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 6 | L (mm): 50
UR51201200508 R (mm): 0.05 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 8 | L (mm): 50
UR51201200510 R (mm): 0.05 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 10 | L (mm): 50
UR51201200512 R (mm): 0.05 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 12 | L (mm): 50
UR51201200516 R (mm): 0.05 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 16 | L (mm): 50
UR51201200520 R (mm): 0.05 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 20 | L (mm): 50
UR5120120103 R (mm): 0.1 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 3 | L (mm): 50
UR5120120104 R (mm): 0.1 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 4 | L (mm): 50
UR5120120106 R (mm): 0.1 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 6 | L (mm): 50
UR5120120108 R (mm): 0.1 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 8 | L (mm): 50
UR5120120110 R (mm): 0.1 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 10 | L (mm): 50
UR5120120112 R (mm): 0.1 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 12 | L (mm): 50
UR5120120116 R (mm): 0.1 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 16 | L (mm): 50
UR5120120120 R (mm): 0.1 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 20 | L (mm): 50
UR5120120203 R (mm): 0.2 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 3 | L (mm): 50
UR5120120204 R (mm): 0.2 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 4 | L (mm): 50
UR5120120206 R (mm): 0.2 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 6 | L (mm): 50
UR5120120208 R (mm): 0.2 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 8 | L (mm): 50
UR5120120210 R (mm): 0.2 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 10 | L (mm): 50
UR5120120212 R (mm): 0.2 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 12 | L (mm): 50
UR5120120216 R (mm): 0.2 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 16 | L (mm): 50
UR5120120220 R (mm): 0.2 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 20 | L (mm): 50
UR5120120303 R (mm): 0.3 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 3 | L (mm): 50
UR5120120304 R (mm): 0.3 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 4 | L (mm): 50
UR5120120306 R (mm): 0.3 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 6 | L (mm): 50
UR5120120308 R (mm): 0.3 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 8 | L (mm): 50
UR5120120310 R (mm): 0.3 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 10 | L (mm): 50
UR5120120312 R (mm): 0.3 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 12 | L (mm): 50
UR5120120316 R (mm): 0.3 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 16 | L (mm): 50
UR5120120320 R (mm): 0.3 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 20 | L (mm): 50
UR51201500504 R (mm): 0.05 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 4 | L (mm): 50
UR51201500506 R (mm): 0.05 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 6 | L (mm): 50
UR51201500508 R (mm): 0.05 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 8 | L (mm): 50
UR51201500510 R (mm): 0.05 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 10 | L (mm): 50
UR51201500512 R (mm): 0.05 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 12 | L (mm): 50
UR51201500514 R (mm): 0.05 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 14 | L (mm): 50
UR51201500516 R (mm): 0.05 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 16 | L (mm): 50
UR51201500520 R (mm): 0.05 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 20 | L (mm): 50
UR51201500522 R (mm): 0.05 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 22 | L (mm): 60
UR51201500526 R (mm): 0.05 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 26 | L (mm): 60
UR5120150104 R (mm): 0.1 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 4 | L (mm): 50
UR5120150106 R (mm): 0.1 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 6 | L (mm): 50
UR5120150108 R (mm): 0.1 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 8 | L (mm): 50
UR5120150110 R (mm): 0.1 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 10 | L (mm): 50
UR5120150112 R (mm): 0.1 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 12 | L (mm): 50
UR5120150114 R (mm): 0.1 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 14 | L (mm): 50
UR5120150116 R (mm): 0.1 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 16 | L (mm): 50
UR5120150120 R (mm): 0.1 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 20 | L (mm): 50
UR5120150122 R (mm): 0.1 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 22 | L (mm): 60
UR5120150126 R (mm): 0.1 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 26 | L (mm): 60
UR5120150204 R (mm): 0.2 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 4 | L (mm): 50
UR5120150206 R (mm): 0.2 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 6 | L (mm): 50
UR5120150208 R (mm): 0.2 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 8 | L (mm): 50
UR5120150210 R (mm): 0.2 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 10 | L (mm): 50
UR5120150212 R (mm): 0.2 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 12 | L (mm): 50
UR5120150214 R (mm): 0.2 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 14 | L (mm): 50
UR5120150216 R (mm): 0.2 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 16 | L (mm): 50
UR5120150220 R (mm): 0.2 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 20 | L (mm): 50
UR5120150222 R (mm): 0.2 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 22 | L (mm): 60
UR5120150226 R (mm): 0.2 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 26 | L (mm): 60
UR5120150304 R (mm): 0.3 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 4 | L (mm): 50
UR5120150306 R (mm): 0.3 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 6 | L (mm): 50
UR5120150308 R (mm): 0.3 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 8 | L (mm): 50
UR5120150310 R (mm): 0.3 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 10 | L (mm): 50
UR5120150312 R (mm): 0.3 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 12 | L (mm): 50
UR5120150314 R (mm): 0.3 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 14 | L (mm): 50
UR5120150316 R (mm): 0.3 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 16 | L (mm): 50
UR5120150320 R (mm): 0.3 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 20 | L (mm): 50
UR5120150322 R (mm): 0.3 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 22 | L (mm): 60
UR5120150326 R (mm): 0.3 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 26 | L (mm): 60
UR5120150504 R (mm): 0.5 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 4 | L (mm): 50
UR5120150506 R (mm): 0.5 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 6 | L (mm): 50
UR5120150508 R (mm): 0.5 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 8 | L (mm): 50
UR5120150510 R (mm): 0.5 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 10 | L (mm): 50
UR5120150512 R (mm): 0.5 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 12 | L (mm): 50
UR5120150514 R (mm): 0.5 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 14 | L (mm): 50
UR5120150516 R (mm): 0.5 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 16 | L (mm): 50
UR5120150520 R (mm): 0.5 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 20 | L (mm): 50
UR5120150522 R (mm): 0.5 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 22 | L (mm): 60
UR5120150526 R (mm): 0.5 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 26 | L (mm): 60
UR5120200106 R (mm): 0.1 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 6 | L (mm): 50
UR5120200108 R (mm): 0.1 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 8 | L (mm): 50
UR5120200110 R (mm): 0.1 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 10 | L (mm): 50
UR5120200112 R (mm): 0.1 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 12 | L (mm): 50
UR5120200114 R (mm): 0.1 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 14 | L (mm): 50
UR5120200116 R (mm): 0.1 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 16 | L (mm): 50
UR5120200120 R (mm): 0.1 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 20 | L (mm): 50
UR5120200122 R (mm): 0.1 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 22 | L (mm): 60
UR5120200126 R (mm): 0.1 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 26 | L (mm): 60
UR5120200130 R (mm): 0.1 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 30 | L (mm): 70
UR5120200206 R (mm): 0.2 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 6 | L (mm): 50
UR5120200208 R (mm): 0.2 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 8 | L (mm): 50
UR5120200210 R (mm): 0.2 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 10 | L (mm): 50
UR5120200212 R (mm): 0.2 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 12 | L (mm): 50
UR5120200214 R (mm): 0.2 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 14 | L (mm): 50
UR5120200216 R (mm): 0.2 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 16 | L (mm): 50
UR5120200220 R (mm): 0.2 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 20 | L (mm): 50
UR5120200222 R (mm): 0.2 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 22 | L (mm): 60
UR5120200226 R (mm): 0.2 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 26 | L (mm): 60
UR5120200230 R (mm): 0.2 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 30 | L (mm): 70
UR5120200306 R (mm): 0.3 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 6 | L (mm): 50
UR5120200308 R (mm): 0.3 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 8 | L (mm): 50
UR5120200310 R (mm): 0.3 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 10 | L (mm): 50
UR5120200312 R (mm): 0.3 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 12 | L (mm): 50
UR5120200314 R (mm): 0.3 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 14 | L (mm): 50
UR5120200316 R (mm): 0.3 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 16 | L (mm): 50
UR5120200320 R (mm): 0.3 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 20 | L (mm): 50
UR5120200322 R (mm): 0.3 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 22 | L (mm): 60
UR5120200326 R (mm): 0.3 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 26 | L (mm): 60
UR5120200330 R (mm): 0.3 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 30 | L (mm): 70
UR5120200506 R (mm): 0.5 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 6 | L (mm): 50
UR5120200508 R (mm): 0.5 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 8 | L (mm): 50
UR5120200510 R (mm): 0.5 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 10 | L (mm): 50
UR5120200512 R (mm): 0.5 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 12 | L (mm): 50
UR5120200514 R (mm): 0.5 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 14 | L (mm): 50
UR5120200516 R (mm): 0.5 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 16 | L (mm): 50
UR5120200520 R (mm): 0.5 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 20 | L (mm): 50
UR5120200522 R (mm): 0.5 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 22 | L (mm): 60
UR5120200526 R (mm): 0.5 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 26 | L (mm): 60
UR5120200530 R (mm): 0.5 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 30 | L (mm): 70
UR5120250108 R (mm): 0.1 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 8 | L (mm): 50
UR5120250110 R (mm): 0.1 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 10 | L (mm): 50
UR5120250112 R (mm): 0.1 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 12 | L (mm): 50
UR5120250114 R (mm): 0.1 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 14 | L (mm): 50
UR5120250116 R (mm): 0.1 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 16 | L (mm): 50
UR5120250120 R (mm): 0.1 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 20 | L (mm): 50
UR5120250126 R (mm): 0.1 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 26 | L (mm): 60
UR5120250130 R (mm): 0.1 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 30 | L (mm): 70
UR5120250208 R (mm): 0.2 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 8 | L (mm): 50
UR5120250210 R (mm): 0.2 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 10 | L (mm): 50
UR5120250212 R (mm): 0.2 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 12 | L (mm): 50
UR5120250214 R (mm): 0.2 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 14 | L (mm): 50
UR5120250216 R (mm): 0.2 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 16 | L (mm): 50
UR5120250220 R (mm): 0.2 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 20 | L (mm): 50
UR5120250226 R (mm): 0.2 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 26 | L (mm): 60
UR5120250230 R (mm): 0.2 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 30 | L (mm): 70
UR5120250308 R (mm): 0.3 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 8 | L (mm): 50
UR5120250310 R (mm): 0.3 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 10 | L (mm): 50
UR5120250312 R (mm): 0.3 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 12 | L (mm): 50
UR5120250314 R (mm): 0.3 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 14 | L (mm): 50
UR5120250316 R (mm): 0.3 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 16 | L (mm): 50
UR5120250320 R (mm): 0.3 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 20 | L (mm): 50
UR5120250326 R (mm): 0.3 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 26 | L (mm): 60
UR5120250330 R (mm): 0.3 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 30 | L (mm): 70
UR5120250508 R (mm): 0.5 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 8 | L (mm): 50
UR5120250510 R (mm): 0.5 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 10 | L (mm): 50
UR5120250512 R (mm): 0.5 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 12 | L (mm): 50
UR5120250514 R (mm): 0.5 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 14 | L (mm): 50
UR5120250516 R (mm): 0.5 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 16 | L (mm): 50
UR5120250520 R (mm): 0.5 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 20 | L (mm): 50
UR5120250526 R (mm): 0.5 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 26 | L (mm): 60
UR5120250530 R (mm): 0.5 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 30 | L (mm): 70
UR5120300108 R (mm): 0.1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 8 | L (mm): 50
UR5120300110 R (mm): 0.1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 10 | L (mm): 50
UR5120300112 R (mm): 0.1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 12 | L (mm): 50
UR5120300114 R (mm): 0.1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 14 | L (mm): 60
UR5120300116 R (mm): 0.1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 16 | L (mm): 60
UR5120300120 R (mm): 0.1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 20 | L (mm): 60
UR5120300126 R (mm): 0.1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 26 | L (mm): 65
UR5120300130 R (mm): 0.1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 30 | L (mm): 70
UR5120300135 R (mm): 0.1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 35 | L (mm): 70
UR5120300140 R (mm): 0.1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 40 | L (mm): 80
UR5120300208 R (mm): 0.2 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 8 | L (mm): 50
UR5120300210 R (mm): 0.2 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 10 | L (mm): 50
UR5120300212 R (mm): 0.2 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 12 | L (mm): 50
UR5120300214 R (mm): 0.2 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 14 | L (mm): 60
UR5120300216 R (mm): 0.2 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 16 | L (mm): 60
UR5120300220 R (mm): 0.2 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 20 | L (mm): 60
UR5120300226 R (mm): 0.2 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 26 | L (mm): 65
UR5120300230 R (mm): 0.2 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 30 | L (mm): 70
UR5120300235 R (mm): 0.2 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 35 | L (mm): 70
UR5120300240 R (mm): 0.2 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 40 | L (mm): 80
UR5120300308 R (mm): 0.3 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 8 | L (mm): 50
UR5120300310 R (mm): 0.3 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 10 | L (mm): 50
UR5120300312 R (mm): 0.3 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 12 | L (mm): 50
UR5120300314 R (mm): 0.3 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 14 | L (mm): 60
UR5120300316 R (mm): 0.3 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 16 | L (mm): 60
UR5120300320 R (mm): 0.3 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 20 | L (mm): 60
UR5120300326 R (mm): 0.3 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 26 | L (mm): 65
UR5120300330 R (mm): 0.3 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 30 | L (mm): 70
UR5120300335 R (mm): 0.3 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 35 | L (mm): 70
UR5120300340 R (mm): 0.3 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 40 | L (mm): 80
UR5120300508 R (mm): 0.5 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 8 | L (mm): 50
UR5120300510 R (mm): 0.5 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 10 | L (mm): 50
UR5120300512 R (mm): 0.5 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 12 | L (mm): 50
UR5120300514 R (mm): 0.5 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 14 | L (mm): 60
UR5120300516 R (mm): 0.5 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 16 | L (mm): 60
UR5120300520 R (mm): 0.5 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 20 | L (mm): 60
UR5120300526 R (mm): 0.5 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 26 | L (mm): 65
UR5120300530 R (mm): 0.5 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 30 | L (mm): 70
UR5120300535 R (mm): 0.5 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 35 | L (mm): 70
UR5120300540 R (mm): 0.5 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 40 | L (mm): 80
UR5120301008 R (mm): 1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 8 | L (mm): 50
UR5120301010 R (mm): 1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 10 | L (mm): 50
UR5120301012 R (mm): 1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 12 | L (mm): 50
UR5120301014 R (mm): 1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 14 | L (mm): 60
UR5120301016 R (mm): 1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 16 | L (mm): 60
UR5120301020 R (mm): 1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 20 | L (mm): 60
UR5120301026 R (mm): 1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 26 | L (mm): 65
UR5120301030 R (mm): 1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 30 | L (mm): 70
UR5120301035 R (mm): 1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 35 | L (mm): 70
UR5120301040 R (mm): 1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 40 | L (mm): 80
UR5120400110 R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 10 | L (mm): 50
UR5120400112 R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 12 | L (mm): 50
UR5120400114 R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 14 | L (mm): 60
UR5120400116 R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 16 | L (mm): 60
UR5120400120 R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 20 | L (mm): 60
UR5120400126 R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 26 | L (mm): 65
UR5120400130 R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 30 | L (mm): 65
UR5120400135 R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 35 | L (mm): 70
UR5120400140 R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 40 | L (mm): 80
UR5120400145 R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 45 | L (mm): 90
UR5120400150 R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 50 | L (mm): 100
UR5120400210 R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 10 | L (mm): 50
UR5120400212 R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 12 | L (mm): 50
UR5120400214 R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 14 | L (mm): 60
UR5120400216 R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 16 | L (mm): 60
UR5120400220 R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 20 | L (mm): 60
UR5120400226 R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 26 | L (mm): 65
UR5120400230 R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 30 | L (mm): 65
UR5120400235 R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 35 | L (mm): 70
UR5120400240 R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 40 | L (mm): 80
UR5120400245 R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 45 | L (mm): 90
UR5120400250 R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 50 | L (mm): 100
UR5120400310 R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 10 | L (mm): 50
UR5120400312 R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 12 | L (mm): 50
UR5120400314 R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 14 | L (mm): 60
UR5120400316 R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 16 | L (mm): 60
UR5120400320 R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 20 | L (mm): 60
UR5120400326 R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 26 | L (mm): 65
UR5120400330 R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 30 | L (mm): 65
UR5120400335 R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 35 | L (mm): 70
UR5120400340 R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 40 | L (mm): 80
UR5120400345 R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 45 | L (mm): 90
UR5120400350 R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 50 | L (mm): 100
UR5120400510 R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 10 | L (mm): 50
UR5120400512 R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 12 | L (mm): 50
UR5120400514 R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 14 | L (mm): 60
UR5120400516 R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 16 | L (mm): 60
UR5120400520 R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 20 | L (mm): 60
UR5120400526 R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 26 | L (mm): 65
UR5120400530 R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 30 | L (mm): 65
UR5120400535 R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 35 | L (mm): 70
UR5120400540 R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 40 | L (mm): 80
UR5120400545 R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 45 | L (mm): 90
UR5120400550 R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 50 | L (mm): 100
UR5120401010 R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 10 | L (mm): 50
UR5120401012 R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 12 | L (mm): 50
UR5120401014 R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 14 | L (mm): 60
UR5120401016 R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 16 | L (mm): 60
UR5120401020 R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 20 | L (mm): 60
UR5120401026 R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 26 | L (mm): 65
UR5120401030 R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 30 | L (mm): 65
UR5120401035 R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 35 | L (mm): 70
UR5120401040 R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 40 | L (mm): 80
UR5120401045 R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 45 | L (mm): 90
UR5120401050 R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 50 | L (mm): 100
UR51205001 R (mm): 0.1 | ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 8 | ℓ2 (mm): 15 | L (mm): 60
UR51205002 R (mm): 0.2 | ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 8 | ℓ2 (mm): 15 | L (mm): 60
UR51205003 R (mm): 0.3 | ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 8 | ℓ2 (mm): 15 | L (mm): 60
UR51205005 R (mm): 0.5 | ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 8 | ℓ2 (mm): 15 | L (mm): 60
UR51205010 R (mm): 1 | ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 8 | ℓ2 (mm): 15 | L (mm): 60
UR51205015 R (mm): 1.5 | ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 8 | ℓ2 (mm): 15 | L (mm): 60
UR51205020 R (mm): 2 | ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 8 | ℓ2 (mm): 15 | L (mm): 60
UR51206001 R (mm): 0.1 | ØD (mm): 6 | Ød (mm): 6 | ℓ1 (mm): 9 | ℓ2 (mm): 20 | L (mm): 60
UR51206002 R (mm): 0.2 | ØD (mm): 6 | Ød (mm): 6 | ℓ1 (mm): 9 | ℓ2 (mm): 20 | L (mm): 60
UR51206003 R (mm): 0.3 | ØD (mm): 6 | Ød (mm): 6 | ℓ1 (mm): 9 | ℓ2 (mm): 20 | L (mm): 60
UR5120600390 R (mm): 0.3 | ØD (mm): 6 | Ød (mm): 6 | ℓ1 (mm): 15 | ℓ2 (mm): 30 | L (mm): 90
UR51206005 R (mm): 0.5 | ØD (mm): 6 | Ød (mm): 6 | ℓ1 (mm): 9 | ℓ2 (mm): 20 | L (mm): 60
UR5120600590 R (mm): 0.5 | ØD (mm): 6 | Ød (mm): 6 | ℓ1 (mm): 15 | ℓ2 (mm): 30 | L (mm): 90
UR51206010 R (mm): 1 | ØD (mm): 6 | Ød (mm): 6 | ℓ1 (mm): 9 | ℓ2 (mm): 20 | L (mm): 60
UR5120601090 R (mm): 1 | ØD (mm): 6 | Ød (mm): 6 | ℓ1 (mm): 15 | ℓ2 (mm): 30 | L (mm): 90
UR51206015 R (mm): 1.5 | ØD (mm): 6 | Ød (mm): 6 | ℓ1 (mm): 9 | ℓ2 (mm): 20 | L (mm): 60
UR51206020 R (mm): 2 | ØD (mm): 6 | Ød (mm): 6 | ℓ1 (mm): 9 | ℓ2 (mm): 20 | L (mm): 60
UR51208001 R (mm): 0.1 | ØD (mm): 8 | Ød (mm): 8 | ℓ1 (mm): 12 | ℓ2 (mm): 25 | L (mm): 70
UR51208002 R (mm): 0.2 | ØD (mm): 8 | Ød (mm): 8 | ℓ1 (mm): 12 | ℓ2 (mm): 25 | L (mm): 70
UR51208003 R (mm): 0.3 | ØD (mm): 8 | Ød (mm): 8 | ℓ1 (mm): 12 | ℓ2 (mm): 25 | L (mm): 70
UR51208003100 R (mm): 0.3 | ØD (mm): 8 | Ød (mm): 8 | ℓ1 (mm): 20 | ℓ2 (mm): 35 | L (mm): 100
UR51208005 R (mm): 0.5 | ØD (mm): 8 | Ød (mm): 8 | ℓ1 (mm): 12 | ℓ2 (mm): 25 | L (mm): 70
UR51208005100 R (mm): 0.5 | ØD (mm): 8 | Ød (mm): 8 | ℓ1 (mm): 20 | ℓ2 (mm): 35 | L (mm): 100
UR51208010 R (mm): 1 | ØD (mm): 8 | Ød (mm): 8 | ℓ1 (mm): 12 | ℓ2 (mm): 25 | L (mm): 70
UR51208010100 R (mm): 1 | ØD (mm): 8 | Ød (mm): 8 | ℓ1 (mm): 20 | ℓ2 (mm): 35 | L (mm): 100
UR51208015 R (mm): 1.5 | ØD (mm): 8 | Ød (mm): 8 | ℓ1 (mm): 12 | ℓ2 (mm): 25 | L (mm): 70
UR51208020 R (mm): 2 | ØD (mm): 8 | Ød (mm): 8 | ℓ1 (mm): 12 | ℓ2 (mm): 25 | L (mm): 70
UR51210001 R (mm): 0.1 | ØD (mm): 10 | Ød (mm): 10 | ℓ1 (mm): 15 | ℓ2 (mm): 30 | L (mm): 75
UR51210002 R (mm): 0.2 | ØD (mm): 10 | Ød (mm): 10 | ℓ1 (mm): 15 | ℓ2 (mm): 30 | L (mm): 75
UR51210003 R (mm): 0.3 | ØD (mm): 10 | Ød (mm): 10 | ℓ1 (mm): 15 | ℓ2 (mm): 30 | L (mm): 75
UR51210003100 R (mm): 0.3 | ØD (mm): 10 | Ød (mm): 10 | ℓ1 (mm): 25 | ℓ2 (mm): 40 | L (mm): 100
UR51210005 R (mm): 0.5 | ØD (mm): 10 | Ød (mm): 10 | ℓ1 (mm): 15 | ℓ2 (mm): 30 | L (mm): 75
UR51210005100 R (mm): 0.5 | ØD (mm): 10 | Ød (mm): 10 | ℓ1 (mm): 25 | ℓ2 (mm): 40 | L (mm): 100
UR51210010 R (mm): 1 | ØD (mm): 10 | Ød (mm): 10 | ℓ1 (mm): 15 | ℓ2 (mm): 30 | L (mm): 75
UR51210010100 R (mm): 1 | ØD (mm): 10 | Ød (mm): 10 | ℓ1 (mm): 25 | ℓ2 (mm): 40 | L (mm): 100
UR51210015 R (mm): 1.5 | ØD (mm): 10 | Ød (mm): 10 | ℓ1 (mm): 15 | ℓ2 (mm): 30 | L (mm): 75
UR51210020 R (mm): 2 | ØD (mm): 10 | Ød (mm): 10 | ℓ1 (mm): 15 | ℓ2 (mm): 30 | L (mm): 75
UR51212002 R (mm): 0.2 | ØD (mm): 12 | Ød (mm): 12 | ℓ1 (mm): 18 | ℓ2 (mm): 32 | L (mm): 80
UR51212003 R (mm): 0.3 | ØD (mm): 12 | Ød (mm): 12 | ℓ1 (mm): 18 | ℓ2 (mm): 32 | L (mm): 80
UR51212003110 R (mm): 0.3 | ØD (mm): 12 | Ød (mm): 12 | ℓ1 (mm): 30 | ℓ2 (mm): 45 | L (mm): 110
UR51212005 R (mm): 0.5 | ØD (mm): 12 | Ød (mm): 12 | ℓ1 (mm): 18 | ℓ2 (mm): 32 | L (mm): 80
UR51212005110 R (mm): 0.5 | ØD (mm): 12 | Ød (mm): 12 | ℓ1 (mm): 30 | ℓ2 (mm): 45 | L (mm): 110
UR51212010 R (mm): 1 | ØD (mm): 12 | Ød (mm): 12 | ℓ1 (mm): 18 | ℓ2 (mm): 32 | L (mm): 80
UR51212010110 R (mm): 1 | ØD (mm): 12 | Ød (mm): 12 | ℓ1 (mm): 30 | ℓ2 (mm): 45 | L (mm): 110
UR51212015 R (mm): 1.5 | ØD (mm): 12 | Ød (mm): 12 | ℓ1 (mm): 18 | ℓ2 (mm): 32 | L (mm): 80
UR51212020 R (mm): 2 | ØD (mm): 12 | Ød (mm): 12 | ℓ1 (mm): 18 | ℓ2 (mm): 32 | L (mm): 80
UR51216005 R (mm): 0.5 | ØD (mm): 16 | Ød (mm): 16 | ℓ1 (mm): 20 | ℓ2 (mm): 35 | L (mm): 100
UR51216005150 R (mm): 0.5 | ØD (mm): 16 | Ød (mm): 16 | ℓ1 (mm): 35 | ℓ2 (mm): 50 | L (mm): 150
UR51216010 R (mm): 1 | ØD (mm): 16 | Ød (mm): 16 | ℓ1 (mm): 20 | ℓ2 (mm): 35 | L (mm): 100
UR51216010150 R (mm): 1 | ØD (mm): 16 | Ød (mm): 16 | ℓ1 (mm): 35 | ℓ2 (mm): 50 | L (mm): 150
UR51220005 R (mm): 0.5 | ØD (mm): 20 | Ød (mm): 20 | ℓ1 (mm): 25 | ℓ2 (mm): 40 | L (mm): 100
UR51220005150 R (mm): 0.5 | ØD (mm): 20 | Ød (mm): 20 | ℓ1 (mm): 40 | ℓ2 (mm): 55 | L (mm): 150
UR51220010 R (mm): 1 | ØD (mm): 20 | Ød (mm): 20 | ℓ1 (mm): 25 | ℓ2 (mm): 40 | L (mm): 100
UR51220010150 R (mm): 1 | ØD (mm): 20 | Ød (mm): 20 | ℓ1 (mm): 40 | ℓ2 (mm): 55 | L (mm): 150
End MillsKorloy
442 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Korloy U-Star 2 Flute Neck Type Radius End Mill UR512

Brand Korloy·End Mills

Available part numbers (442)

UR512002002005, UR51200200201, UR512002002015, UR51200200202, UR512002005005, UR51200200501, UR512002005015, UR51200200502, UR51200300201, UR51200300202 + 432 more — see full table ↓

How to order

Send the Korloy part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
UR512002002005R (mm): 0.02 | ØD (mm): 0.2 | Ød (mm): 4 | ℓ1 (mm): 0.3 | ℓ2 (mm): 0.5 | L (mm): 40
UR51200200201R (mm): 0.02 | ØD (mm): 0.2 | Ød (mm): 4 | ℓ1 (mm): 0.3 | ℓ2 (mm): 1 | L (mm): 40
UR512002002015R (mm): 0.02 | ØD (mm): 0.2 | Ød (mm): 4 | ℓ1 (mm): 0.3 | ℓ2 (mm): 1.5 | L (mm): 40
UR51200200202R (mm): 0.02 | ØD (mm): 0.2 | Ød (mm): 4 | ℓ1 (mm): 0.3 | ℓ2 (mm): 2 | L (mm): 40
UR512002005005R (mm): 0.05 | ØD (mm): 0.2 | Ød (mm): 4 | ℓ1 (mm): 0.3 | ℓ2 (mm): 0.5 | L (mm): 40
UR51200200501R (mm): 0.05 | ØD (mm): 0.2 | Ød (mm): 4 | ℓ1 (mm): 0.3 | ℓ2 (mm): 1 | L (mm): 40
UR512002005015R (mm): 0.05 | ØD (mm): 0.2 | Ød (mm): 4 | ℓ1 (mm): 0.3 | ℓ2 (mm): 1.5 | L (mm): 40
UR51200200502R (mm): 0.05 | ØD (mm): 0.2 | Ød (mm): 4 | ℓ1 (mm): 0.3 | ℓ2 (mm): 2 | L (mm): 40
UR51200300201R (mm): 0.02 | ØD (mm): 0.3 | Ød (mm): 4 | ℓ1 (mm): 0.5 | ℓ2 (mm): 1 | L (mm): 40
UR51200300202R (mm): 0.02 | ØD (mm): 0.3 | Ød (mm): 4 | ℓ1 (mm): 0.5 | ℓ2 (mm): 2 | L (mm): 40
UR51200300203R (mm): 0.02 | ØD (mm): 0.3 | Ød (mm): 4 | ℓ1 (mm): 0.5 | ℓ2 (mm): 3 | L (mm): 40
UR51200300501R (mm): 0.05 | ØD (mm): 0.3 | Ød (mm): 4 | ℓ1 (mm): 0.5 | ℓ2 (mm): 1 | L (mm): 40
UR51200300502R (mm): 0.05 | ØD (mm): 0.3 | Ød (mm): 4 | ℓ1 (mm): 0.5 | ℓ2 (mm): 2 | L (mm): 40
UR51200300503R (mm): 0.05 | ØD (mm): 0.3 | Ød (mm): 4 | ℓ1 (mm): 0.5 | ℓ2 (mm): 3 | L (mm): 40
UR51200400501R (mm): 0.05 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 1 | L (mm): 40
UR512004005015R (mm): 0.05 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 1.5 | L (mm): 40
UR51200400502R (mm): 0.05 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 2 | L (mm): 40
UR512004005025R (mm): 0.05 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 2.5 | L (mm): 40
UR51200400503R (mm): 0.05 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 3 | L (mm): 40
UR51200400504R (mm): 0.05 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 4 | L (mm): 40
UR5120040101R (mm): 0.1 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 1 | L (mm): 40
UR51200401015R (mm): 0.1 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 1.5 | L (mm): 40
UR5120040102R (mm): 0.1 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 2 | L (mm): 40
UR51200401025R (mm): 0.1 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 2.5 | L (mm): 40
UR5120040103R (mm): 0.1 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 3 | L (mm): 40
UR5120040104R (mm): 0.1 | ØD (mm): 0.4 | Ød (mm): 4 | ℓ1 (mm): 0.6 | ℓ2 (mm): 4 | L (mm): 40
UR51200500501R (mm): 0.05 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 1 | L (mm): 45
UR512005005015R (mm): 0.05 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 1.5 | L (mm): 45
UR51200500502R (mm): 0.05 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 2 | L (mm): 45
UR512005005025R (mm): 0.05 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 2.5 | L (mm): 45
UR51200500503R (mm): 0.05 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 3 | L (mm): 45
UR51200500504R (mm): 0.05 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 4 | L (mm): 45
UR51200500505R (mm): 0.05 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 5 | L (mm): 45
UR51200500506R (mm): 0.05 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 6 | L (mm): 45
UR5120050101R (mm): 0.1 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 1 | L (mm): 45
UR51200501015R (mm): 0.1 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 1.5 | L (mm): 45
UR5120050102R (mm): 0.1 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 2 | L (mm): 45
UR51200501025R (mm): 0.1 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 2.5 | L (mm): 45
UR5120050103R (mm): 0.1 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 3 | L (mm): 45
UR5120050104R (mm): 0.1 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 4 | L (mm): 45
UR5120050105R (mm): 0.1 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 5 | L (mm): 45
UR5120050106R (mm): 0.1 | ØD (mm): 0.5 | Ød (mm): 4 | ℓ1 (mm): 0.7 | ℓ2 (mm): 6 | L (mm): 45
UR51200600502R (mm): 0.05 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 2 | L (mm): 45
UR51200600503R (mm): 0.05 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 3 | L (mm): 45
UR51200600504R (mm): 0.05 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 4 | L (mm): 45
UR51200600506R (mm): 0.05 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 6 | L (mm): 45
UR51200600508R (mm): 0.05 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 8 | L (mm): 45
UR51200600510R (mm): 0.05 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 10 | L (mm): 45
UR5120060102R (mm): 0.1 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 2 | L (mm): 45
UR5120060103R (mm): 0.1 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 3 | L (mm): 45
UR5120060104R (mm): 0.1 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 4 | L (mm): 45
UR5120060106R (mm): 0.1 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 6 | L (mm): 45
UR5120060108R (mm): 0.1 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 8 | L (mm): 45
UR5120060110R (mm): 0.1 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 10 | L (mm): 45
UR5120060202R (mm): 0.2 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 2 | L (mm): 45
UR5120060203R (mm): 0.2 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 3 | L (mm): 45
UR5120060204R (mm): 0.2 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 4 | L (mm): 45
UR5120060206R (mm): 0.2 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 6 | L (mm): 45
UR5120060208R (mm): 0.2 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 8 | L (mm): 45
UR5120060210R (mm): 0.2 | ØD (mm): 0.6 | Ød (mm): 4 | ℓ1 (mm): 0.9 | ℓ2 (mm): 10 | L (mm): 45
UR51200700502R (mm): 0.05 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 2 | L (mm): 45
UR51200700504R (mm): 0.05 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 4 | L (mm): 45
UR51200700506R (mm): 0.05 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 6 | L (mm): 45
UR51200700508R (mm): 0.05 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 8 | L (mm): 45
UR51200700510R (mm): 0.05 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 10 | L (mm): 45
UR5120070102R (mm): 0.1 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 2 | L (mm): 45
UR5120070104R (mm): 0.1 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 4 | L (mm): 45
UR5120070106R (mm): 0.1 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 6 | L (mm): 45
UR5120070108R (mm): 0.1 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 8 | L (mm): 45
UR5120070110R (mm): 0.1 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 10 | L (mm): 45
UR5120070202R (mm): 0.2 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 2 | L (mm): 45
UR5120070204R (mm): 0.2 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 4 | L (mm): 45
UR5120070206R (mm): 0.2 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 6 | L (mm): 45
UR5120070208R (mm): 0.2 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 8 | L (mm): 45
UR5120070210R (mm): 0.2 | ØD (mm): 0.7 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 10 | L (mm): 45
UR51200800502R (mm): 0.05 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 2 | L (mm): 45
UR51200800503R (mm): 0.05 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 3 | L (mm): 45
UR51200800504R (mm): 0.05 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 4 | L (mm): 45
UR51200800506R (mm): 0.05 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 6 | L (mm): 45
UR51200800508R (mm): 0.05 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 8 | L (mm): 45
UR51200800510R (mm): 0.05 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 10 | L (mm): 45
UR5120080102R (mm): 0.1 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 2 | L (mm): 45
UR5120080103R (mm): 0.1 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 3 | L (mm): 45
UR5120080104R (mm): 0.1 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 4 | L (mm): 45
UR5120080106R (mm): 0.1 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 6 | L (mm): 45
UR5120080108R (mm): 0.1 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 8 | L (mm): 45
UR5120080110R (mm): 0.1 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 10 | L (mm): 45
UR5120080202R (mm): 0.2 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 2 | L (mm): 45
UR5120080203R (mm): 0.2 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 3 | L (mm): 45
UR5120080204R (mm): 0.2 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 4 | L (mm): 45
UR5120080206R (mm): 0.2 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 6 | L (mm): 45
UR5120080208R (mm): 0.2 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 8 | L (mm): 45
UR5120080210R (mm): 0.2 | ØD (mm): 0.8 | Ød (mm): 4 | ℓ1 (mm): 1.2 | ℓ2 (mm): 10 | L (mm): 45
UR51201000503R (mm): 0.05 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 3 | L (mm): 50
UR51201000504R (mm): 0.05 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 4 | L (mm): 50
UR51201000506R (mm): 0.05 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 6 | L (mm): 50
UR51201000508R (mm): 0.05 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 8 | L (mm): 50
UR51201000510R (mm): 0.05 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 10 | L (mm): 50
UR51201000512R (mm): 0.05 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 12 | L (mm): 50
UR51201000514R (mm): 0.05 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 14 | L (mm): 50
UR51201000516R (mm): 0.05 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 16 | L (mm): 50
UR51201000520R (mm): 0.05 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 20 | L (mm): 50
UR5120100103R (mm): 0.1 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 3 | L (mm): 50
UR5120100104R (mm): 0.1 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 4 | L (mm): 50
UR5120100106R (mm): 0.1 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 6 | L (mm): 50
UR5120100108R (mm): 0.1 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 8 | L (mm): 50
UR5120100110R (mm): 0.1 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 10 | L (mm): 50
UR5120100112R (mm): 0.1 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 12 | L (mm): 50
UR5120100114R (mm): 0.1 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 14 | L (mm): 50
UR5120100116R (mm): 0.1 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 16 | L (mm): 50
UR5120100120R (mm): 0.1 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 20 | L (mm): 50
UR5120100203R (mm): 0.2 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 3 | L (mm): 50
UR5120100204R (mm): 0.2 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 4 | L (mm): 50
UR5120100206R (mm): 0.2 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 6 | L (mm): 50
UR5120100208R (mm): 0.2 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 8 | L (mm): 50
UR5120100210R (mm): 0.2 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 10 | L (mm): 50
UR5120100212R (mm): 0.2 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 12 | L (mm): 50
UR5120100214R (mm): 0.2 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 14 | L (mm): 50
UR5120100216R (mm): 0.2 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 16 | L (mm): 50
UR5120100220R (mm): 0.2 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 20 | L (mm): 50
UR5120100303R (mm): 0.3 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 3 | L (mm): 50
UR5120100304R (mm): 0.3 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 4 | L (mm): 50
UR5120100306R (mm): 0.3 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 6 | L (mm): 50
UR5120100308R (mm): 0.3 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 8 | L (mm): 50
UR5120100310R (mm): 0.3 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 10 | L (mm): 50
UR5120100312R (mm): 0.3 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 12 | L (mm): 50
UR5120100314R (mm): 0.3 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 14 | L (mm): 50
UR5120100316R (mm): 0.3 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 16 | L (mm): 50
UR5120100320R (mm): 0.3 | ØD (mm): 1 | Ød (mm): 4 | ℓ1 (mm): 1.5 | ℓ2 (mm): 20 | L (mm): 50
UR51201200503R (mm): 0.05 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 3 | L (mm): 50
UR51201200504R (mm): 0.05 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 4 | L (mm): 50
UR51201200506R (mm): 0.05 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 6 | L (mm): 50
UR51201200508R (mm): 0.05 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 8 | L (mm): 50
UR51201200510R (mm): 0.05 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 10 | L (mm): 50
UR51201200512R (mm): 0.05 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 12 | L (mm): 50
UR51201200516R (mm): 0.05 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 16 | L (mm): 50
UR51201200520R (mm): 0.05 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 20 | L (mm): 50
UR5120120103R (mm): 0.1 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 3 | L (mm): 50
UR5120120104R (mm): 0.1 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 4 | L (mm): 50
UR5120120106R (mm): 0.1 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 6 | L (mm): 50
UR5120120108R (mm): 0.1 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 8 | L (mm): 50
UR5120120110R (mm): 0.1 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 10 | L (mm): 50
UR5120120112R (mm): 0.1 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 12 | L (mm): 50
UR5120120116R (mm): 0.1 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 16 | L (mm): 50
UR5120120120R (mm): 0.1 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 20 | L (mm): 50
UR5120120203R (mm): 0.2 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 3 | L (mm): 50
UR5120120204R (mm): 0.2 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 4 | L (mm): 50
UR5120120206R (mm): 0.2 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 6 | L (mm): 50
UR5120120208R (mm): 0.2 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 8 | L (mm): 50
UR5120120210R (mm): 0.2 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 10 | L (mm): 50
UR5120120212R (mm): 0.2 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 12 | L (mm): 50
UR5120120216R (mm): 0.2 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 16 | L (mm): 50
UR5120120220R (mm): 0.2 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 20 | L (mm): 50
UR5120120303R (mm): 0.3 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 3 | L (mm): 50
UR5120120304R (mm): 0.3 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 4 | L (mm): 50
UR5120120306R (mm): 0.3 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 6 | L (mm): 50
UR5120120308R (mm): 0.3 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 8 | L (mm): 50
UR5120120310R (mm): 0.3 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 10 | L (mm): 50
UR5120120312R (mm): 0.3 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 12 | L (mm): 50
UR5120120316R (mm): 0.3 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 16 | L (mm): 50
UR5120120320R (mm): 0.3 | ØD (mm): 1.2 | Ød (mm): 4 | ℓ1 (mm): 1.8 | ℓ2 (mm): 20 | L (mm): 50
UR51201500504R (mm): 0.05 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 4 | L (mm): 50
UR51201500506R (mm): 0.05 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 6 | L (mm): 50
UR51201500508R (mm): 0.05 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 8 | L (mm): 50
UR51201500510R (mm): 0.05 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 10 | L (mm): 50
UR51201500512R (mm): 0.05 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 12 | L (mm): 50
UR51201500514R (mm): 0.05 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 14 | L (mm): 50
UR51201500516R (mm): 0.05 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 16 | L (mm): 50
UR51201500520R (mm): 0.05 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 20 | L (mm): 50
UR51201500522R (mm): 0.05 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 22 | L (mm): 60
UR51201500526R (mm): 0.05 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 26 | L (mm): 60
UR5120150104R (mm): 0.1 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 4 | L (mm): 50
UR5120150106R (mm): 0.1 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 6 | L (mm): 50
UR5120150108R (mm): 0.1 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 8 | L (mm): 50
UR5120150110R (mm): 0.1 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 10 | L (mm): 50
UR5120150112R (mm): 0.1 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 12 | L (mm): 50
UR5120150114R (mm): 0.1 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 14 | L (mm): 50
UR5120150116R (mm): 0.1 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 16 | L (mm): 50
UR5120150120R (mm): 0.1 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 20 | L (mm): 50
UR5120150122R (mm): 0.1 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 22 | L (mm): 60
UR5120150126R (mm): 0.1 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 26 | L (mm): 60
UR5120150204R (mm): 0.2 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 4 | L (mm): 50
UR5120150206R (mm): 0.2 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 6 | L (mm): 50
UR5120150208R (mm): 0.2 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 8 | L (mm): 50
UR5120150210R (mm): 0.2 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 10 | L (mm): 50
UR5120150212R (mm): 0.2 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 12 | L (mm): 50
UR5120150214R (mm): 0.2 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 14 | L (mm): 50
UR5120150216R (mm): 0.2 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 16 | L (mm): 50
UR5120150220R (mm): 0.2 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 20 | L (mm): 50
UR5120150222R (mm): 0.2 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 22 | L (mm): 60
UR5120150226R (mm): 0.2 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 26 | L (mm): 60
UR5120150304R (mm): 0.3 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 4 | L (mm): 50
UR5120150306R (mm): 0.3 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 6 | L (mm): 50
UR5120150308R (mm): 0.3 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 8 | L (mm): 50
UR5120150310R (mm): 0.3 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 10 | L (mm): 50
UR5120150312R (mm): 0.3 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 12 | L (mm): 50
UR5120150314R (mm): 0.3 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 14 | L (mm): 50
UR5120150316R (mm): 0.3 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 16 | L (mm): 50
UR5120150320R (mm): 0.3 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 20 | L (mm): 50
UR5120150322R (mm): 0.3 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 22 | L (mm): 60
UR5120150326R (mm): 0.3 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 26 | L (mm): 60
UR5120150504R (mm): 0.5 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 4 | L (mm): 50
UR5120150506R (mm): 0.5 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 6 | L (mm): 50
UR5120150508R (mm): 0.5 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 8 | L (mm): 50
UR5120150510R (mm): 0.5 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 10 | L (mm): 50
UR5120150512R (mm): 0.5 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 12 | L (mm): 50
UR5120150514R (mm): 0.5 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 14 | L (mm): 50
UR5120150516R (mm): 0.5 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 16 | L (mm): 50
UR5120150520R (mm): 0.5 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 20 | L (mm): 50
UR5120150522R (mm): 0.5 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 22 | L (mm): 60
UR5120150526R (mm): 0.5 | ØD (mm): 1.5 | Ød (mm): 4 | ℓ1 (mm): 2.3 | ℓ2 (mm): 26 | L (mm): 60
UR5120200106R (mm): 0.1 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 6 | L (mm): 50
UR5120200108R (mm): 0.1 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 8 | L (mm): 50
UR5120200110R (mm): 0.1 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 10 | L (mm): 50
UR5120200112R (mm): 0.1 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 12 | L (mm): 50
UR5120200114R (mm): 0.1 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 14 | L (mm): 50
UR5120200116R (mm): 0.1 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 16 | L (mm): 50
UR5120200120R (mm): 0.1 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 20 | L (mm): 50
UR5120200122R (mm): 0.1 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 22 | L (mm): 60
UR5120200126R (mm): 0.1 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 26 | L (mm): 60
UR5120200130R (mm): 0.1 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 30 | L (mm): 70
UR5120200206R (mm): 0.2 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 6 | L (mm): 50
UR5120200208R (mm): 0.2 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 8 | L (mm): 50
UR5120200210R (mm): 0.2 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 10 | L (mm): 50
UR5120200212R (mm): 0.2 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 12 | L (mm): 50
UR5120200214R (mm): 0.2 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 14 | L (mm): 50
UR5120200216R (mm): 0.2 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 16 | L (mm): 50
UR5120200220R (mm): 0.2 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 20 | L (mm): 50
UR5120200222R (mm): 0.2 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 22 | L (mm): 60
UR5120200226R (mm): 0.2 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 26 | L (mm): 60
UR5120200230R (mm): 0.2 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 30 | L (mm): 70
UR5120200306R (mm): 0.3 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 6 | L (mm): 50
UR5120200308R (mm): 0.3 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 8 | L (mm): 50
UR5120200310R (mm): 0.3 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 10 | L (mm): 50
UR5120200312R (mm): 0.3 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 12 | L (mm): 50
UR5120200314R (mm): 0.3 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 14 | L (mm): 50
UR5120200316R (mm): 0.3 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 16 | L (mm): 50
UR5120200320R (mm): 0.3 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 20 | L (mm): 50
UR5120200322R (mm): 0.3 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 22 | L (mm): 60
UR5120200326R (mm): 0.3 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 26 | L (mm): 60
UR5120200330R (mm): 0.3 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 30 | L (mm): 70
UR5120200506R (mm): 0.5 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 6 | L (mm): 50
UR5120200508R (mm): 0.5 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 8 | L (mm): 50
UR5120200510R (mm): 0.5 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 10 | L (mm): 50
UR5120200512R (mm): 0.5 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 12 | L (mm): 50
UR5120200514R (mm): 0.5 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 14 | L (mm): 50
UR5120200516R (mm): 0.5 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 16 | L (mm): 50
UR5120200520R (mm): 0.5 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 20 | L (mm): 50
UR5120200522R (mm): 0.5 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 22 | L (mm): 60
UR5120200526R (mm): 0.5 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 26 | L (mm): 60
UR5120200530R (mm): 0.5 | ØD (mm): 2 | Ød (mm): 4 | ℓ1 (mm): 3 | ℓ2 (mm): 30 | L (mm): 70
UR5120250108R (mm): 0.1 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 8 | L (mm): 50
UR5120250110R (mm): 0.1 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 10 | L (mm): 50
UR5120250112R (mm): 0.1 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 12 | L (mm): 50
UR5120250114R (mm): 0.1 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 14 | L (mm): 50
UR5120250116R (mm): 0.1 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 16 | L (mm): 50
UR5120250120R (mm): 0.1 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 20 | L (mm): 50
UR5120250126R (mm): 0.1 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 26 | L (mm): 60
UR5120250130R (mm): 0.1 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 30 | L (mm): 70
UR5120250208R (mm): 0.2 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 8 | L (mm): 50
UR5120250210R (mm): 0.2 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 10 | L (mm): 50
UR5120250212R (mm): 0.2 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 12 | L (mm): 50
UR5120250214R (mm): 0.2 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 14 | L (mm): 50
UR5120250216R (mm): 0.2 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 16 | L (mm): 50
UR5120250220R (mm): 0.2 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 20 | L (mm): 50
UR5120250226R (mm): 0.2 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 26 | L (mm): 60
UR5120250230R (mm): 0.2 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 30 | L (mm): 70
UR5120250308R (mm): 0.3 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 8 | L (mm): 50
UR5120250310R (mm): 0.3 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 10 | L (mm): 50
UR5120250312R (mm): 0.3 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 12 | L (mm): 50
UR5120250314R (mm): 0.3 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 14 | L (mm): 50
UR5120250316R (mm): 0.3 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 16 | L (mm): 50
UR5120250320R (mm): 0.3 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 20 | L (mm): 50
UR5120250326R (mm): 0.3 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 26 | L (mm): 60
UR5120250330R (mm): 0.3 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 30 | L (mm): 70
UR5120250508R (mm): 0.5 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 8 | L (mm): 50
UR5120250510R (mm): 0.5 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 10 | L (mm): 50
UR5120250512R (mm): 0.5 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 12 | L (mm): 50
UR5120250514R (mm): 0.5 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 14 | L (mm): 50
UR5120250516R (mm): 0.5 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 16 | L (mm): 50
UR5120250520R (mm): 0.5 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 20 | L (mm): 50
UR5120250526R (mm): 0.5 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 26 | L (mm): 60
UR5120250530R (mm): 0.5 | ØD (mm): 2.5 | Ød (mm): 4 | ℓ1 (mm): 4 | ℓ2 (mm): 30 | L (mm): 70
UR5120300108R (mm): 0.1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 8 | L (mm): 50
UR5120300110R (mm): 0.1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 10 | L (mm): 50
UR5120300112R (mm): 0.1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 12 | L (mm): 50
UR5120300114R (mm): 0.1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 14 | L (mm): 60
UR5120300116R (mm): 0.1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 16 | L (mm): 60
UR5120300120R (mm): 0.1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 20 | L (mm): 60
UR5120300126R (mm): 0.1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 26 | L (mm): 65
UR5120300130R (mm): 0.1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 30 | L (mm): 70
UR5120300135R (mm): 0.1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 35 | L (mm): 70
UR5120300140R (mm): 0.1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 40 | L (mm): 80
UR5120300208R (mm): 0.2 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 8 | L (mm): 50
UR5120300210R (mm): 0.2 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 10 | L (mm): 50
UR5120300212R (mm): 0.2 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 12 | L (mm): 50
UR5120300214R (mm): 0.2 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 14 | L (mm): 60
UR5120300216R (mm): 0.2 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 16 | L (mm): 60
UR5120300220R (mm): 0.2 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 20 | L (mm): 60
UR5120300226R (mm): 0.2 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 26 | L (mm): 65
UR5120300230R (mm): 0.2 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 30 | L (mm): 70
UR5120300235R (mm): 0.2 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 35 | L (mm): 70
UR5120300240R (mm): 0.2 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 40 | L (mm): 80
UR5120300308R (mm): 0.3 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 8 | L (mm): 50
UR5120300310R (mm): 0.3 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 10 | L (mm): 50
UR5120300312R (mm): 0.3 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 12 | L (mm): 50
UR5120300314R (mm): 0.3 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 14 | L (mm): 60
UR5120300316R (mm): 0.3 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 16 | L (mm): 60
UR5120300320R (mm): 0.3 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 20 | L (mm): 60
UR5120300326R (mm): 0.3 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 26 | L (mm): 65
UR5120300330R (mm): 0.3 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 30 | L (mm): 70
UR5120300335R (mm): 0.3 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 35 | L (mm): 70
UR5120300340R (mm): 0.3 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 40 | L (mm): 80
UR5120300508R (mm): 0.5 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 8 | L (mm): 50
UR5120300510R (mm): 0.5 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 10 | L (mm): 50
UR5120300512R (mm): 0.5 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 12 | L (mm): 50
UR5120300514R (mm): 0.5 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 14 | L (mm): 60
UR5120300516R (mm): 0.5 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 16 | L (mm): 60
UR5120300520R (mm): 0.5 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 20 | L (mm): 60
UR5120300526R (mm): 0.5 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 26 | L (mm): 65
UR5120300530R (mm): 0.5 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 30 | L (mm): 70
UR5120300535R (mm): 0.5 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 35 | L (mm): 70
UR5120300540R (mm): 0.5 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 40 | L (mm): 80
UR5120301008R (mm): 1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 8 | L (mm): 50
UR5120301010R (mm): 1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 10 | L (mm): 50
UR5120301012R (mm): 1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 12 | L (mm): 50
UR5120301014R (mm): 1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 14 | L (mm): 60
UR5120301016R (mm): 1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 16 | L (mm): 60
UR5120301020R (mm): 1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 20 | L (mm): 60
UR5120301026R (mm): 1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 26 | L (mm): 65
UR5120301030R (mm): 1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 30 | L (mm): 70
UR5120301035R (mm): 1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 35 | L (mm): 70
UR5120301040R (mm): 1 | ØD (mm): 3 | Ød (mm): 6 | ℓ1 (mm): 4.5 | ℓ2 (mm): 40 | L (mm): 80
UR5120400110R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 10 | L (mm): 50
UR5120400112R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 12 | L (mm): 50
UR5120400114R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 14 | L (mm): 60
UR5120400116R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 16 | L (mm): 60
UR5120400120R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 20 | L (mm): 60
UR5120400126R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 26 | L (mm): 65
UR5120400130R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 30 | L (mm): 65
UR5120400135R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 35 | L (mm): 70
UR5120400140R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 40 | L (mm): 80
UR5120400145R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 45 | L (mm): 90
UR5120400150R (mm): 0.1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 50 | L (mm): 100
UR5120400210R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 10 | L (mm): 50
UR5120400212R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 12 | L (mm): 50
UR5120400214R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 14 | L (mm): 60
UR5120400216R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 16 | L (mm): 60
UR5120400220R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 20 | L (mm): 60
UR5120400226R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 26 | L (mm): 65
UR5120400230R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 30 | L (mm): 65
UR5120400235R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 35 | L (mm): 70
UR5120400240R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 40 | L (mm): 80
UR5120400245R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 45 | L (mm): 90
UR5120400250R (mm): 0.2 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 50 | L (mm): 100
UR5120400310R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 10 | L (mm): 50
UR5120400312R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 12 | L (mm): 50
UR5120400314R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 14 | L (mm): 60
UR5120400316R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 16 | L (mm): 60
UR5120400320R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 20 | L (mm): 60
UR5120400326R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 26 | L (mm): 65
UR5120400330R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 30 | L (mm): 65
UR5120400335R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 35 | L (mm): 70
UR5120400340R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 40 | L (mm): 80
UR5120400345R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 45 | L (mm): 90
UR5120400350R (mm): 0.3 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 50 | L (mm): 100
UR5120400510R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 10 | L (mm): 50
UR5120400512R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 12 | L (mm): 50
UR5120400514R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 14 | L (mm): 60
UR5120400516R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 16 | L (mm): 60
UR5120400520R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 20 | L (mm): 60
UR5120400526R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 26 | L (mm): 65
UR5120400530R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 30 | L (mm): 65
UR5120400535R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 35 | L (mm): 70
UR5120400540R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 40 | L (mm): 80
UR5120400545R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 45 | L (mm): 90
UR5120400550R (mm): 0.5 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 50 | L (mm): 100
UR5120401010R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 10 | L (mm): 50
UR5120401012R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 12 | L (mm): 50
UR5120401014R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 14 | L (mm): 60
UR5120401016R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 16 | L (mm): 60
UR5120401020R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 20 | L (mm): 60
UR5120401026R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 26 | L (mm): 65
UR5120401030R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 30 | L (mm): 65
UR5120401035R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 35 | L (mm): 70
UR5120401040R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 40 | L (mm): 80
UR5120401045R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 45 | L (mm): 90
UR5120401050R (mm): 1 | ØD (mm): 4 | Ød (mm): 6 | ℓ1 (mm): 6 | ℓ2 (mm): 50 | L (mm): 100
UR51205001R (mm): 0.1 | ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 8 | ℓ2 (mm): 15 | L (mm): 60
UR51205002R (mm): 0.2 | ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 8 | ℓ2 (mm): 15 | L (mm): 60
UR51205003R (mm): 0.3 | ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 8 | ℓ2 (mm): 15 | L (mm): 60
UR51205005R (mm): 0.5 | ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 8 | ℓ2 (mm): 15 | L (mm): 60
UR51205010R (mm): 1 | ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 8 | ℓ2 (mm): 15 | L (mm): 60
UR51205015R (mm): 1.5 | ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 8 | ℓ2 (mm): 15 | L (mm): 60
UR51205020R (mm): 2 | ØD (mm): 5 | Ød (mm): 6 | ℓ1 (mm): 8 | ℓ2 (mm): 15 | L (mm): 60
UR51206001R (mm): 0.1 | ØD (mm): 6 | Ød (mm): 6 | ℓ1 (mm): 9 | ℓ2 (mm): 20 | L (mm): 60
UR51206002R (mm): 0.2 | ØD (mm): 6 | Ød (mm): 6 | ℓ1 (mm): 9 | ℓ2 (mm): 20 | L (mm): 60
UR51206003R (mm): 0.3 | ØD (mm): 6 | Ød (mm): 6 | ℓ1 (mm): 9 | ℓ2 (mm): 20 | L (mm): 60
UR5120600390R (mm): 0.3 | ØD (mm): 6 | Ød (mm): 6 | ℓ1 (mm): 15 | ℓ2 (mm): 30 | L (mm): 90
UR51206005R (mm): 0.5 | ØD (mm): 6 | Ød (mm): 6 | ℓ1 (mm): 9 | ℓ2 (mm): 20 | L (mm): 60
UR5120600590R (mm): 0.5 | ØD (mm): 6 | Ød (mm): 6 | ℓ1 (mm): 15 | ℓ2 (mm): 30 | L (mm): 90
UR51206010R (mm): 1 | ØD (mm): 6 | Ød (mm): 6 | ℓ1 (mm): 9 | ℓ2 (mm): 20 | L (mm): 60
UR5120601090R (mm): 1 | ØD (mm): 6 | Ød (mm): 6 | ℓ1 (mm): 15 | ℓ2 (mm): 30 | L (mm): 90
UR51206015R (mm): 1.5 | ØD (mm): 6 | Ød (mm): 6 | ℓ1 (mm): 9 | ℓ2 (mm): 20 | L (mm): 60
UR51206020R (mm): 2 | ØD (mm): 6 | Ød (mm): 6 | ℓ1 (mm): 9 | ℓ2 (mm): 20 | L (mm): 60
UR51208001R (mm): 0.1 | ØD (mm): 8 | Ød (mm): 8 | ℓ1 (mm): 12 | ℓ2 (mm): 25 | L (mm): 70
UR51208002R (mm): 0.2 | ØD (mm): 8 | Ød (mm): 8 | ℓ1 (mm): 12 | ℓ2 (mm): 25 | L (mm): 70
UR51208003R (mm): 0.3 | ØD (mm): 8 | Ød (mm): 8 | ℓ1 (mm): 12 | ℓ2 (mm): 25 | L (mm): 70
UR51208003100R (mm): 0.3 | ØD (mm): 8 | Ød (mm): 8 | ℓ1 (mm): 20 | ℓ2 (mm): 35 | L (mm): 100
UR51208005R (mm): 0.5 | ØD (mm): 8 | Ød (mm): 8 | ℓ1 (mm): 12 | ℓ2 (mm): 25 | L (mm): 70
UR51208005100R (mm): 0.5 | ØD (mm): 8 | Ød (mm): 8 | ℓ1 (mm): 20 | ℓ2 (mm): 35 | L (mm): 100
UR51208010R (mm): 1 | ØD (mm): 8 | Ød (mm): 8 | ℓ1 (mm): 12 | ℓ2 (mm): 25 | L (mm): 70
UR51208010100R (mm): 1 | ØD (mm): 8 | Ød (mm): 8 | ℓ1 (mm): 20 | ℓ2 (mm): 35 | L (mm): 100
UR51208015R (mm): 1.5 | ØD (mm): 8 | Ød (mm): 8 | ℓ1 (mm): 12 | ℓ2 (mm): 25 | L (mm): 70
UR51208020R (mm): 2 | ØD (mm): 8 | Ød (mm): 8 | ℓ1 (mm): 12 | ℓ2 (mm): 25 | L (mm): 70
UR51210001R (mm): 0.1 | ØD (mm): 10 | Ød (mm): 10 | ℓ1 (mm): 15 | ℓ2 (mm): 30 | L (mm): 75
UR51210002R (mm): 0.2 | ØD (mm): 10 | Ød (mm): 10 | ℓ1 (mm): 15 | ℓ2 (mm): 30 | L (mm): 75
UR51210003R (mm): 0.3 | ØD (mm): 10 | Ød (mm): 10 | ℓ1 (mm): 15 | ℓ2 (mm): 30 | L (mm): 75
UR51210003100R (mm): 0.3 | ØD (mm): 10 | Ød (mm): 10 | ℓ1 (mm): 25 | ℓ2 (mm): 40 | L (mm): 100
UR51210005R (mm): 0.5 | ØD (mm): 10 | Ød (mm): 10 | ℓ1 (mm): 15 | ℓ2 (mm): 30 | L (mm): 75
UR51210005100R (mm): 0.5 | ØD (mm): 10 | Ød (mm): 10 | ℓ1 (mm): 25 | ℓ2 (mm): 40 | L (mm): 100
UR51210010R (mm): 1 | ØD (mm): 10 | Ød (mm): 10 | ℓ1 (mm): 15 | ℓ2 (mm): 30 | L (mm): 75
UR51210010100R (mm): 1 | ØD (mm): 10 | Ød (mm): 10 | ℓ1 (mm): 25 | ℓ2 (mm): 40 | L (mm): 100
UR51210015R (mm): 1.5 | ØD (mm): 10 | Ød (mm): 10 | ℓ1 (mm): 15 | ℓ2 (mm): 30 | L (mm): 75
UR51210020R (mm): 2 | ØD (mm): 10 | Ød (mm): 10 | ℓ1 (mm): 15 | ℓ2 (mm): 30 | L (mm): 75
UR51212002R (mm): 0.2 | ØD (mm): 12 | Ød (mm): 12 | ℓ1 (mm): 18 | ℓ2 (mm): 32 | L (mm): 80
UR51212003R (mm): 0.3 | ØD (mm): 12 | Ød (mm): 12 | ℓ1 (mm): 18 | ℓ2 (mm): 32 | L (mm): 80
UR51212003110R (mm): 0.3 | ØD (mm): 12 | Ød (mm): 12 | ℓ1 (mm): 30 | ℓ2 (mm): 45 | L (mm): 110
UR51212005R (mm): 0.5 | ØD (mm): 12 | Ød (mm): 12 | ℓ1 (mm): 18 | ℓ2 (mm): 32 | L (mm): 80
UR51212005110R (mm): 0.5 | ØD (mm): 12 | Ød (mm): 12 | ℓ1 (mm): 30 | ℓ2 (mm): 45 | L (mm): 110
UR51212010R (mm): 1 | ØD (mm): 12 | Ød (mm): 12 | ℓ1 (mm): 18 | ℓ2 (mm): 32 | L (mm): 80
UR51212010110R (mm): 1 | ØD (mm): 12 | Ød (mm): 12 | ℓ1 (mm): 30 | ℓ2 (mm): 45 | L (mm): 110
UR51212015R (mm): 1.5 | ØD (mm): 12 | Ød (mm): 12 | ℓ1 (mm): 18 | ℓ2 (mm): 32 | L (mm): 80
UR51212020R (mm): 2 | ØD (mm): 12 | Ød (mm): 12 | ℓ1 (mm): 18 | ℓ2 (mm): 32 | L (mm): 80
UR51216005R (mm): 0.5 | ØD (mm): 16 | Ød (mm): 16 | ℓ1 (mm): 20 | ℓ2 (mm): 35 | L (mm): 100
UR51216005150R (mm): 0.5 | ØD (mm): 16 | Ød (mm): 16 | ℓ1 (mm): 35 | ℓ2 (mm): 50 | L (mm): 150
UR51216010R (mm): 1 | ØD (mm): 16 | Ød (mm): 16 | ℓ1 (mm): 20 | ℓ2 (mm): 35 | L (mm): 100
UR51216010150R (mm): 1 | ØD (mm): 16 | Ød (mm): 16 | ℓ1 (mm): 35 | ℓ2 (mm): 50 | L (mm): 150
UR51220005R (mm): 0.5 | ØD (mm): 20 | Ød (mm): 20 | ℓ1 (mm): 25 | ℓ2 (mm): 40 | L (mm): 100
UR51220005150R (mm): 0.5 | ØD (mm): 20 | Ød (mm): 20 | ℓ1 (mm): 40 | ℓ2 (mm): 55 | L (mm): 150
UR51220010R (mm): 1 | ØD (mm): 20 | Ød (mm): 20 | ℓ1 (mm): 25 | ℓ2 (mm): 40 | L (mm): 100
UR51220010150R (mm): 1 | ØD (mm): 20 | Ød (mm): 20 | ℓ1 (mm): 40 | ℓ2 (mm): 55 | L (mm): 150

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Cutting Tools →
